Side 1/4
IMPORTANT:
Go to www.extron.com for the complete
user guide, installation instructions, and
specifications before connecting the
product to the power source.
BUC 202 • Setup Guide
This guide provides instructions for an experienced installer to set up and operate the Extron
BUC 202 two channel unbalanced/balanced audio converter and line driver.
Rear Panel Features and Cabling
100-240V 50/60 Hz
0.2A MAX
1
2
1
2
OUTPUTS
BUC 202
15
18
0
21
3
6
9
12
-15
-18
-21
-3
-6
-9
-12
15
18
0
21
3
6
9
12
-15
-18
-21
-3
-6
-9
-12
1
2
INPUTS
A
B
C
D
A
AC power — Connect to standard AC power: 100 to 240 VAC, at 50 or 60 Hz.
B
Trim adjustment (channels 1 and 2) — Adjust the audio input level for the channel using
the 16-position rotary switch. This switch sets the level in 3 dB increments from -21 dB to
+21 dB. The arrow on the shaft indicates the current setting.
C
— This 3.5 mm 5-pole captive screw connector accepts line level Input connector
balanced or unbalanced, mono or stereo audio signals (see the illustrations below for
proper wiring).
Unbalanced Stereo Input
Balanced Stereo Input
Tip
Ring
Tip
Ring
1 2
Sleeves
Tip
Sleeve
Sleeve
Tip
1 2
Unbalanced Dual Mono Input
Balanced Dual Mono Input
(high impedance)
Tip
Ring
1 2
Sleeve
Tip
Sleeve
1 2
Do not tin the wires!
Tip-ring-sleeve and tip-sleeve connections:
NOTE: Unity gain (0 dB) for both channels is at the 12 o’clock
(vertical) position with the arrow on the shaft pointing to the 0
position. When the switch is set to the bottom position (indicated
by a dot) the signal is muted (see Adjusting the Trim).
1
2
TRIM
15
18
0
21
3
6
9
12
-15
-18
-21
-3
-6
-9
-12
15
18
0
21
3
6
9
12
-15
-18
-21
-3
-6
-9
-12
Sleeve ( )
Ring (R)
Tip (L)
Tip (+)
Sleeve ( )
Tip-Ring-Sleeve Tip-Sleeve


Produkt Specifikationer

Mærke: Extron
Kategori: Audio/video konverter
Model: BUC 202
Bredde: 110 mm
Dybde: 114 mm
Højde: 42 mm
Vægt: 400 g
Produktfarve: Sort
Strømforbrug (typisk): 2.9 W
Harmoniseret systemkode (HS): 85176990
Ekstern strømadapter: Ingen
Prøvetagningsfrekvens: 20 - 20000
