Side 1/8
2. ABOUT AUTOMATIC SNOW MELTING
With automatic snow melting, you keep it dry and ice-free throughout
the winter. This contributes to both increased safety against falls and
accidents when it is slippery, as well as saving work with shoveling,
spreading and salting. Ground sensors can be installed in places where
snow and ice problems normally occur, which gives you functional
and energy-saving control of the heating cables. The sensors can be
installed in concrete or asphalt, or placed under paving stones and
tiles, in addition to the roof/gutter. There are also precipitation sensors
for wall mounting where you cannot place the sensor in the ground.
Whether it is ice or snow on stairs, in the entrance or driveway that is
the problem, a thermostat can be used to regulate the system. The
thermostat receives information about temperature and humidity from
a sensor, and it knows itself if there is rain or snow, and the risk of ice
formation. Based on system settings and your wishes, it will ensure ice-
free access to, for example, the mailbox or garage.
A pre-programmed installation procedure guides you through the
setup, helping you make the choices that suit your needs. Based on
your choices, the snow melt thermostat suggests the optimal settings
for your conguration.
3. INSTALLATION GUIDELINES
The power supply must always be disconnected before installation or
maintenance work on the control unit or on components connected
to it. This control unit or components connected to it must only be
installed by a registered installation company. The product must be
installed and documented in accordance with the current edition of
NEK 400 and the installation instructions.
How to install Multireg IceControl Pro
1. Use a at object (e.g. a at-head screwdriver) to bend the trigger on
the DIN rail.
2. Place the top of the Multireg IceControl Pro mounting slot over the
top of the DIN rail.
3. Bend the Multireg IceControl Pro towards the DIN rail until the
bottom clicks into place.
Make all necessary connections to the device, and reconnect the
power once all connections are made.
PREPARATION AND CONNECTION OF CABLES
Before connecting, the cables must be stripped of approx. 6mm.
Be careful not to damage the conductors. Tighten the cables with a
torque of 0.5 Nm. The cable size should be between 12 and 30 AWG.
MULTIREG
ICECONTROL PRO
Firmware 1.10
01.01.2020
Installation guide
Version 2025-F (01.11.25)
CONTENT
1. Introduction
2. About snow melting automation
3. Installation guidelines
4. Connection
4.1 Overview of connection Multireg IceControl Pro
4.2 Connection diagram IceControl ground sensor TF GS
4.3 Connection diagram IceControl air sensor TF AIS
4.4 Placement of IceControl ground sensor TF GS
5. First-time startup/restart
6. Menu
7. Advanced settings
7.1 Ground sensor 1
7.2 IceControl air sensor TF AIS
7.3 IceControl gutter sensor TF TS2
7.4 IceControl rain and snow sensor
7.5 Other advanced settings items
7.6 System information
8. Connecting other sensors
8.1 Connection diagram IceControl gutter sensor TF TS2
8.2 Connection diagram IceControl rain and snow sensor
- Location of IceControl rain and snow sensor
Product information
Accessories for automatic snow melting
MODBUS 485
1. INTRODUCTION
Multireg IceControl Pro is a control unit for up to two heating zones.
It is designed to melt snow and ice on the ground, in stairs and on
roofs and in gutters. You can control the heating in the ground and the
heating cables in the gutter with one and the same system. If you are
going to have two zones with ground heating, you must also have two
ground sensors.
Multireg IceControl Pro is compatible with several types of ground
and air sensors. The controller is used for electric heating systems. It is
equipped with a simple and user-friendly menu. Read the installation
instructions carefully before starting up.
