1. Menu function
After powering on, press the menu button, and the menu function table will appear
in sequence; the UP or DOWN button to modify the function parameters, the ENTER
button to save the current functions and parameters (with power-off memory after
saving).
Menu function table:
2. Master-slave control
Two or more identical lamps are connected with DMX three-core signal line, the
lamps are set to any address code A001~A512, any one is set as the master, and the
other lamps are the slaves, all the slaves’ displays do not flicker; use the master to
fade, Pulse change, jump change, voice control, and self-propelled effects, all slaves
will synchronize gradual change, pulse change, jump, voice control, and
self-propelled effects.
Special attention:
1. Only one host can be set for a group of lamps. If there is more than one host, all
lamps will flash randomly and out of sync.
2. All lamps and lanterns must be the master and slave when the DMX512 console is
turned off.
3. Factory setting
When any address code is A001~A512, press the menu button for 3 seconds to enter
the factory setting. Factory settings are mainly the functions of each output power of
the lamp, fan setting mode, setting temperature protection point, and sending
parameters. Any mode in the factory setting can be excited by pressing the menu
button for 3 seconds.
A001
Modify the address code (A001~A512) UP or DOWN, and save with the ENTER
key. The default is A001.
Switch between CH03, CH09, CH24 three channels UP or DOWN, ENTER key to
save, default CH09.
Gradient, modify the gradual speed UP or DOWN (FF00~FF99), confirm to save,
the default is FF10.
Pulse change, modify the pulse change speed UP or DOWN (EE00~EE99),
confirm to save, default EE10.
There are 242 kinds of built-in effects (P000~P241), switch the built-in effects ,
save by the ENTER key, and jump to P000 by default.
Modify the operating speed of the built-in effect (S000~S255) UP or DOWN, and
save with the ENTER key. The default is S010.
Soud
Sound control mod
R255
Modify the brightness of the red lamp bead UP or DOWN (R000~R255), and save
with the ENTER key. The default is R255.
Modify the brightness of the green lamp bead UP or DOWN (G000~G255),
confirm to save, and the default is G255.
Modify the brightness of the blue lamp bead UP or DOWN (B000~B255), confirm
to save, and the default is B255.
Display temperature. For example, T045 means that the current lamp
temperature is 45℃; if 10K thermistor is not installed, T000 is displayed.
