Side 1/5

K12C

ANTIFREEZE HEATING CABLES

WITH CONSTANT POWER FOR PIPES

■Suitable for protection against

freezing pipes for misting, irrigation

and ﬁre prevention systems

■Constant power delivered ~10 W/m

HEATING CABLES

CODE Cable

length

Minimum

installation room

temperature

Maximum

room temperature

powered

Maximum length

of the heating circuit

from the supply point

K12C25 25 m -20 °C 40 °C 160 m

K12C50 50 m -20 °C 40 °C 160 m

K12C75 75 m -20 °C 40 °C 160 m

HOMOLOGATION AND STANDARDS OPERATION

■The heating cables consist of a coil-wound

resistance on two conductors. The resistance is

in contact with the conductors through splicing

points at constant intervals; the energy to heat the

resistance is drawn at the splicing points;

■The total power of the cable is determined by a

combination of temperature, length of the heating

circuit and supply voltage;

■They require control thermostats to be used to

function.

K12C - HEATING CABLES WITH CONSTANT ANTIFREEZE POWER FOR PIPES

Ø PIPE Minimum room temperature

with 19 mm coating

on the pipe

inches -10°C -20°C

19 3/4 1:1 1:1

25 1 1:1 1:1

38 1 1/2 1:1 1:1

50 2 1:1 1:1

63 2 1/2 1:1 1.4:1

75 3 1:1 1.6:1

100 4 1:1 2:1

INSTALLATION

■The cable can only be cut at the indicated splicing

points;

■Minimum bending radius 20 mm;

■The length of the cable varies according to the

diameter of the pipe;

■The cable must be secured along the pipe with

the relevant ﬁxing tape code K50 for steel pipes or

code K50AL for plastic pipes;

■In the case of large pipes, the strips may need to

be wound so as to ensure adequate heat;

■The conductors have cold tails and can be

connected directly to the thermostat or to the

junction box;

■At the end of the cable, the 2 conductors must be

kept insulated and must not come into contact

with each other; use the kit to seal the terminals

for cables with constant power (for 1 cable) code

KIT1A;

■It is advisable to apply an insulating coating over

the heating cable for a correct installation;

■Refer to the table to check whether the cables

must be wound in a spiral with an increase in the

required length.

The table shows the ratio between the length of the heating cable

with that of the pipe, depending on the outside temperature and

the pipe Ø. The values shown are based on the use of an insulating

coating with a thickness of 19 mm with a coefﬁcient of thermal

conductivity of 0.034 W/m at 0°C.
