INSTALLATION INSTRUCTIONS FOR PART GMOS-044

METRA. The World’s best kits.™ metraonline.com1-800-221-0932

REV. 7/16/2014 INSTGMOS-044

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

• Providesaccessory(12-volt10-amp)

• RetainsR.A.P.(retainedaccessorypower)

• Usedinamplifiedornon-amplifiedsystems

• Retainschimes

• ProvidesNAVoutputs(parkingbrake,reverse,mute,andV.S.S.)

• PrewiredASWC-1harnessincluded(ASWC-1notincluded)

• RetainsOnStar/OEBluetooth

• AdjustablevolumeforchimesandOnStar

• Highlevelspeakerinput

• USBupdatable

• Retainsbalanceandfade

FEATURES

•Cuttingtool•Crimpingtool•Tape•Connectors

(example:butt-connectors,bellcaps,etc.)

TOOLS REQUIRED

GM amplified/non-amplified

OnStar LAN data bus interface

2010-up

GMOS-044

•GMOS-044interface•GMOS-044harness

INTERFACE COMPONENTS

Applications

BUICK

Allure 2010

Regal 2011-2012

CHEVY

Cruze

(with monochrome screen) 2011-up

GMOS-044

From the 16-pin harness to the aftermarket radio:

• ConnecttheRedwiretotheignition/accessorywire.

• ConnecttheOrange/White wiretotheilluminationwire.Iftheaftermarket

radiohasnoilluminationwirejusttapeofftheOrange/Whitewire.

• ConnecttheBlue/Whitewiretotheampturnonwire.

• ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.

• ConnecttheWhite/Blackwiretotheleftfrontnegativespeakeroutput.

• Connectthe Graywiretotherightfrontpositivespeakeroutput.

• ConnecttheGray/Blackwiretotherightfrontnegativespeakeroutput.

• ConnecttheBrown wiretothemutewire.Iftheaftermarketradiodoesnot

haveaMutewire,tapeuptheBrownwire.

Thefollowingwiresareforaftermarketmultimedia/navigationradiosthatprovide

thesewires(ifnottapethemoffanddisregardthem):

• ConnectthelightGreenwiretotheparkingbrakewireoftheaftermarket

navigationradio.

• ConnecttheBlue/PinkwiretotheVSSorspeedsensewireoftheaftermarket

navigationradio.

• ConnecttheGreen/Purplewiretothereversewireoftheaftermarket

navigationradio.

• Plugthe16-pinharnessintotheGMOS-044.

From the 18-pin harness to the aftermarket radio:

• ConnecttheBlack wirewiththeringterminaltotheradiochassiswithISO

screwthatissuppliedwithradio.

Note: This wire must be connected as instructed otherwise the interface

will not be functional.

• TheBlack/Yellowwireandadditional12-pinharnesswillbediscussedlater

inthismanual.

• Plugthe18-pinharnessintotheGMOS-044.

From the 44-pin harness to the aftermarket radio:

• ConnecttheYellowwiretothe12-voltconstant/batterywireofthe

aftermarketradio.

• ConnecttheBlackwiretothegroundwire.

• Connectthe Greenwiretotheleftrearpositivespeakeroutput.

Connections to be made
