Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage

of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson

products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is

required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications

and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.

Rev.B

INST-820

Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage

of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson

products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is

required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications

and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.

7160-0987-XX

F110 DOCKING STATION

PS-001

Printing Spec:

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

Revision Form Product

INSTALLATION INSTRUCTIONS

Item No. 7160-0987-33 Tri-RF WITH ACCELEROMETER POWERED RS232

Item No. 7160-0987-40 No RF WITH POWERED RS232

Item No. 7160-0987-43 Tri-RF WITH POWERED RS232

This instruction sheet is for the following products:

Item No. 7160-0987-00 No RF

Item No. 7160-0987-03 Tri-RF

Item No. 7160-0987-10 No RF WITH HANDLE

Item No. 7160-0987-13 Tri-RF WITH HANDLE

Item No. 7160-0987-20 No RF WITH ACCELEROMETER

Item No. 7160-0987-23 Tri-RF WITH ACCELEROMETER

Item No. 7160-0987-30 No RF WITH ACCELEROMETER POWERED RS232

This instruction sheet is for the F110 docking station only. For instructions on

features, set-up, and operation of the F110 computer, please refer to the manual

provided by Getac with the computer.

This docking station is designed to be used with a variety of Gamber-Johnson

mounting systems. Installation instructions for other Gamber-Johnson products

are provided with each individual product.

During Installation:

DO NOT connect this docking station to the vehicle battery until:

All other electrical connections are made1.

Mounting of all components is complete2.

Verification that no shorts exist in the entire system3.

DO NOT install equipment or route wiring or cords in the deployment path of any air bag.

When drilling into the vehicle, DO make sure that both sides of the surface are clear of

anything that could be damaged.

CAUTION:

If wiring is shorted to the frame, high current conductors can cause hazardous

sparks resulting in electrical fires or flying molten metal.

After installation:

Test the docking station to ensure that it is working properly.

File these instructions in a safe place and refer to them when performing maintenance or re-

installing.

WARNING

: Failure to follow all safety precautions and instructions may result in property

damage, serious injury, or death.

IMPORTANT SAFETY INFORMATION FOR INSTALLERS

Safety is dependent on the proper installation and servicing of this docking station. It is

important to read and follow all instructions before installing this product.

To properly install a Gamber-Johnson docking station you must have a good understanding of

automotive electrical procedures and systems, along with proficiency in the installation and

service of aftermarket vehicle equipment.

There are no adjustments required at any time of the electrical components within the

docking station. Opening the docking station will void the product warranty.

Conduct a "Bench Test"

Gamber-Johnson strongly advises a "bench test" be conducted to verify all

electronic and software issues are resolved prior to installation:

Make sure the computer is operational by itself.1.

Insert computer into the docking station and verify that the computer is 2.

operating in the dock.

Interconnect entire assembly and verify start-up of all components, 3.

including other equipment (printers, modems, scanners, etc.)

Gamber-Johnson recommends positioning of all mounts and equipment in the

vehicle prior to the actual install to verify that mounting locations are safe and

practical.

PRE-INSTALLATION RECOMMENDATOINS
