I128SYS

IP Compliant Loudspeaker System

Features

• IPSpeakersFromAtlasSoundAllowUsersorSystemAdministrators

toSendLive,Prerecorded,orAdHocMessagesAlongwithControl

DatatoSpeakerEndPointsOverNeworExistingMulticastEnabled

LocalAreaNetworks.

• AlsoCompatiblewithSIP(SessionInitiationProtocol)VoIPSystems.

ContactAtlasSoundforSIPConfigurationInfo.

• HighlyEfficient10ozDualConeLoudspeakerSystemProvides94dB

AverageSPL@1W/1MandIsCapableof103dB@1MeterViathe

RatedPoweroftheInternalIPAddressableAmplifier

• 105˚Dispersioninthe2kHzOctaveBand(-6dB)

• WideFrequencyResponseof86Hz–8kHz(±5dB)IsPerfectfor

SpeechandGeneralMessagingPlayback

• EasytoInstall1'x2'“DropIn”design

General Description

ModelI128SYSfromAtlasSoundconsistsofafactoryassembled

loudspeaker,baffle,andPCBamplifier/controlboardsecurelymounted

totherearofthebaffleviaconcealedweldstuds.Theamplifier/control

boardiscapableofproducing9WattsRMSintothe8 loudspeakerΩ

with9VDCminimumpowerprovidedbyAFcompliantPOEswitches.

Local12VDC–18VDCPSUsmayalsobeusedinsteadofPOEswitches.

InterconnectionisviaaboardmountedfemaleRJ-45connector.The

industrystandardC10AloudspeakerusedintheI128SYSisadualcone

8”(205mm)loudspeakerwitha10oz(260g)ceramicmagnet.Itincludes

acurvelinearpaperconeforlowerharmonicdistortion.Theloudspeaker

isalsoequippedwithafull1”(25mm)diametercoppervoicecoilwith

aluminumformerforbetterheatdissipation.The18-gaugeconstruction

ofthemetalbaffleprovidessecurityanddurabilityincommercial

applications.Aperforated22-gaugemetalscreenisprovidedover

theloudspeakertomaximizeperformancebyallowingtheoptimum

percentageofopenareaforwardoftheloudspeaker.Thebaffleis

finishedinneutralwhiteelectrostaticpowdercoat.

Loudspeaker Speciﬁcations

SpeakerSize 8"(203mm)

PowerHandling 15Watts

Sensitivity(SPL@1W/1M) 94dB

FrequencyResponse1 86Hz–8kHz(±5dB)

Dispersion2 105˚

ConeMaterial TreatedPaper

SurroundMaterial&Dampening Polymerdampenedintegralpaper

surround.

FluxDensity 10,600Gauss,1.06Tesla

MagnetWeight Nominal,10oz(260g)

BasketMaterial Stamped,Plated20-gaugeCRS

VoiceCoilDiameter 1"(25mm)

VoiceCoilMaterial Copper

VoiceCoilFormerMaterial BlackAnodizedAluminum

VoiceCoilWindingWidth 0.225"(6mm)

TopPlateThickness .239"(6mm)

Weight 32oz(908g)

Diameter 8.125(206mm)

Depth 2.875"(73mm)

MountingDimensions 7.625"(194mm)BoltCircle

1. Measured in recommended enclosure

2. 6dB down point, 2kHz octave band

Bafﬂe Speciﬁcations

BaffleMaterial 18-gaugeCRS

SpeakerGrilleMaterial 22-gaugePerforatedSteel

OverallWidth 11.94"(303mm)

OverallHeight 23.67"(601mm)

Depth  4.89"(124mm) (Front of Baffle to Rear of Enclosure)

Color White

Ampliﬁer / Control Speciﬁcations

PowerRating 9WattsRMSintoan8 Loadwith9VDCInputΩ

Inputs RJ-45FemaleonPCBAccessiblefromRearof

Speaker

Outputs 2WireMain±TerminatedtoLoudspeaker

PowerSource IEEE802.3afCompliantPOENetworkSwitchesor

Local12VDC-18VDCPSU

Dimensions 4.25"(108mm)x7.25"(184mm)

Mounting ViaCustomDesignedCRSBracket

NetworkControl MulticastEnabledNetworks

I128SYS

AtlasSound.com 2/2

1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: (800) 876-3333

FAX (800) 765-3435

Applications

TheperfectchoiceforEducation,Military/Government,andLargeScale

Corporateapplications.Itprovidesthecapabilitytosimultaneouslysend

amulticastaudiostreamandtextmessagestoanycombinationofIP

phones,AtlasSoundIPspeakers,andPCs.Withthepushofasingle

buttononthephoneorasingleclickfromaPC,ausercansendalive,

recorded,orscheduledbroadcasttooneormorepaginggroups.With

IPcompliantloudspeakerproductsfromAtlasSound,systemdesigners

andintegratorswillhavetheabilitytodeployextremelylargescale

andcomplexpagingsystemsoverneworexistingnetworkswiththe

convenienceofcentralizedadministrationbyITpersonnel.

Extremecostsavingscanalsoberealizedfromtheeliminationof

separate“standalone”paging&clock/bellsystemswhenControlKom

™



isutilizedineducationapplicationsinconjunctionwiththemodel

I128SYSspeakersystem.

Architect & Engineer Speciﬁcations

UnitshallbeAtlasSoundModelI128SYS.Theloudspeakersystemshall

includefactoryassembledloudspeaker,IPaddressablePCBamplifier/

control,metalbaffle,andenclosure.Theloudspeakershallhavea10oz

(260g)ceramicmagnetandaseamlesscone.Frequencyresponserange

shallbe86Hz–8kHz(-5dB).Sensitivityshallbe94dBaverage.Voicecoil

formershallbeblackanodizedaluminumtohelpdissipateheat,havean

impedanceof8 andadiameterof1"(25mm).TheIPaddressablePCBΩ

amplifier/controlshallbemountedtotherearoftheloudspeakerbaffle

viacustomdesignedCRSbracket..Theamplifier/controlPCBshallbe

capableofproducing9WattsRMSwithaminimumof9VDCpower

providedeitherlocallyorviaIEEE802.3afcompliantPOEswitches.

InterconnectshallbeviafemaleRJ-45connectormountedtothePCB.

AllcontrolfunctionalityofthePCBamplifiershallbedeterminedvia

software.Themetalloudspeakerbaffleoveralldimensionsshallbe11.94"

(303mm)wideby23.67"(601mm)tall.Enclosureshallbeincluded.Finish

shallbeAtlasSoundneutralwhiteelectrostaticpowdercoat.
