OWNER'S MANUAL

CAR AUDIO SYSTEM

PLEASE READ CAREFULLY BEFORE INSTALLING OR OPERATING THIS UNIT.

CAP-4320

WARNING

Make sure you choose a suitable place to mount the unit. The position should be completely

dry with a good circulation of air, and from a mechanical point of view very stable.

System Planning

Proper system planning is the best way to maximize your amplifier performance. By planning

your installation carefully you can avoid situations where the performance of the reliability of

your system is compromised. Your authorized dealer has been trained to maximize your

system's sonic potential. Your dealer is a valuable resource in helping you with your system

design and installation.

Speaker Requirements

Each channel of your amplifier can easily drive

4Ω speaker loads when used in the stereo

mode. When a channel-pair is bridged, the

recommended minimum load impedance is 3Ω

for subwoofer use, and 4Ω for full range

operation. Although operation with lower

impedances is not likely to cause immediate

damage to the internal circuitry, the unit will

most likely overheat, causing the thermal

protection circuitry to shut down the amplifier.

When the chassis cools down, normal operation

will resume. Continuing to operate the amplifier

under these conditions is not recommended and

will reduce its life expectancy.

Most speakers designed for car audio operation

are 4Ω impedance. Connecting two such

speakers in parallel will result in a 2Ω

impedance load as seen by the amplifier. Some

subwoofer models feature a dual 4Ω voice coil

design. Connecting these voice coils in parallel

will result in a 2Ω nominal impedance, which is

not recommended for use with bridged channels

of your amplifier.

EN EN

8Ω 8Ω

4Ω 4Ω

Series wiring Series wiring

Parallel wiring Parallel wiring

Series/parallel wiring Series/parallel wiring

• 2 •

Produkt Specifikationer

Mærke:	Denver
Kategori:	Modtager
Model:	CAP-4320
Bredde:	280 mm
Dybde:	50 mm
Højde:	170 mm
Produktfarve:	Sort
Pakkedybde:	760 mm
Pakkebredde:	370 mm
Pakkehøjde:	189 mm
Produkter pr. intermodal container (20 fod):	3460 stk
Produkter pr. intermodal container (40 fod, HC):	8400 stk
Husmateriale:	Aluminium
Frekvensområde:	20 - 20000 Hz
Produkter pr. hovedkasse (udvendigt):	4 stk
Signal/støjforhold:	90 dB
Audio RCA-indgange:	2
Antal forstærkerkanaler:	4 kanaler
RMS udgangseffekt pr. kanal (4 Ohm):	240 W
Maks. udgangseffekt (RMS):	1000 W
RMS udgangseffekt pr. kanal (2 ohm):	360 W
Broforbundet udgangseffekt (maks):	360 W
