Side 1/8
Outdoor Video Surveillance UPS
Installation Guide
Models Include:
ReServ1WP
- Twelve (12) true sine wave regulated 24VAC outputs
and Four (4) regulated 12VDC outputs.
- 4 amp total supply current @ 24VAC and 2 amp total supply current @ 12VDC.
- PTC protected power-limited outputs.
ReServ2WP
- Sixteen (16) true sine wave regulated 24VAC outputs.
- 4 amp total supply current.
- PTC protected power-limited outputs.
ReServ3WP
- Sixteen (16) regulated 12VDC outputs.
- 8 amp total supply current.
- PTC protected power-limited outputs.
Rev. 082610 More than just power.™
- 2 - ReServWP
Overview:
ReServWP Outdoor Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cameras during
normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
ReServWP Series Outdoor Video Surveillance UPS Configuration Reference Chart:
Altronix
Model Number
Output/Supply
Current (Amp
Ambient
Temperature
Input Rating
PTC Protected
Power-Limited
Outputs
24VAC Outputs
12VDC Outputs
Agency Listings
UL Listings
and
File Numbers
ReServ1WP
24VAC @ 4 amp (100VA)
and 12VDC @ 2 amp -33º - 30º C 115VAC
60Hz,
3.5 amp
16 12 4
UL File # E329542
UL 60950-1
UL/CUL Listed
for
Information
Technology
Equipment.
UL 60950-22
Information Technology
Equipment - Safety -
Part 22: Equipment to
be Installed Outdoors
24VAC @ 3.5 amp (85VA)
and 12VDC @ 2 amp -33º - 42º C
ReServ2WP
24VAC @ 4 amp (100VA) -33º - 30º C 115VAC
60Hz,
3.5 amp
16 16 ----
24VAC @ 3.5 amp (85VA) -33º - 42º C
ReServ3WP 12VDC @ 8 amp -33º - 42º C
115VAC
60Hz,
3.5 amp
16 16----
Specifications:
Stand-by Specifications:
Stand-by Batteries
ReServ1WP - 4 amp (100VA) load at 24VAC and 2 amp load at 12VDC max.
ReServ2WP - 4 amp (100VA) max. load at 24VAC
ReServ3WP - 8 amp (100VA) max. load at 12VDC
Two (2) 12VDC/7AH 45 minutes
Two (2) 12VDC/12AH 90 minutes
Installation Instructions:
This installation should be made by qualified service personnel and should conform to all local codes and in accordance
with the National Electrical Code. This product contains no serviceable parts.
1. Remove back plate inside the enclosure by removing four (4) mounting screws.
2. Mark and drill desired knockouts on the enclosure to facilitate wiring .(Fig. 1, pg. 3)
It is required to use UL Listed outdoor rated conduit hubs with a minimum outdoor rating of 4X.Note:
3. Secure back plate inside the enclosure with four (4) mounting screws.
4. Mount unit in the desired location with the appropriate fasteners utilizing the holes provided on the
enclosure’s flanges . Secure enclosure to earth ground. (Pgs. 7 and 8)
This product needs to be secured to the building/pole before operation.Note:
5. Connect AC power mains to the terminals marked [L] and [N], .(Figs. 2-3, pg. 5-6)
Output:
• PTCprotectedpower-limitedoutputsarerated@1amp.
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
• Automaticswitchovertostand-bybatterywhenACfails.
Supervision:
• ACfailsupervision(form“C”contacts).
• Lowbatterysupervision(form“C”contacts).
Visual and Audio Indicators:
• AC/DCpowerLEDindicators.
• IndividualpoweroutputLEDindicators.
• LowvoltageinputandShutdownLEDindicators.
• AudioACFailandBatteryFailindicator.
Additional Features:
• TruesinewaveregulatedACoutputs(ReServ1WPand
ReServ2WP). Regulated DC outputs (ReServ1WP and
ReServ3WP).
• Unitmaintainscamerasynchronization.
• Easeofinstallationsavestimeandeliminatescostlylabor.
Enclosure Dimensions :(H x W x D)
• NEMA4/IP66Ratedenclosure.
• Accommodatesuptotwo(2)12VDC/7AHbatteriesor
two (2) 12VDC/12AH batteries.
 17.375”x12”x6.5”(441.3mmx304.8mmx165.1mm)
