SOUL PREACHER

Guitar Compressor Effect

Congratulations on your purchase of the Electro-Harmonix Soul Preacher. The Soul Preacher is

a compact compressor/sustainer effect with variable parameters allowing extreme or subtle

adjustments of the dynamic qualities of YOUR playing. Two knobs and one 3 way toggle switch

control the output volume, the depth of the effect and the attack/decay characteristics of the

effect.

The input sensitivity is 50mV to 2 volts, making it a perfect fit to most magnetic guitar pickups

and active/buffered pickups. The preamp does add some distortion and the amount is level

dependent… humbuckers and high output single coil pickups will distort much more than

normal single coil guitar pickups. This distortion can be controlled somewhat from the guitar’s

volume level ahead of the compressor.

The Soul Preacher has a maximum gain reduction of 40dB and a maximum gain of 46 dB. This

allows for maximum sustain with an acceptable noise floor. All compressors have a lot of make-

up gain and will amplify noise. The Soul Preacher has less thanks to a novel circuit.

The standard features allow the Soul Preacher to control the amount of sustain and the

matching volume level, as well as the attack/decay characteristic.

Using Your Soul Preacher

Engaging the footswitch inserts the effect. A red status LED illuminates. Adjust the “SUSTAIN”

knob for the desired amount of the effect. Adjust the “VOL” knob to cut, match, or boost the

outgoing signal to the incoming signa l. Selecting “fast”, “med”, or “slow” with the “ATTACK”

toggle switch changes the timing of the onset of compression.

The “fast” setting of the “ATTACK” switch, will squash the entire signal. This setting will also

add a little more distortion. This setting is nice with the “SUSTAIN” cranked all the way, but

there are many useful variations in between. “med” will not catch the leading edge of the

transient so the result will be a brighter more percussive attack. the transition has a soft

“bump” in it, that is super groovy. This is the most versatile setting. “slow” misses the edge

completely, and then squashes down with a bumpy funky squeeze. Perfect for funk chord

comp or chunky rhythm playing… try reducing the “sustain” to half, at first, for this effect.

Adjust the volume level to match the incoming signal level.

- CONTROLS -

Status LED –

When the effect is engaged this red LED will illuminate. While the Soul Preacher

is in True Bypass, the Status LED will be off. Press the footswitch to toggle between effect and

true bypass mode.

When the

power is applied, the Status LED should glow brightly signaling

all operational voltages are satisfactory.

VOL –

use to adjust the amount of make-up gain.

SUSTAIN –

use to set the amount of compression

ATTACK–

sets the timing of the attack / decay

-POWER-

Power from the internal 9-volt battery is activated by plugging into the INPUT jack. The input

cable should be removed when the unit is not in use to avoid running down the battery. If a

battery eliminator is used, the Soul Preacher will be powered up as long as a wall-wart is

plugged into the wall.

Please make sure to use Alkaline or Lithium “high energy” Batteries with this pedal.

The correct,

optional 9V power supply from Electro-Harmonix is the 9.6VDC-US

200BI (same as used by Boss DC 200mA). The battery ™ & Ibanez™9.6 Volts

eliminator must have a barrel connector with center negative The battery may be .

left in or taken out when using an eliminator.
