FT4F-:

Wireless  at pushbuttons, 80x80 mm external

dimensions, internal frame dimensions

63x63 mm, 15 mm high. Generates the power

for wireless telegrams itself when the button

is pressed, therefore there is no connecting

wire and no standby loss.

The scope of supply comprises the frame

R1F, a  at rocker WF, a  at double rocker

DWF (all same colour), an attachment frame

BRF, the mounting base HP, the wireless

module and one adhesive foil.

FT55-:

Wireless pushbuttons, 80x80 mm external

dimensions, internal frame dimensions

55x55 mm, 15 mm high.

Generates the power for wireless telegrams

itself when the button is pressed, therefore

there is no connecting wire and no standby

loss.

The scope of supply comprises the frame R,

a rocker W55, a double rocker DW55 (all

same colour), an attachment frame BRF, the

mounting base HP, the wireless module and

one adhesive foil.

Wireless pushbuttons with one rocker can

transmit two evaluable signals: press rocker

up and press rocker down. Wireless push-

buttons with double rocker can transmit

four evaluable signals: press two rockers up

or down.

The mounting base can be screwed onto a

 at surface or glued to the wall, on glass or

on furniture using the enclosed adhesive

foil. Use the sleeves in the 55 mm socket

box for screw mounting.

Wireless sensor

Wireless  at pushbuttons

FT4F-

Wireless pushbuttons FT55-

Temperature at mounting location:

-20°C up to +50°C.

Storage temperature: -25°C up to +70°C.

Relative humidity:

annual average value <75%.

30 000 595 - 1

The double rocker is snapped onto the

wire-

less module at the factory. If the double rocker

is replaced by the large rocker, remove the

rocker halves by pulling off to the front. Do

not bend towards the middle. Then snap the

large rocker so that the markings 0 and I on

the back line up with the same markings on

the wireless module.

Adhesion: First adhere the set

comprising

the mounting base, frame and attachment

frame

- with the latches pointing at the top

and bottom. Then snap on the set

comprising

the wireless module and rocker

- with the

marking 0 on the back always pointing up.

Before screwing, remove the mounting

base from the frame and the attachment

frame. To do this, press the latches on the

mounting base outwards. Then screw the

mounting base - with the latches at top and

bottom -, snap on the frame with the attach-

ment frame and snap on the set

comprising

the wireless module and rocker

- with the

marking 0 on the back always pointing to

the top.

For screw mounting, we recommend stain-

less steel countersunk screws 2.9x25 mm,

DIN 7982 C, for screw connections. Both

with rawl plugs 5x25 mm and with 55 mm

switch boxes.

The Eltako frame can be replaced on

installation at any time by a design frame

with the same internal dimensions from

other manufacturers. FT4F: 63x63 mm,

FT55: 55x55 mm.

The wireless module integrated in the

wireless pushbuttons can be taught-in

encrypted in all encryptable actuators of

the 61 Series, 62 Series and Series 71 as

well as the FAM14. This requires the FTVW

wireless pushbutton encryption rocker.

Encryptable actuators bear the pictogram

Pushbuttons with engraving +0I:

If wireless pushbuttons are taught-in as

direction switches in a building, it is then

recommended to  t any central control switch

with the engraving 0/I rotated through 180°.

Then the central switch-on (I) is at the top

as well as the switch-on for the direction

switches.

Teaching-in wireless sensors in wire-

less actuators

All sensors must be taught-in in the

actuators so that they can detect and

execute commands.

The teach-in process is described in the

operating instructions of actuators.

Manuals and documents in further

languages

http://eltako.com/redirect/FT4F-_FT55-

1. App 2. 3.

www.

Frequency 868.3 MHz

Transmit power max. 10 mW

Hereby, Eltako GmbH declares that the radio

equipment type FT4F-, FT55- is in com-

pliance with Directive 2014/53/EU.

The full text of the EU declaration of

conformity is available at the following

internet address: eltako.com

Must be kept for later use!

Eltako GmbH

D-70736 Fellbach

Technical Support English:

+49 711 943 500 25

technical-support@eltako.de

eltako.com

42/2022 Subject to change without notice.
