1-way wireless rotary switch for single

mounting 80 x 80 x 25 mm over a  ush box or

mounting into the E-Design55 switching

system. With battery (lifetime 2-8 years).

Smart Home sensor.

The scope of supply comprises a moun ting

base with snapped-on electronics, a frame

R1UE55 and a cover panel with rotary knob.

The rotary switch sends dimming values

(brightness values) to the dimming actuator.

At switching off over the rotary switch, this

value is stored into it. If several rotary switches

are taught in in the same dimming actuator,

and dimming commands are alternatively

sent from different ones, it can be that

brightness jumps appears during the dimming

process.

To teach-in the wireless rotary switch to the

actuators, remove the rotary knob.

2 internal 3 V CR1632 button cells are supplying

the power for several years.

To replace the button cell, just remove the

front panel and the rotary knob.

Only assemble on a  at surface:

Screw on mounting base or stick it on using

the enclosed adhesive foil. Then snap on the

frame, remove the battery insulations, plug on

the rotary knob and snap on the front panel.

We recommend stainless-steel countersunk

screws 2.9x25 mm, DIN 7982 C, for screw

connections. Both with rawl plugs 5x25 mm

and with 55 mm switch boxes. Set of 2 stain-

less-steel countersunk screws 2.9x25 mm

and plugs 5x25 mm are enclosed.

Minimum brightness can be adjusted in 3 steps

with one jumper. You can also select the soft-on

function which switches on the lighting grad-

ually.

Wireless sensor without wire

Wireless rotary switch

FDT55EB-

Temperature at mounting location:

-20°C up to +50°C.

Storage temperature: -25°C up to +70°C.

Relative humidity:

annual average value <75%.

30 055 539 - 1

Press on the middle of the rotary knob to

switch on at the last dimming value or to save

the current dimming value and switch off.

Wireless switching actuators FSR61, FL62

and FSLA can be switched on by pressing or

turning and switched off by pressing.

The following applies to FD62:

Turn to the right (clockwise) to dim up. The

turning speed determines the dim-up speed.

If the dimming actuator was switched off to

the right at the start of dimming, switch-on is

at minimum brightness followed by gradual

dim-up. This is the children‘s room circuit.

If the rotary knob is turned to the right jerkily

– with the actuator previously switched on or off

– dim-up is rapid to full brightness. This corre-

sponds to the double-click function of a normal

direction pushbutton, top

Turn to the left (anticlockwise) to dim-down

to the minimum brightness adjusted on the

dimming actuator. The turning speed deter-

mines the dim-down speed.

If the rotary knob is turned to the left jerkily,

dim-down is rapid to the minimum brightness

adjusted on the dimming actuator.

Teach-in:

To teach in the wireless rotary switch in

the actuators, pull off the rotary knob and

the front panel. Press and hold the mini

pushbutton (LRN) which is then accessi-

ble and brie y press the rotary knob

shaft.

Please look on the corresponding actua-

tors manual for the teaching-in position.

Teach-in telegram: 0xE0400D80

If the FDT55EB- is taught-in in FL62, FD62 or

FSLA, con rmation telegrams are auto-

matically switched on and sent. It locks

automatically the teach-in mode.

Enable teach-in mode with FDT55EB-:

Plug in the two jumpers on the 4 pins to

select the minimum brightness and brie y

press the rotary spindle.

Clear rotary switch from actuator:

Plug both jumpers on the 4 pins to select

minimum brightness and brie y press the

rotary spindle three times.

Then replug the two jumpers to the

required positions for minimum bright-

ness and Soft-On.

If the dimming actuator was switched off to

the left at the start of dimming, switch-on is

at minimum brightness followed by gradual

dim-up by turning to the right.

To replace the CR1632 button cells, just

remove the cover panel comprising the

rotary knob.

Set the minimum brightness in 3 steps using

the Min. Level jumper.

The lowest dimming value of 10% is situated in

the as-delivered state (jumper plugged onto

the two centre pins).

To reduce the lowest dimming value to 1%,

plug the jumper onto the two left pins.

To raise the lowest dimming value to 20%,

plug the jumper onto the two right pins.

When the Soft-On jumper is plugged onto the

two pins, is selected and the lighting Soft-On

is switched on gradually.

The crossed-out waste container indicates

that batteries may not be disposed with ot-

her household or commercial waste.

Batteries can be returned free of charge to

the retail outlet after use.

Attention: Danger of explosion if

battery is replaced improperly.

Only replace it by an equivalent

type!

Frequency 868.3 MHz

Transmit power max. 10 mW

Hereby, Eltako GmbH declares that the radio

equipment type FDT55EB- is in com pliance

with Directive 2014/53/EU.

The full text of the EU declaration of

conformity is available at the following

internet address: eltako.com

Must be kept for later use!

Eltako GmbH

D-70736 Fellbach

Technical Support English:

+49 711 943 500 25

technical-support@eltako.de

eltako.com

28/2022 Subject to change without notice.

Manuals and documents in further

languages

http://eltako.com/redirect/FDT55EB-

1. App 2. 3.
