AXDIS-HK4
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-HK4
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter
• Zip ties • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections ........................................................ 2-3
Installation .............................................................4
Programming .........................................................5
Audio Level Adjustment .......................................6
Steering Wheel Control Settings (SWC)
LED Feedback .......................................................7
Changing Radio Type ..........................................8
Remapping the SWC Buttons .............................9
Dual Assignment (Long Button Press) ............. 10
Troubleshooting.................................................... 11
Hyundai/Kia Data Interface with SWC 2010-2013
APPLICATIONS
• Designed for amplified models
• Provides NAV outputs (park brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Retains balance
• Micro-B USB updatable
Hyundai
Tucson * ............................. 2010-2013
Kia
Sorento* .............................2011-2013
• AXDIS-HK4 interface • AXDIS-HK4 harness
• AXSP-HK interface • 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
* With NAV
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter
your Year, Make, Model
vehicle into the vehicle fit
guide and look for the Dash
Kit Installation Instructions.
Product Info
www.MetraOnline.com
