Side 1/4

Original Instructions

Version 3

May 2024

22230

COMBINED

LIVE WIRE,

METAL & STUD

DETECTOR

User Manual for: Combined Live Wire, Metal &

Stud Detector

Stock No: 22230

Part No: D389

Read this manual in full before using this product and

retain it for future use. Always use the latest version of

the manual. Please visit drapertools.com/manuals for

the latest version.

1. Intended Use

This detector is designed to nd hidden live AC wires,

metal, wooden studs through common wall materials.

Suitable for use indoors and outdoors.

Any other application beyond the conditions established

for use will be considered misuse. Draper Tools accepts

no responsibility for improper use of this product.

This product is suitable for use by enthusiasts and

radespersons alike.

– 2 –

1.1 Specication

2. HealthandSafety

Information

Important: Read all the Health and Safety instructions

before attempting to operate, maintain or repair this

product. Failure to follow these instructions may result in

injury or damage to the user or the product.

• Use this product ONLY as instructed in this manual.

CAUTION! Depending on the proximity of

electrical wiring or pipes to the wall surface, the

sensor may detect them as studs. Always take care

when nailing, cutting or drilling into walls, oors

and ceilings as they may contain these items.

• Always turn o the power when nailing, cutting or

drilling near electrical wires.

CAUTION!

− The unit will not detect live wires inside metal

pipes or conduits, behind metallic wall coverings

or other dense materials. Use extra care in these

situations.

− Items that are shielded in some way or more than

38mm from the surface will not be detected.

• DO NOT use this device if the tester is damaged in any

way or if there is evidence of battery leakage.

• The battery must be replaced with one with the same

specication.

• When replacing the battery check that it is tted in

the correct +/- orientation.

• DO NOT dismantle or attempt to repair this unit.

3. ExplanationofSymbols

Read the

instruction manual

European

conformity

Caution!

UK Conformity

Assessed

Do not incinerate

or throw onto re

WEEE – Waste Electrical & Electronic Equipment

Do not dispose of this product with

domestic waste

4.Identication

Carefully remove the product from the packaging and

examine it for any signs of damage that may have

occurred during shipment. If any part is damaged or

missing, do not attempt to use the product.

Please contact the Draper Helpline; contact details can

be found at the back of this manual.

(1) LCD display screen

(2) Mode switch

(3) ON/OFF button

(4) Battery compartment (back of detector)

Stock No. 22230

Part No. D389

Detection distance:

Stud

19mm

Metal

60mm

AC Voltage

51mm

Power Supply:

1 X 9V/PP3 battery

(not supplied)

Dimensions: L 160 X W 69 X H 31mm

Net Weight: 196g

(4)

(1)

(2)

(3)
