Side 1/8

INSTALLATION INSTRUCTIONS FOR PART AFSI-01

REV. 11/14/2013 INSTAFSI-01

CAUTION. Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE. Refer to the instructions included with the

aftermarket radio.

• Provides accessory (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems

• For standard sound systems with stand-alone subwoofer,

use part number 70-5522 along with the AFSI-01

• For SONY/THX amplified systems, use part numbers AX-ADBOX2 and AX-ADFD01

• Provides NAV outputs (parking brake, reverse, mute, V.S.S.)

• OE Bluetooth retention

• Retains SYNC

• Adjustable gain control for SYNC

• High level speaker input

• Micro “B” USB updatable

KIT FEATURES

• Cutting tool • Crimping tool • Tape • Connectors

(example butt-connectors, bell caps, etc.)

TOOLS REQUIRED

Ford SYNC retention

interface 2008-up

APPLICATIONS

See inside front cover

• AFSI-01 Interface • AXXESS 16-pin harness with

stripped leads • AXXESS 22-pin to Ford 24-pin and

16-pin harness • LCD screen

INTERFACE COMPONENTS

AFSI-01

Applications

FORD

Econoline 2010-up

Edge 2008-2010

Escape 2009-2012

Expedition 2009-up

Explorer 2008-2010

Explorer Sport Trac 2008-2010

F-250/350/450/550 2009-up

Flex 2008-2012

Fusion 2008-2012

Taurus 2008-2009

Taurus X 2008-2009

LINCOLN

MKX 2008-2010

MKZ 2008-2009

MERCURY

Milan 2008-2011

Mountaineer 2008-2010

Sable 2008-2009

From the AXXESS 16-pin harness

• Connect the wires to the ignition/accessory wire of the aftermarket radio.Red

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange/White

aftermarket radio does not have an illumination wire, tape off the wire.Orange/White

• Connect the wire to the amp turn on wire of the aftermarket radio (note, wire Blue/White

must be connected even if there isn’t an amp in the vehicle).

• Connect the wire to the mute wire of the aftermarket radio. If the aftermarket radio Brown

does not have a Mute wire, tape up the wire (note, if the mute wire is not connected Brown

the radio will turn off when OnStar is active).

• Connect the wire to the left front positive speaker output of the aftermarket radioWhite

• Connect the wire to the left front negative speaker output of the aftermarket radio.White/Black

• Connect the wire to the right front positive speaker output of the aftermarket radio.Gray

• Connect the wire to the right front negative speaker output of the aftermarket radio.Gray/Black

Tape up the following wires as they will not be used in this application:

Installing the Interface

• wireGreen

• wireGreen/Black

• wirePurple

• wirePurple/Black
