OPERATING INSTRUCTIONS

· Batteries: Locate battery compartment latch on top of megaphone (A).

Open and insert 8 "C" size batteries (not included) into the battery sleeves

(B). (C) Follow battery diagram on label and sleeves for battery direction.

Close megaphone.

· Battery Status: The megaphone has 3 LED's LOW, MID, HIGH (D), that will tell

you the current strength of the battery. Note: Drained batteries do not give

sufficient sound volume. Replace the batteries when LOW LED lights when

trigger is squeezed. Remove batteries when not in use for a long time.

· Talk: Make sure that the switch is in the (E) Off / Talk position. Place mouth

about one inch from microphone squeeze trigger and speak or you can (F), (G)

slide switch on the side of the microphone up into the locked position. (H) ON

CAUTION: If you do not move switch into the OFF position when done,

megaphone will stay ON and drain the batteries. Microphone can also be re-

moved from bracket. To increase volume, rotate volume control knob from bot- (I)

tom to top.

When you have a fresh set of batteries you may get "feedback" when talking. To

eliminate feedback you need to turn down the gain. Locate the gain control in (J)

the battery compartment. Turn until you do not hear any feedback. Less gain,

turn counter clockwise. More gain, turn clockwise.

Siren: To activate , move switch to the right. Siren will be heard. There Siren (E)

is no control of the volume.

· Whistle: To activate Whistle (E), move switch to the left. Whistle will be heard.

There is no control of the volume.

· Property Label: Located on the bottom of the bell. Use marking pen to write

ownership name on megaphone.

IF YOU HAVE ANY QUESTIONS OR PROBLEMS PLEASE CALL

OUR CUSTOMER SERVICE DEPARTMENT AT 1-800-267-5486

Thank you for purchasing

AmpliVox S602MR MITY-MEG PLUS 25 Watt MEGAPHONE

We encourage you to visit our website to register www.ampli.com

your product for its warranty coverage, sign up to receive our news-

letter, download our catalog, and learn more about the complete line

of AmpliVox audio visual products, including portable PA systems,

and lecterns.

WHY USE RECHARGEABLE BATTERIES?

Save Money—While rechargeable batteries cost more initially, they can be reused hundreds of times

and last for years.

Protect the Environment Conserve Resources —

The corrosive materials and heavy metals in batteries can impair human health and the environment.

Rechargeable batteries use greatly reduces the quantity of batteries manufactured, used and discarded.

· Rechargeable Battery Pack is available for this model: Optional Lithium-ion battery S1405

pack with built-in wall charger. Replaces the 8 "C" size batteries.

· A fully charged battery will provide 8 hours of typical operation, defined as speaking 35% of

the time at mid volume, and over one year of standby / idle time

Available only from AmpliVox Resellers or AmpliVox Portable Sound Systems

WARRANTY

Limited One (1) Year Warranty

AmpliVox warrants this product to be free from defects in materials and workmanship (subject to the terms

set forth below) for a period of one (1) year from the date of purchase ( Warranty Period ). “ ”

During the Warranty Period, AmpliVox will repair or replace (at AmpliVox discretion) this product or any de-

fective parts ( Warranty Service ). “ ”

Repair or replacement under the terms of this warranty does not give right to any extension or a new begin-

ning of the period of warranty.

CLAIMS UNDER THE WARRANTY

To obtain Warranty Service, contact AmpliVox (800-267-5486) to be assigned a Return Authorization number

(RA#). After receiving RA #, the defective unit is to be returned to AmpliVox in either its original packaging or

packaging aording an equal degree of protection. You will bear the cost of shipping the product to Am-

pliVox. If the product is covered by the warranty, AmpliVox will bear the cost of shipping product back to you

after the completion of service under this warranty.

Return shipping will be charged to you for products not covered by the warranty or requiring no warranty re-

pair.

The following information must be presented to obtain Warranty Service: (a) the RA# must

be clearly and legibility marked on the outside of shipping carton, (b) proof of purchase,

which clearly indicates the name and address of the seller, the date of purchase and the

product type, which is evidence that this product is within the Warranty Period. Please fur-

ther include (c) your return address, (d) daytime telephone number, and (e) reason for return.

LIMITATION OF WARRANTY

This warranty is only valid for the original purchaser and will automatically terminate prior to expiration if this

product is sold or otherwise transferred to another party. The warranty provided by AmpliVox in this state-

ment applies only to products purchased for use, and not for resale. It does not apply to open box purchases,

which are sold as is and without any warranty. Specically exempt from warranty are limited-life consum-“ ”

able components subject to normal wear and tear, such as microphone windscreens, ear cushions, modular

plugs, ear tips, decorative finishes, batteries, and other accessories. This warranty is invalid if the factory-

applied serial number, date code label, or product label has been altered or removed from this product. This

warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, Acts of Nature, ac-

cident, disassembling or modication of, or to any part of, the product. This warranty does not cover damage

due to improper operation, maintenance or installation, or attempted repair by anyone other than AmpliVox.

Any unauthorized repairs will void this warranty.

Repairs or replacements as provided under this warranty are the exclusive remedy of the consumer.

Amplivox shall not be liable for any incidental or consequential damages for breach of any express or implied

warranty on this product except to the extent prohibited by law, this warranty is exclusive and in lieu of all

other express and implied warranties what so ever, including but not limited to the warranty of merchantability

and tness for a practical purpose.

NOTE! This warranty gives you specic legal rights. You may have other rights which vary from location to

location. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or

implied warranties, so the above exclusions may not apply to you. This warranty does not aect your legal

(statutory) rights under your applicable national or local laws.

AmpliVox - 650 Anthony Trail, Suite D, Northbrook, IL 60062 - Phone: (800)267-5486 Fax: (800)267-5489 www.ampli.com

Dispose of the product according

to local standards and regulations

April, 2014

Produkt Specifikationer

Mærke:	AmpliVox
Kategori:	Megafon
Model:	S602MR
Vægt:	1134 g
Velegnet til:	Udendørs
Produktfarve:	Red, White
Udgangseffekt:	25 W
Strømkilde type:	Batteri
Diameter:	228.6 mm
Længde:	381 mm
Maks. rækkevidde:	1609.3 m
Megafontilstande:	Tale
