Side 1/8
Outdoor Video Surveillance UPS
Installation Guide
Models Include:
ReServ1WPV
- Twelve (12) true sine wave regulated 24VAC outputs
and Four (4) regulated 12VDC outputs.
- 4 amp total supply current @ 24VAC and 2 amp total supply current @ 12VDC.
- PTC protected power-limited outputs.
ReServ2WPV
- Sixteen (16) true sine wave regulated 24VAC outputs.
- 4 amp total supply current.
- PTC protected power-limited outputs.
ReServ3WPV
- Sixteen (16) regulated 12VDC outputs.
- 8 amp total supply current.
- PTC protected power-limited outputs.
More than just power.™
- 2 - ReServWPV
Overview:
ReServWPV Outdoor Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cameras
during normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
ReServWPV Series Outdoor Video Surveillance UPS Configuration Reference Chart:
Altronix
Model Number
Output/Supply
Current (Amp
Ambient
Temperature Input Rating
PTC
Protected
Power-
Limited
Outputs
24VAC
Outputs
12VDC
Outputs
ReServ1WPV
24VAC @ 4 amp (100VA)
and 12VDC @ 2 amp -33º - 30º C 220VAC 50Hz,
2 amp 16 12 4
24VAC @ 3.5 amp (85VA)
and 12VDC @ 2 amp -33º - 42º C
ReServ2WPV 24VAC @ 4 amp (100VA) -33º - 30º C 220VAC 50Hz,
2 amp 16 16 ----
24VAC @ 3.5 amp (85VA) -33º - 42º C
ReServ3WPV 12VDC @ 8 amp -33º - 42º C 220VAC 50Hz,
2 amp 16 16----
Specifications:
Stand-by Specifications:
Stand-by Batteries
ReServ1WPV - 4 amp (100VA) load at 24VAC and 2 amp load at 12VDC max.
ReServ2WPV - 4 amp (100VA) max. load at 24VAC
ReServ3WPV - 8 amp (100VA) max. load at 12VDC
Two (2) 12VDC/7AH 45 minutes
Two (2) 12VDC/12AH 90 minutes
Installation Instructions:
This installation should be made by qualified service personnel and should conform to all local codes and in accordance
with the National Electrical Code. This product contains no serviceable parts.
1. Remove back plate inside the enclosure by removing the four (4) mounting screws.
2. Mark and drill desired knockouts on the enclosure to facilitate wiring .(Fig. 1, pg. 3)
It is required to use UL Listed outdoor rated conduit hubs with a minimum outdoor rating of 4X.Note:
3. Secure back plate inside enclosure with the four (4) mounting screws.
4. Mark and drill holes that line up with the top and bottom holes of the enclosure flange Mount unit in the desired
location with the appropriate fasteners . Secure enclosure to earth ground. (Pgs. 7 and 8)
This product needs to be secured to the building/pole before operation.Note:
5. Connect AC power mains to the terminals marked [L] and [N] .(Figs. 2-3, pg. 5-6)
Use 18 AWG or larger for all power connections (Battery, output) .(Figs. 2-3, pg. 5-6)
Use 18 AWG to 22 AWG for power limited circuits (AC Fail/Low Battery reporting) .(Figs. 2-3, pg. 5-6)
A readily accessible disconnect device shall be incorporated in the building installation wiring.Note:
6. The LEDs on the power supply board will illuminate when AC power is present.
7. Measure output voltage before connecting cameras/devices to outputs. This helps avoiding potential damage.
Output:
• PTC protected power-limited outputs are rated @ 1 amp.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery when AC fails.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
Visual and Audio Indicators:
• AC/DC power LED indicators.
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• Audio AC Fail and Battery Fail indicator.
Additional Features:
• True sine wave regulated AC outputs (ReServ1WPV and
ReServ2WPV). Regulated DC outputs (ReServ1WPV and
ReServ3WPV).
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
Enclosure Dimensions:
• NEMA4 / IP66 Rated enclosure.
• Accommodates up to two (2) 12VDC/7AH batteries or
two (2) 12VDC/12AH batteries.
17.375” x 12” x 6.5” (441.3mm x 304.8mm x 165.1mm)
