1. Battery Installation

1) Use the included the T10 Torx tool unscrew battery cover screw until the battery to

cover can be opened as shown in Fig 2.

2) Inspect the battery compartment for dirt, moisture, or corrosion, and then clean

the battery compartment if needed.

3) Inspect the O-ring seal on the battery cover to make sure that it is free of sand and

dirt particles and that it has not been damaged.

4) Install the battery as marked on the battery compartment floor with the ribbon

under the battery cell to help with future battery removal. (See Fig 2 ).

5) After installing the battery, close the battery cover and use the included the T10

Torx tool rotate the battery cap screw until secure .to clockwise

Caution:

The P.ID includes a flat top 18350 Li-ion battery which requires use of the included

charging cable or a high quality charger only. Frequently inspect the condition of the

battery, including the terminals and outer shrink wrap. Do not use a battery with

signs of damage.

1) High Power White LED with Visible Laser (DUAL includes IR Laser)

2) Rechargeable 18350 battery

3) Magnetic Charging Port

4) CNC Milled 7075 Aluminum Housing

5) IP68 Dust and Waterproof

6) 2 Rail Interface Adapters

www.holosun.com

WEAPON LIGHT + LASER SIGHT

P.ID PLUS

P.ID DUAL

System Description

Battery

Thank you for purchasing the P.ID PLUS/DUAL from HOLOSUN The P.ID .

PLUS/DUAL is a weapon combines a visible laser (PLUS) or visible light system that

and IR laser (DUAL) high-power LED designed for Positive with a white light

IDentification in all-weather and . lighting conditions The P.ID PLUS/DUAL attaches

to any firearm that uses a MIL-STD 1913 Picatinny rail and includes adapters for

universal compatibility. This product is a Class III laser. Before operation, please

read the User's Manual carefully:

2. Battery Recharging

1) The recharging voltage for the P.ID PLUS/DUAL is DC5V.

2) Connect the USB end of the charging cable to an external USB power source,

then attach the opposite end of the magnetic charging cable to the charging port of

the sight (See Fig 3)..

I. Red indicator light: charging

ii. Green indicator light: fully charged

Caution:

Do not connect the charger if there is no battery installed.

Do not use a disposable battery.

Please keep the charging port clean, wipe any dust or debris away before charging.

The P.ID PLUS/DUALcan only be charged with the included magnetic charging

cable, that is not compatible with other MCC cables.

Fig 2

WARNING:

1. Do not point the light or laser towards human eyes.

This may cause temporary, or permanent damage to

the eyes.

2. Do not look into the laser through binoculars or

telescopes.

Important Notices

1. Component Description

2. Packaging

The P.ID PLUS/DUAL packaging includes the following items:

1) P. ID PLUS or DUAL Light w/ Laser Sight(s)

2) User Manual

3) 2 Rail Interface Adapter Inserts(Adapter 1 is installed on the product)

4) T10 Torx Tool

5) USB Magnetic Charging Cable

6) Flat Top 18350 Battery

when the light is on. The radiant energy of the light may cause damage to the light

itself, or even result in burning other materials.

5. Do not leave the light in any type of fabric bag or fusible plastic container under

high temperature.

CAUTION:

1. Ensure the firearm is unloaded and safe by removing all ammunition and

magazines from firearm and verifying an empty chamber before installation and

battery replacement.

DO NOT ATTEMPT TO INSTALL THIS SIGHT KIT ON A

LOADED FIREARM

2. Remove the P.ID PLUS/DUAL from the firearm and ensure the light is OFF before

performing any inspections.

3. Please remove the battery before storing the light for a long period of time.

4. Please keep the packaging should you need to make a warranty claim.

User Manual

Features

Fig 3

Battery

Compartment

Battery

Battery Insulation

Material

Battery Cover

O-Ring Seal

Screw

THIS PRODUCT COMPLIES WITH 21CFR PARTS

1040.10 AND 1040.11 EXCEPT FOR DEVIATION

PURSUANT TO LASER NOTICE 50 DATED JUNE 24,2007.

THIS PRODUCT COMPLIES WITH IEC

60825-1:2007-03 ED. 2.0 AND IEC

60825-1:2014-05 ED. 3.0

WARNING VISIBLE AND INVISIBLE

LASER RADIATION

DO NOT STARE INTO THE BEAM OR VIEW

DIRECTLY WITH OPTICAL INSTRUMENTS

CLASS II LASER PRODUCT

0.7mW @800-860nm CW

AVOID DIRECT EYE EXPOSURE

CLASS 3R LASER PRODUCT

5mW@500-670nm CW

Fig 1

1 Bezel 9 VIS Windage Adjustment

2 Body 10 IR Windage Adjustment(DUAL)

3 Adapter Insert 11 IR Elevation Adjustment(DUAL)

4 Clamping Block 12 VIS Elevation Adjustment

5 Locking Screw 13 Battery Compartment Screw

6 Magnetic charging port 14 Battery Compartment

7 Mode Indicator(DUAL) 15 Bottom Activation Buttons

8 Charging Indicator 16 Top Activation Buttons

Charging Indicator

Magnetic charging

port

Mode

Indicator

(DUAL)

3. Do not point the laser beam at reflective surfaces.

4. Do not cover the light head, or place the light head down on the ground

Installation

1. Installation on an Accessory Rail

1) Using the included T10 torx tool, loosen the clamp block in order to install the P.ID

PLUS/DUAL on the accessory rail.

2) Press the head of the clamp screw to open up the rail clamp to it’s maximum width.

Fig 5

We provide a limited lifetime warranty from the date of purchase on parts and

workmanship to the original purchaser. At our sole discretion, we will repair or

replace products found to be defective under normal use without charge, excluding

any delivery costs, which will be born by purchaser. We will not be liable for

incidental, consequential, or special damages arising out of or in any connection

with the use or performance of this product. This warranty is void if the product has

been misused, modified, neglected, or disassembled prior to its return. Please refer

to www.holosun.com for current and complete warranty information and other

conditions.

The P.ID series is a rugged and compact light that is designed to operate in severe

environments. The following tips are provided to ensure a long product life. When

cleaning the lens, ensure it has cooled before any maintenance. Blow away any dust

on the surface, wet the lens with lens cleaner or clean water, then wipe away

smudges with lens tissue, soft cotton or a microfiber cloth. Avoid touching the glass

surface with dry cloth or tissue paper. Do not use organic solvents such as alcohol or

acetone. No special maintenance is needed for the housing surface. Do not try to

dismantle the device as the internal parts are specially cleaned and sealed and with

an anti-fog treatment. Any such attempt will void the warranty.

Fig 7

For more information about Holosun, our Terms of Use and Sale, and our

Phone: 909-594-2888

Fax: (909) 598-4888

Email: warranty@holosun.com

Holosun Technologies Inc.

Ve r: A0

P.ID operation

Zero Setting

Maintenance & care

Fig 4

2) Insert the other adapter into the slot on top of the P.ID PLUS/DUAL and tighten the

adapter screw clockwise .

3) Place the fixed side of the rail clamp against the firearm rail, use the included tool

to turn the clamp screw head clockwise completely until the P. ID PLUS/DUAL is

secured onto the rail and cannot be moved forward or back. See Fig 5

3) Place the fixed side of the rail clamp against the firearm rail

and swing the light into position until the recoil lug of the rail interface insert fully

engages a slot in the accessory rail. Then press the clamp block so that it grabs onto

the rail.

4) Whilepushing forward on the P ID PLUS/DUAL(towardthefirearm muzzle), turn .

the clamp screw clockwise completely untilthe P ID PLUS/DUAL is secured onto the .

rail andcannotbe moved forwardorback S e Fig 4 . .

There are two sets of activation buttons at the rear of the P.ID PLUS/DUAL. The top

b activate activate the . See Fig 6uttons the white light, and bottom buttons laser

1. Constant On:

A short press of either activation button (left or right), will activate

the , depending on mode. A second short press of either activation light and/or laser

button (left or right) will turn the light and/or laser off.

2. Momentary On:

activation Press and hold either button (left or right) for more

than 0.5s, and the and/or laser buttonlight will remain on until you release the

3. Operation mode:

bottompress and hold both the activation buttons

simultaneously for 3s to cycle through + (default), , IR, and WL VIS PLUS DUAL

modes.

a. W + mode: L VIS

the indicator is off, the top buttons LED activate white light, and

the bottom buttons activate VIS laser.

b. P mode: LUS

the indicator is blue, LED all four buttons activate both white light and

VIS laser simultaneously.

c. IR mode:

the indicator is green, LED top buttons are disabled and bottom buttons

activate IR laser only. (P.ID DUAL only)

d. D mode: UAL

the indicator is red, the top buttons LED activate white light and VIS

laser, and the bottom buttons activate IR laser. (P.ID DUAL only)

4) Power Settings:

All P.ID models have high/low power settings

To change the power setting, press and hold the light (top) activation buttons

simultaneously, the P.ID PLUS/DUAL will alternate between high and low power

every one-second.

P.ID PLUS: High Mode output is 900 Lumens/20,000 Candela, Low Mode is 450

Lumens/10,000 Candela.

P.ID DUAL: High Mode output is 800 Lumens/17,000 Candela, Low Mode is 400

Lumens/8,500 Candela.

1. The elevation adjustment screws (U, D) are located on the lower part of the

housing and the windage adjustment screws (L, L) are located on the left and right

sides of the housing (see figure 7). Before leaving the factory, the sight has been

mechanically zeroed to approximately 25 yards.

2. Adjustments can be performed by inserting the flat-tipped end of the included

multi-tool into the slotted adjustment turret and rotating.

3. When adjusting vertically and horizontally, the corresponding relationship

between rotation direction and laser pointer movement is shown in the table below.

The U, D, and L markings reference the point of impact change, not the laser

movement direction.

The maximum adjustment range is 60MOA.±

Caution: If you feel the knobs can no longer be rotated, you may

have reached the mechanical limit of the adjustment turret.

Do not try to rotate the knobs further if you feel a bind or you may cause damage.

Limited Lifetime warranty

Clamp Block

Clamp ScrewH ead

Adapter

Springs

Screw

Top left

button

Top right

button

Bottom left

button

Bottom right

button

Fig 6

2. Selecting the Proper Adapter

The P.ID PLUS/DUAL comes with 2 adapters , Marked

as 1 and 2 respectively. See Fig 5. Both adapters are

meant for any firearms with MIL-STD 1913 or similar rail.

To change out the rail interface adapter the P.ID

PLUS/DUAL must be removed from the accessory rail.

Select the adapter which matches the angle of your

accessory rail.

1) Use the included tool adapterto turn the screw

counterclockwise to remove the adapter screw, then

remove the adapter by pulling is straight out.

Caution:

If the battery voltage is below 2.7V, the sight will shut down automatically after 2s

delay.

Low Battery Warning(P.ID DUAL only): If the battery voltage is below 2.9Vdc, the

laser beam will blink once every 10s.

1.51

Adapter 1

1.75

Adapter 2

Mode Adjuster Direction

Pointer

Movement

VIS

Elevation

Adjusting

(U)

CCW

Down

Windage

Adjusting

(L)

Left

CCW

Right

Elevation

Adjusting

CW Up

CCW Down

Windage

Adjusting

(L)

CW Left

CCW Right

IR Elevation

Adjustment

IR Windage

Adjustment

VIS Elevation

Adjustment

WIS Windage

Adjustment

5) Lockout:

The Lockout function disables all

functions to prevent unintentional light

and/or laser discharges. Triple tap one of

the top activation buttons to activate the

lockout. The white light will blink once

and power off the unit disabling all

buttons. Repeat process to deactivate

the Lockout.

Produkt Specifikationer

Mærke:	Holosun
Kategori:	Ikke kategoriseret
Model:	P.ID Plus

Har du brug for hjælp?

Hvis du har brug for hjælp til Holosun P.ID Plus stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Holosun Manualer

Holosun HE530G Manual

6 Juli 2025

Holosun P.ID Plus Manual

3 April 2025

Holosun HS407C X2 Manual

3 April 2025

Holosun P.ID Dual Manual

3 April 2025

Holosun P.ID HC Manual

2 April 2025

Holosun HS407K X2 Manual

2 April 2025

Holosun P.ID Manual

2 April 2025

Holosun Paralow HS403B Manual

20 November 2024

Holosun AEMS-CORE-120101 Manual

5 September 2024

Holosun HS507C X2 Manual

5 September 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Hozelock 5102 Manual

2 August 2025

ART 310 Manual

2 August 2025

Gorenje KAS53ZDCINVFT Manual

2 August 2025

Gorenje KAS35ZDCINVFT Manual

2 August 2025

Navman MY450LMT Manual

2 August 2025

Navman MiVue 745 Manual

1 August 2025

Hitachi WR22SE Manual

1 August 2025

Synology M2D20 Manual

1 August 2025

Fluke FibertLert-125 Manual

1 August 2025

Buffalo GC882 Manual

1 August 2025
