IMPORTANT!

PLEASE READ THIS BEFORE INSTALLATION.

This thermostat is tested and certiﬁed by Pepper One Gmbh

according to the requirements put forward by the Z-Wave

Alliance. This is a Z-wave Plus product with the 500 series chip.

If the product does not work with your gateway, then the

gateway manufacturer has not made an integration or

implemented such a thermostat with their gateway.

We do not give any guarantee towards integration.

PRINCIPLES FOR REGULATION

The Heatit Z-Wave thermostat is designed for controlling

electrical heating cables and electrical radiators/convectors.

The thermostat has 2 internal temperature sensors and has

3 algorithms for temperature compensation. After you have

set the temperature, the thermostat will use a hysteresis to

regulate the temperature. The hysteresis is adjustable.

TEMPERATURE SHOWN IN DISPLAY

The temperature shown in the display is the actual temperature

for ﬂoor sensor and the external room sensor. You are able to

calibrate the sensor values.

When using the internal room sensor, the temperature shown

is the set point. When using the internal sensor, the thermostat

can seem somewhat inaccurate. This is due to heat generation

inside the thermostat, draft and other external inﬂuences.

If the thermostat is to be used with waterbased heating systems,

you have to use an external sensor.

SETUP

This manual describes the most essential functions and

technical speciﬁcations of the thermostat. These instructions

help the user to control the thermostat, and the electrician

to install and setup the thermostat.

INSTALLATION

Installation must be done by a qualiﬁed electrical installer in

accordance with the National Building codes. Before installation,

disconnect any power to the thermostat’s mains. During

installation of the thermostat, power to the thermostat must

be disconnected AT ALL TIMES!

Use e.g. a small slotted screwdriver. Start by carefully removing

the front cover by pushing the release springs. The front cover

and the frame can now be removed.

Now connect the wires to the thermostat’s terminals:

HEATING (N) Heating cable connection (Neutral)

N Power connection (Neutral) 230V

L Power connection (Live) 230V

HEATING (L) Heating cable connection (Live)

PILOT Pilot signal (ECO temp) 230V

FLOOR SENSOR NTC type (10, 12, 15, 22, 33 or 47kΩ).

Default 10kΩ.

EXTERNAL SENSOR NTC type (10, 12, 15, 22, 33 or 47kΩ).

Default 10kΩ.

Next, position the thermostat and fasten it onto the wall’s

mounting box using 2-4 screws. Position the frame, then

position and carefully press the front cover until it snaps in

place. Check that the front cover has snapped in place properly

on both left and right side. The front cover should now be ﬁrmly

ﬁxed on all sides.

STARTUP

AFTER CONNECTING THE POWER TO THE THERMOSTAT FOR THE

FIRST TIME, ALL PARAMETERS WILL HAVE DEFAULT SETTINGS.

2 yr

HEATIT Z-WAVE

Installers manual

Firmware 1.8

01.06.2016

Release spring

1: Left 3: Right2: Center

87 mm

58,8 mm

HEAT ING L

HEAT ING N

PILOT WIRE

FLOOR

SENSOR

EXT ERNAL

SENSOR

Made in EU

TF 021

21,3 mm

51,1 mm

87 mm

58,8 mm

29,9 mm

CONTROL

The thermostat is controlled by three touch sensitive capacitive

buttons.

You only need to touch lightly to activate the buttons.

1: Left (Up)

2: Center (Conﬁrm)

3: Right (Down)

INCLUSION/EXCLUSION

To include the thermostat to your home automation gateway,

press Center (conﬁrm) for 10 seconds.

The display will show OFF. Press Right (down) 4 times till you

see Con in the display. Now start add device in your home

automation software. Start inclusion mode by pressing Center

(conﬁrm) for approximately 2 seconds. The inclusion/exclusion

icon will appear in the display. Conﬁrmation will show Inc/EcL

in the display. If inclusion fails, Err (error) will appear.

Leave programming mode by choosing ESC in menu.

Your thermostat is ready for use with default settings.

PROGRAMMING YOUR THERMOSTAT

To activate the programming mode, press Center (conﬁrm)

for 10 seconds. Now the display will show OFF.

Now you are in programming mode. To scroll up and down

in the menu use button 1 and 3 (left and right) to navigate.

To enter submenu press Center (conﬁrm). Always conﬁrm

your setting by pressing Center (conﬁrm) for 2 seconds.

Menu:

OFF Turns the thermostat oﬀ.

Sensors:

F Floor sensor

A Internal room sensor

AF Internal room + Floor sensor

A2 External room sensor

P Power regulator

FP Floor sensor + Power regulator

A2F External room sensor + Floor sensor

Depending on your choice of sensors, the menu will change.

SEn Select the right Ohm value for your external/ﬂoor sensor.

NTC type (10, 12, 15, 22, 33 or 47kΩ). Default 10kΩ.

CAE Calibration for external sensor.

CAF Calibration for ﬂoor sensor.

CAR Calibration for room sensor.

br1 Brightness of display can be adjusted in this menu.

Con Activation of inclusion/exclusion mode.

diF Hysteresis

ALo Setting lowest allowed temperature (limitation).

(Airsensor)

AHI Setting highest allowed temperature (limitation).

(Airsensor)

FLO Setting lowest allowed temperature (limitation).

(Floor sensor)

FHI Setting highest allowed temperature (limitation).

(Floor sensor)

HEA Switch between heating and cooling function.

ESC Escape – exit programming menu.

PRODUCT INFO Heatit Z-Wave

FEATURES

• Floor sensor

• External room sensor

• Internal room sensor

• Temperature limiter

• Power regulator

• Z-Wave Plus, 500 series

• Weekly program via gateway

• Setback mode via

gateway or pilot wire

• LED-diode

• Can be used in connection

with diﬀerent NTC-sensors

• Lock mode/child lock

• Backlight

• Calibration

• 8 associations

TECHNICAL DATA

Protocol Z-Wave Plus, 868,4 MHz

Rated voltage 230V 50/60Hz

Max load 3600W (resistive load)

750W self-limiting heating cable

Max current 16A

Power consumption 1,5W

Power regulator Time cycle 0-30 min

Min/max installation temp. -20°C to 40°C

Min/max operating temp. 5°C to 40°C

Temperature intervals Floor sensor 5°C to 40°C

External room sensor 5°C to 40°C

Hysteresis 0,3°C to 3,0°C (default 0,5°C)

Sensor values 0°C 29,1 kOhm

10°C 18,6 kOhm

15°C 15,1 kOhm

20°C 12,2 kOhm

25°C 10,0 kOhm

Switch Single-pole switch

IP class IP21

TERMINAL

Use 1,5 mm² or 2,5 mm² according to load.

INCLUDED IN PACKAGE

Floor sensor 3 meters, Art. no. 5430109

WARRANTY

2 years

The thermostat is designed for electrical heating.

ART. NO. PRODUCT COLOR

5430499 Heatit Z-Wave thermostat 3600W 16A White RAL 9003

5430498 Heatit Z-Wave thermostat 3600W 16A Black RAL 9011

5430311 Frame for Heatit White RAL 9003

5430312 Frame for Heatit Black RAL 9011

5430497 Cable for software update on thermostat

5430108 Floor sensor Ø3mm 6m NTC 10 kOhm

5430109 Floor sensor Ø4mm 3m NTC 10 kOhm

5430128 External room sensor, glass front NTC 10 kOhm

5430471 External enclosed sensor IP 20/54
