www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166

Bakers Pride

C-RS series charbroilers feature a standard-

profile design and 15,000 BTU burners for energy

efficiency and broiling performance. Models come in

a range of sizes from 24" to 72" wide. Stainless steel

radiants come standard, as do steel floating rod grates,

which may be adjusted in four separate titling positions

for increased flexibility and temperature control.

A continuously lit, cross-over pilot tube system makes

lighting burners quick and easy. Fully insulated, double

walls help with heat retention, while stainless steel

interior and exterior construction makes this charbroiler

both durable and easy to clean.

This series also offers many options to suit your needs,

such as log holders or Glo-Stones for enhanced flavor

and work decks for added convenience.

• C-RS Radiant - V-shaped radiant

for each burner

• C-RS Glo-Stones - Ceramic coal

screen

• Burners are controlled with a single

valve

• Natural gas or liquid propane

• Steel floating rod grates

(standard) or cast-iron or meat

grates

• Continuously lit crossover pilot

tube

• Double-walled, fully insulated

construction

• Stainless steel exterior, interior,

and combustion chamber

• Stainless steel radiants

• 3/4” NPT rear gas connection

• Towel bar

• One-year limited warranty

FEATURES AT A GLANCE

• Cast-iron radiants

• Glo-Stones

• Natural woodsmoke essence box

• Cut-outs in 10” work deck

• Gas connector hose

• Stainless steel splash guard

• Overhead back shelves

• Warming rack

• 10" work deck

• Stand with casters

• High output burners

OPTIONS & ACCESSORIES

SERIES: C-RS

DANTE SERIES STANDARD-PROFILE COUNTERTOP CHARBROILERS

www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166

MECHANICAL SPECIFICATIONS

Model

No.

BTU

STANDARD/

HIGH OUTPUT

STANDARD/

HIGH OUTPUT

# Grids

# Burners

Broiling Area

in² (cm²)

Counter Space

(W x D)

Cubic

Feet

Ship Wt.

C-24RS

60,000/

80,000

17.6/

23.4

1 4

513 in²

(3,314 cm²)

24" x 35.5"

(610mm x 902mm)

21.6 ft³

(0.6m³)

412 lbs.

(186.9kg)

C-36RS

105,000/

140,000

30.8/

41.0

1 7

810 in²

(5,233 cm²)

36" x 35.5”

(915mm x 902mm)

21.6 ft³

(0.6m³)

601 lbs

(272.6kg)

C-48RS

150,000/

200,000

44.0/

58.6

2 10

1,107 in²

(7,145 cm²)

48" x 35.5”

(1,219mm x 902mm)

35.9 ft³

(1.0m³)

668 lbs.

(303kg)

C-60RS

195,000/

260,000

57.2/

76.2

3 13

1,404 in²

(9,063 cm²)

60" x 35.5”

(1,524mm x 902mm)

35.9 ft³

(1.0m³)

912 lbs.

(413.7kg)

C-72RS

240,000/

320,000

70.0/

94.1

3 16

1,704 in²

(11,001 cm²)

72" x 35.5”

(1,829mm x 902mm)

43.1 ft³

(1.2m³)

1,078 lbs.

(489kg)

*Height includes 4" adjustable (102 mm) legs.

EQUIPMENT DIMENSIONS

REQUIRED CLEARANCES

Non-Combustible

Left 0" (0 mm)

Right 0” (0 mm)

Back 0” (0 mm)

GAS CONNECTIONS

Natural or LP gas

3/4" NPT on Standard Units

1/2” NPT on Safety Piolt Units

SERIES: C-RS

DANTE SERIES STANDARD-PROFILE COUNTERTOP CHARBROILERS

Freight Class: 70

FOB: Smithville 37166

Bakers Pride reserves the right to modify specifications or discontinue

models without incurring obligation. Dimensions nominal.

2M-Z24096 • REV E • (12-21)

SK2997
