Side 1/5
AtlasSound.com 1/4
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
©2013 Atlas Sound L.P. All rights reserved. Atlas Sound and Strategy Series are trademarks of Atlas Sound L.P. All other trademarks are the property of their respective owners. ATS004633 RevB 7/13
Strategy Series® III In-Ceiling 6" 60° Coaxial Speaker System
FAP6260T
Specifications
Power Rating 60 Watts
Transformer Taps 70.7V TAPS : 3.8, 7.5, 15, 30, & 60 Watts
& 8 Bypass1
100V TAPS : 7.5, 15, 30, 60 Watts,
& 8 Bypass1
Frequency Response 63Hz – 20kHz (±7dB)
Sensitivity (1W/1m) 92dB
Dispersion 60°
Woofer 6" Composite Cone Butyl Rubber Surround
Woofer Magnet Weight 20 oz (398g)
HF Driver 20mm Coaxial Horn-Loaded Silk Dome
Tweeter
Diameter 10.972" (279mm)
Overall Height 8.08" (205mm)
Enclosure Volume 365 in3
Cut-out Dimensions 9.567" (243mm)
Features
• Easy Installation in Drop Tile or Sheetrock Ceilings Via C-Ring/V-Rail
Tile Bridge and “Dog Leg” Mounting System (Included)
• Front Mounted Tap Selector Switch for Easy System Tuning
Adjustments Include Transformer Bypass Setting for 8 Direct Ω
Coupled Operation
• Unique Input Section Allows for Conduit Runs with Flex Conduit
• 4 Pole Detachable “Phoenix” Style Connector Allows Easy Pre-Wiring
and Is Convenient for Daisy Chaining Additional Strategy Series Full
Range Speakers or Subwoofers
• Low Profile, Magnetically Attaching Grille with Seismic Security Tabs
• Enhanced Quality 70.7V / 100V Internal Transformers Minimize
Insertion Loss and Maintain Low Frequency Response While
Providing Increased Output for Higher SPL Applications
• Safety Listed to UL 1480
Applications
Atlas Sound’s FAP6260T combines superior coaxial loudspeaker
performance with even dispersion and easy installation. A low profile
enclosure and 60° coverage make the FAP6260T a perfect choice for
high ceilings. The FAP6260T will satisfy the needs of owners, architects,
contractors, and consultants by delivering true, high fidelity sound
reproduction in an attractive and easy-to-install system. The FAP6260T
is ideal for high-intelligibility voice, music, and signal reproduction in
commercial, industrial, and institutional applications.
General Description
The loudspeaker component matches the performance of the legen-
dary Atlas Sound FA136 driver. This high-quality construction 6" coaxial
cone type driver includes a 1" voice coil and composite cone with a
butyl rubber surround. The silk dome tweeter is 20mm and utilizes 2
Neodymium magnets. A high sensitivity of 92dB average means less
power may be required to achieve the desired SPL. This loudspeaker
is factory assembled in an optimally tuned and ported deep drawn
enclosure and includes a specially designed 60 watt low saturation 70.7V
/ 100V transformer. A convenient front mounted selector switch allows
tap selection without the need to remove the speaker from the ceiling.
This switch also includes a transformer bypass setting for 8Ω direct
coupled operation.
FAP6260T
FAP6260T
AtlasSound.com 2/4
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
©2013 Atlas Sound L.P. All rights reserved. Atlas Sound and Strategy Series are trademarks of Atlas Sound L.P. All other trademarks are the property of their respective owners. ATS004633 RevB 7/13
Mounting Accessories
Mounting is simplified with Strategy Series ® style “Dog Leg” tabs that
allow easy installation into drop tile or drywall ceilings with provided tile
bridge assembly. The tile bridge consists of two “V” shaped formed
mounting rails and a C-Ring assembly. The C-Ring can be attached to
the rails with the screws provided to extend support to the T-bar grid
in suspended ceiling applications. Multiple hole locations are provided
to allow the C-Ring to be positioned to the outer edge of the tile if
necessary.
For existing dry-wall applications the tile bridge C-Ring and support rails
can be inserted into the hole cut for the FAP6260T. For easy positioning
the “V” shaped support rails match the shape of the C-Ring tabs for
easy maneuvering and location when working “blindly" above the deck. A
uniquely designed “easy access" input panel on the back of the enclosure
allows for conduit runs. Below this cover resides a detachable Phoenix
/ Euro style locking four-pole connector, which provides for easy daisy
chain wiring to other full range 70.7V/100V loudspeakers or Atlas Sound
FAPSUB-1 subwoofers. The package includes a low profile magnetically
attaching grille with seismic security tabs, which nicely matches
contemporary architecture.
A support ring is also provided on the top of the FAP6260T enclosure to
facilitate an auxiliary support cable.
NOTE: IT IS MANDATORY THAT THIS SECONDARY SUPPORT
BE UTILIZED IN DROP CEILINGS FOR SAFETY AND SEISMIC
CONSIDERATIONS.
Architect & Engineer Specifications
The loudspeaker system shall be Atlas Sound FAP6260T. System shall
include a high performance 6" coaxial loudspeaker, ported bass reflex
enclosure and press-fit grille for conventional ceiling installation.
Frequency response for the system shall be 63Hz – 20kHz (±7dB).
Sensitivity shall be 92dB average.
Loudspeaker shall be comprised of a 6" coaxial cone type driver. Cone
shall be constructed of composite cone with a butyl rubber surround.
The tweeter is a 20mm Coaxial Horn-Loaded Silk dome. Magnet shall
be a minimum of 20 oz (567 g) and the voice coil diameter shall be 1" (25
mm).
Transformer shall be a 70.7V / 100V type with 3.8, 7.5, 15, 30, and 60
watt primary taps (@70.7V) with a front mounted tap selector switch to
include transformer bypass setting for 8Ω direct coupled operation.
Enclosure shall be a deep drawn steel enclosure design. Internal volume
shall be 365 in3. To facilitate connection in conduit systems, enclosure
shall be equipped with an access panel covering a recessed terminal cup.
This cover shall provide a top access compression fitting / strain relief
to facilitate flexible conduit up to 22mm outside diameter or 1" (25mm
inside diameter) conduit when the compression fitting is removed.
External wiring shall be accomplished via a removable wiring connector
with screw-down terminals to provide both secure wire termination and
pre-wiring capability before loudspeaker installation. The 4 pole connector
shall facilitate in/out connections and shall be located in the recessed
area behind the conduit access panel.
Seismic support eye shall be provided on top of enclosure for additional
suspension point when used in drop tile ceilings. Construction of
enclosure shall be a minimum of 18-gauge deep drawn galvanized metal.
The system shall include a support backing plate to reinforce the
ceiling material and tile support rails for use on either 2' x 4' (609mm
x 1219mm) or 2' x 2' (609mm x 609mm) suspended ceiling tiles. This
assembly can all be installed from beneath the ceiling tile.
Overall front face diameter shall not exceed 11" (279mm); overall depth
from the bottom of the ceiling shall not exceed 7.83" (199mm).
Grilles shall be magnetically attaching, with seismic security tabs,
manufactured from 24-gauge perforated steel mesh and finished in white
epoxy. Round grill shall be 10.972" (279mm) diameter.
The loudspeaker shall be the Atlas Sound FAP6260T.
C-Ring / V-Rails
