The ULTIMATEASUB10-B-T-EACH active subwoofer made by Origin

Acoustics delivers exceptional low-end frequency extension for

demanding residential installations.

InIn the

the

thethe Box

Box

BoxBox

1 ULTIMATEASUB10-B-T-EACH

Additional

AdditionalAdditional Items

Items

ItemsItems

6 RCA Cable with 90° Angle Connectors

4 Wall Screws

4 Drywall Anchors

4 Round Rubber Feet

2 Elongated Rubber Feet

1 Wall Mount Plate

Installation

InstallationInstallation

Connections

ConnectionsConnections

NOTE

NOTENOTE: Gently pull away the grille from the surface of the subwoofer,

make the connections and then reattach the grille to the front

surface of the subwoofer. Refer to the section Reattach the Grille

for more information.

Mandatory

MandatoryMandatory Connections

Connections

ConnectionsConnections:

1. Connect the analog unbalanced line level audio connection from the

source to LINE IN RCA connector via RCA cable.

2. Connect the IEC power cable to A/C power.

Optional

OptionalOptional Connections

Connections

ConnectionsConnections:

1. Setthe TRIGGER/AUTO switch to TRIGGER. Then, connect the

TRIGGER input to the +12Vtrigger output of the audio source device.

2. Connect the parallel LINE OUT RCA connector to an additional

subwoofer via RCA cable for an extra bass enhancement.

3. Connect the right-angle USB +5V power connection to the optional

wireless signal extension kit.

ULTIMATE

ULTIMATEULTIMATEASUB10-B-T-EACH

ASUB10-B-T-EACH

ASUB10-B-T-EACHASUB10-B-T-EACH QuickStart

Ultimate

UltimateUltimate 10

1010 in.

in.

in.in. Active

Active

ActiveActive Subwoofer,

Subwoofer,

Subwoofer,Subwoofer, Black

Black

BlackBlack Textured,

Textured,

Textured,Textured, Single

Single

SingleSingle

Attach

AttachAttach the

the

thethe Mounting

Mounting

MountingMounting Feet

Feet

FeetFeet

Follow the procedure to attach either set of the included mounting feet

to the subwoofer:

lIf using the elongated, channeled feet for standing the subwoofer up

vertically:

Route the power cable and the RCA cables each through the channels

on their respective feet. Then press the feet onto the bottom edge of

the subwoofer at their respective silkscreen hashmarks to secure

them in place.

lIf using the four rounded feet to lie the subwoofer on its back surface

horizontally:

Screw the four included posts into each of their respective holes at

each corner of the back surface of the subwoofer. Once all four posts

are screwed into place, cover each post with a rubberfoot.

lIf using the four rounded feet to lie the subwoofer on its front

surface:

Remove the grille from the posts that are already installed and then

cover those posts with the rounded feet.

Wall

WallWall Mount

Mount

MountMount

Follow the procedure to mount the subwoofer to a wall:

1. Hold the included mounting bracket against the wall and use a pencil

to lightly mark the position of the screw holes.

2. Drill holes at the marked screw hole locations and install the four

included drywall anchors.

3. Secure the mounting bracket to the wall using the screws.

4. Screw the four included posts into each of their respective holes at

each corner of the back surface of the subwoofer.

5. Hang the subwoofer on the mounting bracket by fitting the posts

into their respective holes in the bracket.

Reattach

ReattachReattach the

the

thethe Grille

Grille

GrilleGrille

Follow the procedure to reattach the grille to the front surface of the

subwoofer.

1. Place the grille over the front surface of the subwoofer so all the

openings in the columns at each corner of the grille align with their

respective posts.

2. Gently press the grille into place, applying pressure at the corners

over where the posts from the subwoofer will slide into the columns

of the grille. It avoids warping the grille as you push it towards the

subwoofer.

ULTIMATE

ULTIMATEULTIMATEASUB10-B-T-EACH

ASUB10-B-T-EACH

ASUB10-B-T-EACHASUB10-B-T-EACH QuickStart

Ultimate

UltimateUltimate 10

1010 in.

in.

in.in. Active

Active

ActiveActive Subwoofer,

Subwoofer,

Subwoofer,Subwoofer, Black

Black

BlackBlack Textured,

Textured,

Textured,Textured, Single

Single

SingleSingle
