Rev. 082510 More than just power.TM
Video Surveillance UPS
Installation Guide
Models Include:
ReServ1
- Twelve (12) true sine wave regulated 24VAC outputs and four (4) regulated 12VDC outputs.
- 4A total supply current @ 24VAC and 2A total supply current @ 12VDC.
- PTC protected power-limited outputs.
ReServ2
- Sixteen (16) true sine wave regulated 24VAC outputs.
- 4A total supply current.
- PTC protected power-limited outputs.
ReServ3
- Sixteen (16) regulated 12VDC outputs.
- 8A total supply current.
- PTC protected power-limited outputs.
- 2 - ReServ
Overview:
Altronix ReServ Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cameras
during normal or power outage conditions.
True sine wave regulated AC outputs and/or regulated DC outputs.
ReServ Series Video Surveillance UPS
Configuration Reference Chart:
Altronix
Model
Number
Output/Supply
Current (A)
Ambient
Temperature
Input
Rating
PTC Protected
Power-Limited Outputs
24VAC Outputs
12VDC Outputs
Agency
Listings
UL Listings and
File Numbers
ReServ1
24VAC @ 4A (100VA)
& 12VDC @ 2A -33º to 30ºC
115VAC
60Hz, 3.5A 16 12 4 UL File # E329542
UL 60950-1
UL/CUL Listed
for
Information
Technology
Equipment.
24VAC @ 3.5A (85VA)
& 12VDC @ 2A -33º to 42ºC
ReServ2
24VAC @ 4A (100VA) -33º to 30ºC 115VAC
60Hz, 3.5A 16 16 –
24VAC @ 3.5A (85VA) -33º to 42ºC
ReServ3 12VDC @ 8A -33º to 42ºC 115VAC
60Hz, 3.5A 16 –16
Specifications:
Output:
• PTC protected power-limited outputs rated @ 1A.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switchover to stand-by battery
when AC fails.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
Visual & Audio Indicators:
• AC/DC power LED indicators.
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• Audio AC Fail and Battery Fail indicator.
Additional Features:
• True sine wave regulated AC outputs
(ReServ1 & ReServ2).
Regulated DC outputs (ReServ1 & ReServ3).
• Unit maintains camera synchronization.
• Ease of installation saves time and
eliminates costly labor.
Enclosure Dimensions :(H x W x D approximate)
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm)
• Enclosure accommodates up to
two (2) 12VDC/7AH batteries.
Stand-by Specifications:
Stand-by Batteries
ReServ1 - 4A (100VA) load at 24VAC and 2A load at 12VDC max.
ReServ2 - 4A (100VA) max. load at 24VAC
ReServ3 - 8A (100VA) max. load at 12VDC
Two (2) 12VDC/7AH 45 minutes
Two (2) 12VDC/12AH 90 minutes
*When using 12AH batteries or larger a separate UL Listed battery enclosure must be installed.
Optional UL Listed battery enclosure must be mounted adjacent to the power supply via Class 1 wiring methods.
