Side 1/4

POG 2

Polyphonic Octave Generator

Congratulations on your purchase of the POG 2! The POG 2 is a Polyphonic Octave Generator that draws

its heritage from the now legendary POG, originally released in 2005 to worldwide acclaim. The POG 2 can

simultaneously generate multiple octaves from your input signal. Whether you play single notes, arpeggios

or full chords, the POG 2 will perfectly track every note you play. With the POG 2, you can mix together

your original "dry signal" with four different octaves: one octave above the original note, two octaves

above the original note, one octave below your original note and two octaves below the original note.

Additionally you can detune the two upper octaves, slow the attack on all voices including the dry signal

and process the overall tone through a low pass resonant filter with adjustable filter cutoff and selectable

Q. The POG 2 is fully programmable allowing you to store and load presets for performance and recording.

-CONTROLS-

DRY OUTPUT Slider

Controls the output volume of your original DRY signal before it exits the POG 2. –

The DRY OUTPUT volume will increase as its slider is pushed upward.

-2 OCTAVES Slider

Controls the output volume of the signal 2 octaves below the input signal, which is –

one quarter of the frequency of the input signal. As this slider is pushed upward, the volume of the -2

OCTAVE below the original pitch will increase. If you play a middle C note, this slider will control the

volume of the C note two octaves

below

middle C.

-1 OCTAVE Slider -

ntrols the output volume of the signal 1 octave below the input signal, which is Co

half the frequency of the input signal. As this slider is pushed upward, the volume of the -1 OCTAVE below

the original pitch will increase. If you play a middle C note, this slider will control the volume of the C note

one octave

below

middle C.

+1 OCTAVE Slider

– Controls the output volume of the +1 octave signal. True to its name, the +1

OCTAVE signal is one octave above the original input signal. The +1 octave signal is tw ice the frequency of

the original input signal. The volume of the +1 OCTAVE will increase as this slider is pushed upward. If you

play a middle C note, this slider will control the volume of the C note one octave

above

middle C.

+2 OCTAVE Slider

Controls the output volume of the +2 octave signal. The +2 octave signal is two –

octaves above the original input signal or four times the frequency of the original input signal. As this slider

WARNING:

Use only the 9.6 VDC 200mA adapter the POG 2 comes supplied with. Do not

use any other adapters. Using other adapters, even those made by Electro-Harmonix, could

cause harm to the unit, the adapter or you. The POG 2 does not use batteries.

is pushed upward, the volume of the +2 OCTAVE signal will increase. If you play a middle C note, this

slider will control the volume of the C note two octaves

above

middle C.

ATTACK Slider -

Controls the attack envelope of all the octave voices. As the ATTACK slider is pushed

upward, the attack time increases producing a swell or reverse effect. Push the ATTACK slider down to its

minimum position to turn the attack effect off. The Attack effect will also work on the DRY signal whenever

the DRY FX LED is lit, no matter the color of the DRY FX LED.

LP FILTER Slider

Controls the cutoff frequency of the Low Pass Filter. As the LP FILTER slider is pushed –

upward, the cutoff frequency of the filter rises. The LP Filter control can be used to shape the tone of your

POG 2. All of the generated octave signals go through the LP Filter. The dry signal bypasses the LP Filter

when the DRY FX LED is off or lit red, the dry signal goes through the LP Filter when the DRY FX LED is lit

green or amber.

DETUNE Slider

– Controls the amount of detune applied to the +1 and +2 OCTAVE signals. As the

DETUNE slider is pushed up both the depth and rate of detune are increased. When DETUNE is pushed

down to its minimum position the detune function shuts off. The DETUNE slider will also effect the DRY

signal when the DRY FX LED is lit amber.

DRY FX Push-Button and LED

The DRY FX Button cycles through four modes allowing the DRY signal –

to either bypass or pass through the Attack, LP Filter and Detune effects. The modes are as follows:

LED State MODE

DRY bypasses all effects Off

RED DRY goes through Attack control, bypasses LP Filter and Detune

GREEN DRY goes through Attack and LP Filter, bypasses Detune

AMBER DRY goes through all three effects: Attack, LP Filter and Detune

Q Push-Button and LED

The Q button and LED cycles through four levels of resonance or Q for the –

Low Pass Filter. As the Q LED gets brighter the Q increases. LED off signifies the least amount of Q. The

brightest Q LED setting signifies the highest Q setting.

PRESET KNOB

– The white PRESET knob is used to select, load and save the 8 available presets. You can

load the selected preset by pressing and releasing the PRESET knob. To save a setting, first set the POG 2

to the sound you want to save, then turn the PRESET knob to the preset number you want to save your

sound into. Now press and hold the PRESET knob for 3 seconds. Release the knob after all of the Preset

LEDs stop blinking.

BYPASS FSW and LED

– The BYPASS FSW is used to toggle the POG 2 between effect mode and true

bypass mode. When the associated LED is lit, the POG 2 is in effect mode. When the LED is off the POG 2

is in true bypass mode.

PRESET FSW and LED –

The PRESET FSW can be used to cycle through and load the 8 available presets.

When a preset is loaded, the PRESET LED located near the PRESET FSW will light up solid. If a preset is

loaded and then a slider is moved or push-button is pressed, the PRESET LED will blink rapidly to indicate

that a parameter has been changed since the preset was loaded.

INPUT Jack

POG 2. The input impedance presented at the INPUT – This ¼” jack is the audio input to the

jack is 2 M


