PLATFORM

Stereo Compressor/Limiter

Congratulations on purchasing the Electro-Harmonix Platform Stereo

Compressor/Limiter. The Platform presents you with a versatile and powerful

studio-quality compressor enclosed in a stompbox-sized package. Use the

Platform’s compressor/limiter on any instrument—such as guitar, bass or

keyboards—for precise and powerful control of your signal’s volume. Engage the

Drive and Swell functions to further tailor and enhance your sound. Whether

you’re on stage, in the studio, putting together a podcast or creating your next

YouTube masterpiece, the Platform will help you get the job done.

WARNING: Your Platform comes equipped with an Electro-Harmonix 9.6DC-200BI

power supply (same as used by Boss® & Ibanez®: 9.6 Volts DC 200mA). The Platform

requires 125mA at 9VDC with a center negative plug. Use of the wrong adapter or a plug

with the wrong polarity may damage your Platform and void the warranty.

FEATURES

• High-quality compressor/limiter

• Selectable hard/soft knee function

• 8-segment LED gain reduction meter

• Foot switchable overdrive with volume, tone, and gain controls

• Volum swell function e

• True stereo input and output

• Stereo buffered bypass

NOTES AND SPECIFICATIONS

•  Input impedance for each input: 1M

•  Output impedance for each output: 300

• Current draw: 125mA

• Maximum input signal level: +7.2 dBu

COMPRESSOR/LIMITER CONTROLS & INDICATORS

SUSTAIN Knob

Compressor Mode: Adjusts compression ratio. As you turn the SUSTAIN

knob clockwise, the compression ratio increases This .

ratio

determines how much

compression is applied to a signal once it crosses the threshold.

Threshold

is the

volume level at which the compressor begins working on the signal. In

compressor mode, the Platform’s threshold level is fixed at a constant -35dB.

In practical terms, compression ratio determines how much the compressor

squashes the signal level and thus how much it levels out dynamics. The higher

the ratio, the more it reduces the peaks and valleys in your signal level to yield a

more consistent output volume.

RATIO DIAGRAM

Limiter Mode: SUSTAINThe knob adjusts threshold level. As you turn the

SUSTAIN knob clockwise, the threshold level decreases and forces the limiter to

act sooner on your signal. The compression ratio is constant and practically

infinite in Limiter mode.

ATTACK Knob

The knob sets the amount of time delay before the compressor/limiter ATTACK

is activated once the input signal level reaches or exceeds the threshold setting.

Turn the ATTACK knob clockwise to increase the attack time from fast to slow.

Slow ATTACK settings emphasize the initial attack and add greater pop to your

notes (this is great for guitarists who like to chicken pick or play ). Fast funk

ATTACK settings produce a more even compression where the initial attack is

compressed along with the sustained portion of your notes.
