Side 1/4

AtlasSound.com 1/4

1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: (800) 876-3333

FAX (800) 765-3435

Strategy Series® II In-Ceiling 4" Speaker System

FAP40T(B)

Speciﬁcations

Power Rating 16 Watts (8Ω)

Transformer Taps 1, 2, 4, 8, & 16 Watts & 8 BypassΩ

Frequency Response 100Hz – 12kHz (±3dB)

80Hz – 15kHz (±5dB)

Sensitivity (1W / 1M) 87dB

Woofer 4" Polypropylene with SBR Surround

Woofer Magnet Weight 13 oz (369g)

Bezel Diameter 73⁄8" (187mm)

Overall Height 71⁄8" (181mm)

Cut-Out Diameter 65⁄16" (160mm)

Features

• Tuned & Ported Design for Extended Bass Response

• 16 Watts Internal Transformer

• 8Ω Transformer Bypass Setting

• Low Profile Plastic Enclosure

• Input Via 2 Pole Terminal Strip

• Press-Fit Grille Blends Perfectly into Contemporary Architecture

• Lightweight Construction Makes Use of Additional Support in Drywall

Ceilings Unnecessary

• Tile Bridge Included

• Perfect Companion with the FAPSUB Subwoofer System When Sub

Bass Is Required

• Also Available in Black FAP40T-B

• UL 1480 Listed

Applications

Designed to provide high performance in a very compact footprint, the

FAP40T appeals to both system designers and architects. FAP40T is ideal

for high-intelligibility voice, music, and signal reproduction in commercial,

industrial, and institutional applications.

General Description

A unique, patented tap selector switch design allows for easy system

tuning. A full selection of taps up to 16 Watts as well as an 8 transΩ-

former bypass setting is included for maximum system versatility. This

switch "knob" also functions as a diffuser cone, providing smooth, even

dispersion of the high frequency content from the center of the 4" poly-

propylene driver. In fact, the high frequency response of the FAP40T is

so natural that many would assume that the driver in the FAP40T was a

coaxial design instead of a single cone driver.

Low frequency response is enhanced by the tuned and ported enclosure

design. The enclosure (UL1480 Listed) is constructed of high impact

injection molded plastic and includes a press fit grille design that blends

well with contemporary architecture.

A two pole terminal strip housed below a removable metal cover on the

back of the FAP40T enclosure allows for easy system wiring as well as

"daisy chain" wiring to other FAP40Ts or even FAPSUB subwoofers (a

great combination).

FAP40T

FAP40T-B

AtlasSound.com 2/4

1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: (800) 876-3333

FAX (800) 765-3435

Mounting Accessories

A Tile Bridge is included in the package for suspended ceiling applica-

tions. The light weight design of the FAP40T coupled with the "Dog Leg"

mounting system allows the FAP40T to mount into most drywall ceilings

without the need for a separate mounting ring.

For new construction drywall ceiling applications, the optional FA-TR4

trim ring is available. This unit provides a marked location for drywall

installers to cut around, essentially reserving the desired location in the

ceiling until final installation of FAP40T. Mounting holes are provided to

accommodate 16" or 24" OC stud / joist mounting.

The package includes an attractive press-fit grille, which nicely matches

contemporary architecture.

The FAP40T includes a secondary support point built into the termination

cover. This "ring" may be used with an auxiliary support cable in drop tile

installations.

Architect & Engineer Speciﬁcations

The loudspeaker system shall be Atlas Sound FAP40T. System shall

include a high performance 4" loudspeaker, ported bass reflex enclosure

and press-fit grille for conventional ceiling installation.

Frequency response for the system shall be 100Hz – 12kHz (±3dB),

80Hz – 15kHz (±5dB). Sensitivity shall be 87dB average.

Loudspeaker shall be compromised of a 4" cone type driver. Cone shall

be constructed of polypropylene with a butyl rubber surround. Magnet

shall be a minimum of 13oz (368.5g) and the voice coil diameter shall be

1" (25mm).

Transformer shall be a 70.7V / 100V type with 1, 2, 4, 8, and 16 watt

primary taps (@70.7V) with a front mounted tap selector switch. This

tap selector switch shall also include a transformer bypass setting for

instances where the 8 FAP40T driver is to be direct coupled with Ω

a low impedance amplifier.

Enclosure shall be an injection molded plastic design. Internal volume

shall be 85 in3 (1.4L).

To facilitate connection in conduit systems, enclosure shall be equipped

with an access panel covering a recessed terminal cup. This cover shall

provide a 7⁄8" (22mm inside diameter) hole for top access.

External wiring shall be accomplished via a two pole terminal strip with

screw-down terminals to provide secure wire termination.

The system shall include a tile bridge assembly to reinforce the ceil-

ing material. The tile bridge shall be designed for use on either 2' x 4'

(609mm x 1219mm) or 2' x 2' (609mm x 609mm) suspended ceiling tiles.

Overall front face diameter shall not exceed 7

3⁄8" (187mm); overall height

shall not exceed 7

1⁄8" (181mm).

Grilles shall be press-fit, manufactured from 24-gauge perforated steel

mesh and finished in white epoxy. Round grille shall be 5

1⁄2" (140mm)

diameter.

The loudspeaker shall be the Atlas Sound FAP40T.

FAP40T

(Shown Installed in Drop Tile Ceiling)

FAP40T

(Dog Ears Open on Included Tile Bridge)
