FAN CLEANING

Clean the fan grills, extender screen, and extender panels

with a soft, damp cloth. Please use caution around the

motor housing area. Do not allow the motor or other

electrical components to be exposed to water. Also, using

a soft bristle brush attachment, a vacuum cleaner may be

used to extract dust buildup on the grill areas.

NOTE: Remember to turn your fan to the off position prior

to cleaning.

FAN STORAGE INSTRUCTIONS

Your fan can be stored in the off-season, however it is

important to keep it in a safe, dry location.

• We recommend using the original (or appropriately

sized) box.

• Remember to protect the fan from dust.

5 YEAR LIMITED WARRANTY

Sunbeam Products, Inc. doing business as Jarden

Consumer Solutions or if in Canada, Sunbeam Corporation

(Canada) Limited doing business as Jarden Consumer

Solutions (collectively “JCS”) warrants that for a period of

five years from the date of purchase, this product will be

free from defects in material and workmanship. JCS, at its

option, will repair or replace this product or any component

of the product found to be defective during the warranty

period. Replacement will be made with a new or

remanufactured product or component. If the product is no

longer available, replacement may be made with a similar

product of equal or greater value. This is your exclusive

warranty. Do NOT attempt to repair or adjust any electrical

or mechanical functions on this product. Doing so will void

this warranty.

This warranty is valid for the original retail purchaser from

the date of initial retail purchase and is not transferable.

Keep the original sales receipt. Proof of purchase is

required to obtain warranty performance. JCS dealers,

service centers, or retail stores selling JCS products do not

have the right to alter, modify or any way change the terms

and conditions of this warranty.

This warranty does not cover normal wear of parts or

damage resulting from any of the following: negligent use

or misuse of the product, use on improper voltage or

current, use contrary to the operating instructions,

disassembly, repair or alteration by anyone other than JCS

or an authorized JCS service center. Further, the warranty

does not cover: Acts of God, such as fire, flood,

hurricanes and tornadoes.

What are the limits on JCS’s Liability?

JCS shall not be liable for any incidental or consequential

damages caused by the breach of any express, implied or

statutory warranty or condition.

Except to the extent prohibited by applicable law, any

implied warranty or condition of merchantability or fitness

for a particular purpose is limited in duration to the

duration of the above warranty.

JCS disclaims all other warranties, conditions or

representations, express, implied, statutory or otherwise.

JCS shall not be liable for any damages of any kind

resulting from the purchase, use or misuse of, or inability to

use the product including incidental, special,

consequential or similar damages or loss of profits, or for

any breach of contract, fundamental or otherwise, or for

any claim brought against purchaser by any other party.

Some provinces, states or jurisdictions do not allow the

exclusion or limitation of incidental or consequential

damages or limitations on how long an implied warranty

lasts, so the above limitations or exclusion may not apply

to you.

This warranty gives you specific legal rights, and you may

also have other rights that vary from province to province,

state to state or jurisdiction to jurisdiction.

How to Obtain Warranty Service

In the U.S.A.

If you have any question regarding this warranty or would

like to obtain warranty service, please call 1-800-253-2764

and a convenient service center address will be provided

to you.

In Canada

If you have any question regarding this warranty or would

like to obtain warranty service, please call 1-800-253-2764

and a convenient service center address will be provided

to you.

In the U.S.A., this warranty is offered by Sunbeam

Products, Inc. doing business as Jarden Consumer

Solutions located in Boca Raton, Florida 33431. In

Canada, this warranty is offered by Sunbeam Corporation

(Canada) Limited doing business as Jarden Consumer

Solutions, located at 20B Hereford Street, Brampton,

Ontario L6Y 0M1. If you have any other problem or claim in

connection with this product, please write our Consumer

Service Department.

PLEASE DO NOT RETURN THIS PRODUCT TO ANY

OF THESE ADDRESSES OR TO THE PLACE OF

PURCHASE.

Sunbeam Products, Inc. doing business as Jarden

Consumer Solutions, Boca Raton, Florida 33431.

BW230007EM1 Printed in China

9100010009530

Read instructions before operating.

Retain for future reference.

Instruction Leaflet

INFO-LINE

If after having read this leaflet, you have any

questions or comments on your fan,

call 1-800-253-2764 in North America.

☎

remote control

WINDOW fan

MODEL BW2300

If you have any questions regarding your product or

would like to learn more about other Bionaire

products,

please contact our Consumer Service Department at

1-800-253-2764 or visit our website at

www.bionaire.com

WINDOW FAN ACCESSORIES

Window Fan

Extender Panel

To order please go to www.bionaire.com

or call 1-800-253-2764

Issue

IssueIssue

Potential

Cause

Potential Solution

The air is not

moving in the

direction that I

want it to.

Airflow direction

switches are

not in the

correct position.

Adjust the airflow direction switches to

intake, exhaust, or air exchange.

Fan will not

operate even

though I am

turning on the

fan with the

speed control

knob.

Fan is not

plugged in.

The fan is

plugged in and

is set to the Off

position.

Preset

temperature on

the fan is set

too high.

Plug the cord into a 120V AC outlet.

Turn the fan on using the speed button.

Refer to Manual or Automatic Operating

Instructions.

Set the temperature on the fan so that it is

lower than the room temperature. Refer to

Automatic Operating Instructions.

Fan is not secure

in my window

and moves

during operation.

Fan may not be

set in the

window

properly.

Ensure that the bottom edge of the window

sash fits into the groove along the top of the

fan. Close the sash completely on top of the

window so it is secure. Refer to the Window

Fan Installation section.

My window fan

will not fit

horizontally in the

window.

Fan may need

to be installed

vertically.

Window fans can be installed either vertically

or horizontally. Please note that when

installing vertically, the internal adjustable

extender panel t be located on the top of

the window fan and never on the bottom.

Refer to the Window Fan Installation section.

My window fan

has become

dirty.

Long term on

continued use.

This is normal

when circulating

unfiltered air.

First unplug the fan from the outlet. The

outside of the fan can be wiped down with a

damp cloth. Use a vacuum cleaner with a

dust brush attachment. Refer to the

Cleaning/Maintenance Instructions section.

TROUBLESHOOTING GUIDE

BW2300_07EM1. qxd:BW230006EM1. qxd 11/17/07 8:38 AM Page 1

Step 2: To turn the fan on press the Speed Control Button.

Step 3: Set the speed to high, medium (med) or low by

pressing the Speed Control Button.

Step 4: Set the airflow direction to Exhaust (out), Intake (in)

or exchange (one blade blowing air in and the

second blade blowing air out) by pressing the air

flow button.

Step 5: To turn the fan off press the Speed Control Button

until the fan stops.

AUTOMATIC OPERATING INSTRUCTIONS

Your window fan is equipped with the digital control

thermostat that automatically turns the fan on and off

depending upon the preset comfort level. For example, if

you have set your thermostat to 75 degrees and the room

temperature drops to 74 degrees or lower then the fan will

automatically shut off. The fan will then turn on again when

the room temperature exceeds 75 degrees. In order to

take advantage of this feature, make sure your window fan

is in automatic mode (this will be indicated by a red light on

the left of the control panel).

Step 1: Set the fan to Automatic Mode by pressing the

Mode button located on the Control Panel. The

Auto On light will illuminate when the unit is in

Automatic Mode.

Step 2: Press the Temp Set (+,–) buttons on the front of

the Control Panel or use the remote control to

program the desired temperature or switch to the

manual mode.

Step 3: When you are finished setting the temperature, let

go of the button. The display will blink a few times

and then will return to displaying the current room

temperature.

IMPORTANT: If the unit will not start in automatic mode,

please make sure that the set temperature is below the

current room temperature. If the fan is stopped and you

would like to turn it back on, lower the set temperature or

switch to the manual mode.

REMOTE CONTROL INSTRUCTIONS

Your window fan is equipped with a remote control. This

remote control can be used to adjust the following

functions: Power, Manual/Automatic mode, Air Flow

Direction, Temperature adjustments.

Two “AAA” batteries have been included for your

convenience.

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc),or

rechargeable (nickel-cadmium) batteries.

CLEANING/MAINTENANCE INSTRUCTIONS

Follow these instructions to correctly and safely care for

your fan. Please remember:

• Always unplug the fan before cleaning.

• Do not allow water to drip on or enter into fan housing.

• Be sure to use a soft cloth moistened with a mild soap

solution.

• Do not use gasoline, thinner or benzene as a cleaner.

Step 2: If the fan does not fit snugly to the top and bottom of

the window casing, attach the included extender

panel(s) and pull out the built-in extender screen until

the fan fits safely in your window (See Figure 3).

Step 3: To keep the fan in place, carefully close the

window so that the bottom edge of the window

rests on the flat area on the top of the window fan.

WARNING: Be sure fan is securely installed in your

window at all times. Do not lean or push on fan while it is

in the window.

NOTE: For slider windows, set the fan vertically in your

window opening, with the left side on the bottom.

INSTALLATION GUIDE

The extender panels can be secured to the fan by simply

sliding the extender panels into the grooves located on the

left hand side of the fan.

The extender screen can be adjusted by pulling out the

extender locks located on the top and bottom of the right

side of the fan. Push the locks back into place to secure

the extender screen at the desired length.

For 24 inch to 27 inch (61-69cm): Use up to 3 inch

(7cm) of right side, pull out extender screen.

For 28 inch to 34 inch (71-86cm): Use one 3 inch (7cm)

extender panel on the left side. Adjust the pull out extender

screen on the right side for a tight fit

(from 0.5 inch to 7 inch (1.3-17.8cm) ).

For 35 inch to 37 inch (89-94cm): Use two 3 inch (7cm)

extender panels on the left side. Adjust the pull out

extender screen on the right side for a tight fit

(from 0.5 inch to 7 inch (1.3-17.8cm) ).

Larger than 37 inch (94cm): Additional extender panels

will be required.

MANUAL OPERATING INSTRUCTIONS

NOTE: To operate the fan continuously, make sure that the

auto on light located to the left of the control panel is off.

Step 1: Plug your window fan into any 120V AC electrical

outlet.

NOTE:

NOTE:NOTE: The temperature display will always be on when

the fan is plugged into the electrical outlet.

FAN SAFETY

PLEASE READ AND SAVE

THESE IMPORTANT

SAFEGUARDS

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and injury to persons, including the following:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance

directly into a 120 V AC electrical outlet.

3. Keep the cord out of heavy traffic areas. DO NOT let

the cord hang over the edge of a table or counter. To

avoid fire hazard, NEVER put the cord under rugs,

near heat registers, radiators, stoves, or heaters.

4. To protect against electrical hazards, DO NOT

immerse in water or other liquids. Do not use near

water.

5. Close supervision is necessary when any appliance is

used by or near children or disabled people.

6. Always unplug the fan before moving it, putting on or

taking off parts, cleaning, or whenever the fan is not in

use. Be sure to pull by the plug and not the cord.

7. Avoid contact with moving parts. DO NOT operate

without fan grills properly in place.

8. DO NOT operate any appliance with a damaged cord

or plug, if motor fan fails to rotate, after the appliance

malfunctions, or if it has been dropped or damaged in

any manner. Return appliance to manufacturer for

examination, electrical or mechanical adjustment, or

repair.

9. DO NOT operate in the presence of explosive and/or

flammable fumes.

10.Use appliance only for intended household use as

described in this manual. Any other use not

recommended by the manufacturer may cause fire,

electric shock, or injury to persons. The use of

attachments not recommended or sold by Bionaire

may cause hazards.

11.DO NOT use outdoors.

12.Always use on a dry, level surface.

13.Keep unit away from heated surfaces and open flames.

14.DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit. Doing so will void

your warranty. The inside of the unit contains no user

serviceable parts. All servicing should be performed

by qualified personnel only.

PLEASE SAVE THESE

INSTRUCTIONS

CONSUMER SAFETY INFORMATION

THIS APPLIANCE HAS A POLARIZED

AC PLUG (one blade is wider than the

other). To reduce the risk of electric

shock, this plug is intended to fit in a

polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the

plug. If it still does not fit, contact a

qualified electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR

DEFEAT THIS SAFETY FEATURE IN ANY WAY.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

WINDOW FAN INSTALLATION

The window fan has been designed to fit double-hung,

slider and casement windows.

Step 1: Set the fan into your window opening.

INSTALLATION INSTRUCTIONS

Figure 1

PULLS OUT UP TO 7.0 inch (17.8cm)

LEFT

Extra Extender Panels

RIGHT

Built-In, Pull Out Extender Screen

24 inch (61cm) long

FRONT VIEW

Two 3.0 inch (7cm) extenders, (Included in your box packed at both ends)

Figure 3

Figure 2

G. Speed Control Button J. Mode Button

H. Temp Up Button K. Dimmer Button

I. Air Flow Direction Button L. Temp Down Button

A. Front Grills

B. Extender Screen (not shown)

C. Extender Locks(2)

D. Control Panel

E. LCD Display

F. Remote Control

BW2300_07EM1. qxd:BW230006EM1. qxd 11/17/07 8:38 AM Page 2

Produkt Specifikationer

Mærke:	Bionaire
Kategori:	Ventilator
Model:	BW2300

Har du brug for hjælp?

Hvis du har brug for hjælp til Bionaire BW2300 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ventilator Bionaire Manualer

Bionaire BAC015X Manual

25 August 2025

Bionaire BT16 Manual

25 August 2025

Bionaire BW2300 Manual

5 September 2024

Bionaire BT46R Manual

5 September 2024

Bionaire BT90R Manual

5 September 2024

Bionaire BAOF30G Manual

5 September 2024

Bionaire BAC14-I Manual

5 September 2024

Bionaire BASF1016G Manual

5 September 2024

Bionaire BBLF01 Manual

20 August 2024

Bionaire BMT014D Manual

20 August 2024

Ventilator Manualer

Nyeste Ventilator Manualer

Orbegozo CP 149035 Manual

30 September 2025

Orbegozo CP 128105 Manual

30 September 2025

Orbegozo HF 2100 Manual

30 September 2025

ElectriQ TF29OSCT8RW Manual

30 September 2025

Heller HTFE35WF Manual

30 September 2025

ElectriQ TF44OSCT8RW Manual

30 September 2025

Heller HVF50B Manual

30 September 2025

Heller HHDF30S Manual

30 September 2025

DeepCool FL12 SE Manual

30 September 2025

Heller HMTF40 Manual

30 September 2025
