Wireless shading element and

roller shutter actuator

FJ62NP-230V

Temperature at mounting location:

-20°C up to +50°C.

Storage temperature: -25°C up to +70°C.

Relative humidity:

annual average value <75%.

30 200 535 - 3

Only skilled electricians may install this

electrical equipment otherwise there is

the risk of  re or electric shock!

Wireless shading element and roller shutter

actuator 1+1 NO contact, 4 A/250 V AC, not

potential free, for a shading element motor

230 V AC. Standby loss only 0.6 watt.

For installation. 49x51 mm, 20 mm deep.

The terminals are plug-in terminals for

conductor cross-sections of 0.2 mm

2.5 mm

The convenient wireless technology permits

the teach-in of up to 32 wireless universal

pushbuttons, wireless direction pushbuttons

and wireless central control pushbuttons.

Zero passage switching.

Bidirectional wireless switchable.

Supply voltage, switching voltage and

control voltage local 230 V.

If supply voltage fails, the device is

switched off in de ned mode.

In addition to the wireless control input via

an internal antenna, this wireless actuator

can also be controlled locally by a conven-

tional control switch if  tted previously.

Control is either by separate local control

inputs for Up and Down as direction push-

buttons or these two inputs are bridged and

controlled by single pushbuttons as universal

pushbuttons. A change in direction then

takes place by interrupting activation.

An incandescent lamp current is not per-

mitted.

valid for devices from production week

14/22 (see bottom side of housing)

Wireless pushbuttons can be taught in with

either the functions 'Up-Stop-Down-Stop'

as universal pushbuttons or as local push-

buttons as well as a wireless pushbutton or

roller shutter double pushbuttons can be

taught in as direction pushbuttons with press

top for 'Up' and bottom for 'Down'. Press

brie y to stop the movement. In addition,

the central control button can be taught in

with static priority.

The static priority is only active as long as

the radio button is pressed. With a control

signal, e.g. B. a radio transmitter module

FSM61 with switches that has been taught-in

as a central control button, the switching

position'Up' or 'Down' and the priority are

speci cally activated. With priority because

these control signals cannot be overridden

by other control signals until the central

command is canceled again by the end of

the control signal.

The tap reverse function can be activated:

universal pushbuttons, direction pushbuttons

and wired pushbuttons are intially in static

mode so that the position of the blind can

be adjusted.

With control via GFVS software, operating

commands for 'up' and 'down' with the exact

travel time information can be started. As

the actuator reports the exact elapsed time

after each activity, even when driving was

triggered by a pushbutton, the position of

the shading is always displayed correctly in

the GFVS software. Upon reaching the end

positions above and below the position is

automatically synchronized.

When a wireless window contact is taught

in, a lockout protection is set up for open

windows or doors to disable the Central

Down and GFVS Down commands.

Typical connection

Startup:

After power supply is switched on, the

teach-in mode is activated automatically

for 2 minutes if the memory is empty

(as-delivered state) or if the teach-in

mode was not blocked. Teach-in standby

is alerted by a short 'Down, Stop' signal.

If no action occurs for 2 minutes, teach-in

mode ends automatically.

This is signalled by a short 'Down, Stop'.

Teaching-in sensors

Universal pushbutton: tap brie y 3 times;

Direction pushbutton: tap brie y 4 times;

Top part of direction pushbutton as 'Up'

and lower part as 'Down' and 'Stop' in each

case; direction pushbuttons are fully

taught in automatically when the top or

bottom part is pressed.

Central control pushbutton Up:

Tap brie y 5 times;

Central control pushbutton Down:

Tap brie y 6 times;

Window contact FTK, FTKB: (EEP

D5-00-01) as well as FTKE (EEP F6-10-00):

Close and open the window brie y 4 times;

(Close window -> open -> close -> open

->- close -> open -> close -> open)

Wireless window handle sensor FFG7B:

(EEP A5-14-09)

Wireless window/door contact FTKB-hg,

mTronic:

(EEP A5-14-0A)

Wireless window door contact FFGB-hg:

(EEP A5-14-01, -03, -0A)

Wireless window door contact eTronic:

(EEP A5-14-01)

Wireless timer FSU55D, FSU65D:

(EEP A5-38-08)

ON command = Up, OFF command = Down

GFVS: (EEP A5-3F-7F)

Con rmation telegrams are switched on

and sent automatically at teaching-in of

the GFVS. It locks automatically the

teach-in mode.

After a sensor is taught in, it is con rmed

by a short 'Down, Stop'; the teach-in

mode is active for a further 2 minutes.

To avoid teach-in by accident, the

teach-in mode is blocked automatically

2 minutes after the last teach-in if a

universal or a direction pushbutton was

previously taught in. This is alerted by

two short 'Down, Stop' signals.

Encrypted and unencrypted sensors can

be taught in.

Teach in encrypted sensors:

1. Activate teach-in mode if necessary.

2. Activate sensor encryption within

2 minutes.

3. Then teach in the encrypted sensor as

described under 'Teach in sensors'.

With encrypted sensors, use the 'rolling

code', i.e. the code changes in each tele-

gram, both in the transmitter and in the

receiver.

If a sensor sends more than 50 telegrams

when the actuator is not active, the sensor

is no longer recognised when the actuator

is active and must be taught in again as

'encrypted sensor'. It is not necessary to

teach in the function again.

Block teach-in mode immediately:

Tap the pushbutton or an already taught-in

wireless pushbutton (but not a central

control pushbutton) 3 times brie y and

once long (>2 seconds). Lock is signalled

by two short 'Down, Stop' signals.

Unlock teach-in mode:

Tap the rocker, a cable-bound push button

or an already taught-in wireless push-

button (but not a central control button)

4 times brie y and once long (>2 seconds).

Teach-in mode is signalled by a short

'Down, Stop' signal.

Teach in con rmation telegrams from

other actuators:

Unlock simpli ed learning mode:

1. Tap an already taught-in wireless

pushbutton (not central control push-

button) or the local wired button 4 times

brie y plus 2 times long (> 2 seconds).

The readiness for teching-in is sig-

naled by a brie y 'Down, Stop', this

mode is active for 30 seconds.

Switch the actuator, which its con rma-

tion

telegram has to be taught in, on or

off with its wired button. The automatic

locking is signaled immediately after

teaching-in by a brief double 'Down,

Stop'.

Con rmation telegram 'ON' (0x70 and

0x30) is taught in as 'Central UP'.

Con rmation telegram 'OFF' (0x50 and

0x10) is taught in as 'Central DOWN'.

Clear memory content completely

(restore as-delivered state):

1. Switch power supply off/on.

2. Tap the already taught-in wireless

pushbutton (but not a central control

button) 8 times brie y and once long

(>2 seconds).

Clear is signalled by a brief 'Down,

Stop'.

3. Apply on 'Teach in wireless push-

button'.

Teach-in individual release delay time

(Tap reverse function is here not allowed):

1. Start 'go down' by brie y tapping an already

taught-in wireless pushbutton or the local

pushbutton.

2. When the shading element reaches the

bottom end position, unlock the teach-in

mode with an already taught-in wireless

pushbutton (not a central control push-

button) or the local pushbutton.

Start 'go up' by pressing long (>2 seconds)

the already taught-in wireless

pushbutton

(not a central control pushbutton).

After the

shading element reaches the top end

position, tap the pushbutton brie y, the

travel time is saved as the new release

delay time.

After this procedure, the teach-in mode is

automatically locked.

Tap reverse activation:

1. Switch power supply off/on.

2. Tap the already taught-in wireless push-

button (but not a central control button)

5 times brie y and once long (>2 seconds).

ON is signalled by two brief 'Down, Stop'

signals.

Tap reverse deactivation (factory setting):

1. Switch power supply off/on.

2. Tap the already taught-in wireless push-

button (but not a central control button)

6 times brie y and once long (>2 seconds).

OFF is signalled by two brief 'Down, Stop'

signals.

Switch on/off con rmation telegrams:

1. Switch power supply off/on.

2. Tap already taught-in wireless pushbutton

(but not a central control button) 7 times

brie y and once long (>2 seconds).

On is signalled by a two brief 'Down, Stop'

signals.

Off is signalled by a brief 'Down, Stop'.

The release delay time in as-delivered state

is 200 seconds.

Frequency 868.3 MHz

Transmit power max. 10 mW

Hereby, Eltako GmbH declares that the radio

equipment type FJ62NP-230V is in com-

pliance with Directive 2014/53/EU.

The full text of the EU declaration of

conformity is available at the following

internet address: eltako.com

Must be kept for later use!

Eltako GmbH

D-70736 Fellbach

Technical Support English:

+49 711 94350025

technical-support@eltako.de

eltako.com

28/2022 Subject to change without notice.

Manuals and documents in further

languages

http://eltako.com/redirect/FJ62NP-230V

1. App 2. 3.
