RVP565 DAC Preamplier

Connection guide

What's in the box?

1 - Made in USA RVP565

1 - 15V power supply PN PS27s

1 - Remote control

1 - This owners manual

Bellari

Salt Lake City, UT

8/24

Thank you for purchasing the Bellari RVP565. We

spent a considerable amount of time designing and

developing the RVP565. We hope you enjoy using the

RVP565, and that it makes listening to your music col-

lection rewarding. We sincerely appreciate the oppor-

tunity to build a product for you and participate in your

love of quality music and sound. We love what we do

and we’re happy to help. All Bellari products are hand

built in Salt Lake City, Utah by people who care about

high quality music.

SPECIFICATIONS

Input Impedance: 10K ohms

Max Output Gain: 6.63 dB

THD: 0.1%

S/N Ratio: 103 dB, un-weighted

Frequency Response: 20 Hz - 20 KHz

Crosstalk: -75 dB

Output impedance: 100 Ohms

Output Connector: RCA Stereo

Input Connectors: 1: 1/8" TRS Stereo jack

2: RCA Stereo jacks

1: Optical input

1: COAX Digital input

PWR: 15 VDC, 500 mA;

Part number PS27s

Size: 5.5"w x 1.5"h x 3.5"d

Weight: .95 lb.

COAX Digital input. Active when

selector switch is in DAC setting.

RCA Stereo output

for connection to your

preamplier, amplier or

other device.

Volume control will adjust the

level of RCA output.

Pushing the knob in will activate

muting of the output signal.

DC jack for

connection to

the included

power supply

Digital Optical

input. Active when

selector switch is

in DAC setting.

INPUT

OUTPUT

15 VDC

RVP565

bellariaudio.com

OPTICAL IN

COAX IN

2 3

Dac Preamp

RPV565

MADE IN USA

DAC

IN 4

Level

Volume

OFF/ON

IN 4 on the front is a

3.5mm (1/8") stereo

input. It is a great way

to plug your phone

into your system with-

out needing access to

the back of the unit.

Channel 2 and 3

inputs. Active when

selector switch is

in 2 or 3 setting.

Selector switch

for channel output

selection.

IR sensor for

remote.

Level display

Indicates the

output volume

level. Will also

indicate when

unit is muted

either with the

remote or mute

activation with

the front panel

Volume control.

Remote: Requires 2 AAA batteries

(not included)

+ and -

For

volume

control

OFF/ON: For muting

output of unit. Press

once to mute press

again to activate

output.
