Safety pressure switch with manual reset, suitable for heating systems.
B01BMX
Maximum pressure switch with manual reset, IP44
ELECTRICAL FEATURES
Microswitch with manual reset.
2 1
Dimensions (mm)
Range
bar
Differential
minimum for
reset
Sensitive element
max. pressure
bar
Connection
G 1/4
Protection
degree
Contact type
B01BMX 2 ÷ 5,5 0,6 bar 7 female IP44 NC
40 65,3
22,8
15,3
G 1/4
7125,5
CH17
HOMOLOGATION AND STANDARDS
Complies with EN 60730-1 and EN 60730-2-6 standards.
0497
Nominal insulation tension Ui 380V~
Continuous duty nominal current Ith 15A
Operating nominal current Ie: 220V- 250V~ 380V~
Resistive load AC-12 - 15A 10A
Inductive load AC-15 - 2,5A 1,5A
Continuous current DC-13 0,2A - -
13
INSTALLATION
Direct installation on the pipe.
If the fluid temperature exceeds the max allowed value, connect the pressure switch to the pipe by mean of a spiral metallic tube to
better dissipate the heat.
OPERATION
When pressure reaches the minimum set value: 1-2 opens.
The reset function (closes 1-2) is only possible by re-arming the pressure switch by pushing the reset button once the pressure inside
the pipe is above the minimum set value.
FEATURES
Fluid contact parts made in stainless steel, laser welded.
Base and cover in shockproof thermoplastic material.
Output connections in shockproof and self-extinguishing thermoplastic V0 cable gland.
Sensible element with membrane made in stainless steel.
Internal adjustment: the case is ready to be sealed after the calibration.
Maximum temperature of the controlled fluid: 120°C.
Pressure switch max body temperature: -35 ÷ 80°C.
Storage and transport temperature: -35 ÷ 80°C.
Unit weight: 0,14Kg.
