Side 1/1

Ceiling Material up to 2"

Tile Bridge

Auxiliary Suspension intPo

Dogleg In Inverted sitionPo

FAP62T-UL2043

Installation Instructions

ATS003129 RevA 5/08

FAP62T-UL2043

Installation Instructions

Mounting Template

11" Diameter

The Atlas Sound Strategy Series

II assembly mounts easily into existing

construction drop ceiling or drywall materials.

Painting Shield

⁄2" Diameter

Drop Tile Ceiling

Installation

1. Remove 2' 2' or 2' 4' tile. x x

2. Align adjustable dual rail -ring assembly on rear of tile in desired position.& C

3. Using template provided mark cut out circle with marker and cut hole. the ,

(11" FAP62T-UL2043)

4. Affix -ring assembly to rails using screws provided and position assembly on rear of ceiling tile. C

Replace tile into grid. Be sure formed ends of tile bridge rails engage T-bar tile support rails.

5. Bring service loop from rear of tile, through tile bridge C-ring to access panel located on side of enclosure. the / the

Terminate the service loop to Phoenix style connector provided (please note polarity).

Combination knockouts are provided to facilitate conduit.

6. Insert enclosure through front of tile. Using standard #2 Phillips screwdriver or screw-gun, tighten four dogleg assemblies

until they engage C-ring assembly. the DO NOT OVER-TIGHTEN DOGLEG SCREWS!

7. Adjust front mounted switch to desired wattage tap setting or 8 Ω* (See important note regarding 8 operation) Ω

8. Install press-fit grille into front bezel ring. Push baffle upwards until is flush with bezel ring.it the

9. For safety and seismic considerations a suspension ring is integrated into input panel section of unit. the

Atlas Sound strongly suggests that a support wire be installed from this support point to a suitable anchor point above ceiling grid.

In drop tile applications, this wire can usually be installed from an adjacent tile access near speaker location.

Dry Wall ("Hard Deck") Installation

1. Using the FAP62T-UL2043template provided, mark cut out circle in desired mounting location and cut hole. (11" )

2. Place tile bridge rails and C-ring through hole. Use V shaped edge of C-ring to align tile bridge assembly above ceiling-

(alignment screws provided are not required for this type of installation)

3. Bring service loop from rear of tile, through the tile bridge / C-ring to access panel located on side of the enclosure. Terminate service loop to Phoenix style the

connector provided (please note polarity). Combination knockouts are provided to facilitate conduit.

4. Insert enclosure into hole. Using standard #2 Phillips screwdriver or screw-gun, tighten four dogleg assemblies until they engage the C-ring assembly.

DO NOT OVER-TIGHTEN DOGLEG SCREWS!

5. Adjust front mounted switch to desired wattage tap setting or 8 Ω* (See important note regarding 8 operation) Ω

6. Install press-fit grille into front bezel ring. Push baffle upwards until is flush with bezel ring.it the

New Construction (Drywall Ceilings)

Use of optional FAP62-TR

(for use with FAP62T-UL2043 a ) new construction bracket essentially reserves speaker mounting location prior to drywall installation

in new construction. Bracket mounts between 16" or 24" OC studs and includes a

⁄ "8 downward lip to provide a template for drywall installers to cut

around. For final installation, please follow these instructions:

Note: Tile bridge components are not used in new construction applications where new construction bracket is utilized.

1. Bring service loop through hole in ceiling provided by pre construction bracket to access panel located on side of the enclosure- . Terminate service

loop to Phoenix style connector provided (please note polarity). Combination knockouts are provided to facilitate conduit.

2. Insert speaker assembly into hole. Using standard #2 Phillips screwdriver or screw-gun, tighten four the dogleg assemblies until they engage ring provided

on the new construction bracket. DO NOT OVER-TIGHTEN DOGLEG SCREWS!
