AXLOC-80A
AXLOC-80A
AXLOC-80A
AXLOC-80A
AXLOC-80A
AXLOC-80A
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
REV. 12/17/19
REV. 12/17/19
REV. 12/17/19
REV. 12/17/19
REV. 12/17/19
REV. 12/17/19
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Integrate • AxxessInterfaces.com
Integrate • AxxessInterfaces.com
Integrate • AxxessInterfaces.com
Integrate • AxxessInterfaces.com
Integrate • AxxessInterfaces.com
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Wire Color & Function: The audio and power input wire colors are an EIA standard for
car stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXLOC-80A. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
Adjusting the AXLOC-80A for maximum performance:
After completing all of the necessary connections, turn the AXLOC-80A adjustment pots all of the
way down by rotating them completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select
one of the adjustment pots on the AXLOC-80A and turn it slowly clockwise until you notice audio
distortion and then stop. Turn the remaining pot to the same position as the previously adjusted
pot. The audio set-up of the AXLOC-80A is now complete and ready to be enjoyed.
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
INPUT HARNESS
White = LEFT Front (+) Input
White/Black = LEFT Front (-) Input
Black = Reference Ground (-)
(Reference ground optional if noise is present)
Gray = RIGHT Front (+) Input
Gray/Black = RIGHT Front (-) Input
