SE560 Sonic Exciter
Connection guide
SPECIFICATIONS:
Gain: 19.1 dB gain @ 1kHz
Input Impedance: 1k
Output Impedance: 100 ohms RCA
Frequency Response: 3Hz to 31kHz
THD: .003% @ 1KHz
S/N Ratio: >100 dB unweighted
PWR: 15 VDC
Size: 5.5"w x 3.5"d x 1.25"h
Weight: .8 lbs
Indicator: 1 Power LED
Bellari is a division of Rolls Corporation
Salt Lake City, UT
6/18
INPUT
OUTPUT
15 VDC
Sonic Exciter
+
-
SE560
SE560
MADE IN USA
PWR
Volume
MADE IN USA
Bottom
0
Definition
0
Active
3.5mm in
INPUT
OUTPUT
15 VDC
Sonic Exciter
+
-
SE560
SE560
MADE IN USA
PWR
Volume
MADE IN USA
Bottom
0
Definition
0
Active
3.5mm in
What's in the box?
1 - Made in USA SE560
1 - 15V power supply PN PS27s
1 - This owners manual
1 - Lots of foam to keep all items safe, and scratch free
1 - Love for audio, Decades of experience building and designing
0 - Eorts to change the space time continuum
-Whole system sound enhancement
-Turntable/Phono cartridge enhancer
-Stand alone preamp
REAR PANEL
RCA OUTPUT: For connection to your preamplier, amplier or other device.
RCA INPUT: Source input (phone, tablet, DAC, Phono Pre or other player).
3.5MM IN: 1/8" stereo input
15 VDC: For connection to the included power supply.
FRONT PANEL
VOLUME: Adjusts the level of signal.
ACTIVE: When in the sonic exciter is active. When out the original signal is sent
out.
BOTTOM: Adjusts the lower frequency enhancement.
DEFINITION: Adjusts the higher frequency enhancement.
INPUT
OUTPUT
15 VDC
Sonic Exciter
+
-
SE560
SE560
MADE IN USA
PWR
Volume
MADE IN USA
Bottom
0
Definition
0
Active
3.5mm in
INPUT
OUTPUT
15 VDC
Sonic Exciter
+
-
SE560
SE560
MADE IN USA
PWR
Volume
MADE IN USA
Bottom
0
Definition
0
Active
3.5mm in
INTRODUCTION
The SE560 sonic exciter (sound enhancer), whether you are using it as a phono
enhancer or sending music to your amplier or preamp. At every design stage we
spent a considerable amount of time focused on one thing, sound quality.
OPERATION - CONNECTION
The SE560 can be used in many places for audio improvement.
-It can be used as a stand alone preamplier. With 19.1 dB of gain it has more
output potential than most preamps built. Simply plug you source (phone, tablet,
DAC, Phono Pre or other player) into the SE560 and from there to your amplier.
With it's two inputs, it can act almost like a two channel preamp.
-It can ll the role of a turntable-cartrige only improvement in your system. From
your phono pre (or directly from your turntable if it has a phono pre built in) to the
SE560 then to your preamp or power amp. In this application you can adjust for
DECCA levels (hot mastered records) or standard to low level records with ease
just by using the Volume control.
-It also can act as a whole system enhancer by plugging your preamp into the
SE560 then to your amplier.
Any way you choose, it will sound like you had pillows covering your speakers
before you used the SE560.
Where to set the Bottom and Denition? The simple answer is where ever you
feel your system sounds best. We found that most of our listening time was spent
with the Bottom and Denition controls two to three dots/notches past the "0"
(half way up) indicator, I would suggest starting at that setting.
Thank you for purchasing the Bellari SE560. We spent a considerable
amount of time designing and developing the SE560. We hope you enjoy
using the SE560, and that it makes listening to your music collection
rewarding. We sincerely appreciate the opportunity to build a product
for you and participate in your love of quality music and sound. We love
what we do and we’re happy to help. All Bellari products are hand built
in Salt Lake City, Utah by people who care about high quality music. We
spend most of our paychecks on buying more records or equipment.
