Side 1/2

1. Battery Installation

1) Remove the bezel/battery cap by unscrewing it in a CCW direction.

2) Inspect the battery compartment for dirt, moisture, or corrosion, and

then clean the battery compartment if needed.

3) Inspect the O-ring seal on the battery cap to make sure that it is free of

sand and dirt particles and that it has not been damaged.

4) Install the battery as marked on the housing, see positive (+) end first (

Fig. 2 Then replace the bezel/battery cap by screwing it in a CW )

direction.

Caution:

When using for the first time, be sure to remove the battery insulation

material.

1) High Power White LED

2) Rechargeable Flat Top 18350 Battery

3) Magnetic Charging Port

4) CNC Milled 7075 Aluminum Housing

5) IP68 Waterproof

6) Rail Interface Adapter

www.holosun.com

User's Manual

WEAPONLIGHT

P.ID 23k Candela

P.ID-HC 42k Candela

System Description

Objective Lens

Features

Battery

Thank you for purchasing the P.ID / P.ID-HC from HOLOSUN. The P.ID

series of weapon lights are compact, yet powerful pistol mounted white

lights that are designed for Positive IDentification of threats in low or no

light conditions. The P.ID attaches to any firearm that uses a MIL-STD

1913 Picatinny rail and includes adapters for universal compatibility.

Before operation, please read the User's Manual carefully:

2. Battery Recharging

1) The recharging voltage is DC5V.

2) Connect the USB end of the charging cable to an external USB power

source, then attach the other end of the magnetic charging cable to the

charging port of the light. (See Fig 3).

I. Red indicator light: charging

ii. Green indicator light: fully charged

Caution:

Do not connect the charger if there is no battery installed.

Do not use attempt to charge a disposable battery

Please keep the charging port clean, wipe any dust off before charging.

The light can only be charged with the included magnetic charging cable.

The P.ID is not compatible with other MCC cables.

Fig 2

The P.ID / P.ID-HC includes a flat top 18350 Li-ion battery which

requires use of the included charging cable or a high quality

charger only. Frequently inspect the condition of the battery,

including the terminals and outer shrink wrap. Do not use a

battery that has any signs of damage, doing so risks injury.

Installation

1 2

1. Ensure the firearm is unloaded and safe by removing all ammunition

and magazines from the firearm and verify an empty chamber before

installation or battery replacement.

DO NOT ATTEMPT TO INSTALL THIS PRODUCT ON A LOADED

FIREARM.

2. Please keep the packaging should you need to make a warranty claim.

Important Notices

1. Component Description

Fig 1

1 Bezel 5 Locking Screw

2 Body 6 Activation Buttons

3 Adapter Insert 7 Charging Indicator

4 Clamping Block 8 Magnetic Charging Port

2. Packaging

The P.ID packaging includes the following items:

1) P.ID Tactical White Light 4) User manual

2) 3 Rail Interface Adapter Inserts 5) T10 Torx Tool

3) USB Magnetic 6) Flat Top 18350 Battery Charging Cable

Battery Cap / Bezel

Battery

Compartment

Battery

O -Ring

Indicator

Magnetic Charging

Port

Fig 3

1. Installation on an accessory rail

1) Using the included tool, loosen the clamp block in order to install the

P.ID onto the rail.

2) Press the head of the clamp screw to open up the rail clamp to it’s

maximum width.

We provide a limited lifetime warranty from the date of purchase on parts

and workmanship to the original purchaser. At our sole discretion, we will

repair or replace products found to be defective under normal use without

charge, excluding any delivery costs, which will be born by purchaser. We

will not be liable for incidental, consequential, or special damages arising

out of or in any connection with the use or performance of this product.

This warranty is void if the product has been misused, modified,

neglected, or disassembled prior to its return. Please refer to

www.holosun.com for current and complete warranty information and

other conditions.

The P.ID is a rugged and compact light that is designed to operate in

severe environments. The following tips are provided to ensure a long

product life. When cleaning the lens, ensure it has cooled before any

maintenance. Blow away any dust on the surface, wet the lens with lens

cleaner or clean water, then wipe away smudges with lens tissue, soft

cotton or a microfiber cloth. Avoid touching the glass surface with dry cloth

or tissue paper. Do not use organic solvents such as alcohol or acetone.

No special maintenance is needed for the housing surface. Do not try to

dismantle the device as the internal parts are specially cleaned and

sealed and with an anti-fog treatment. Any such attempt will void the

warranty.

Fig 6

For more information about Holosun, our Terms of Use and

Sale, and our Privacy Policy, please visit holosun.com.

The P.ID / P.ID-HC has an activation button on each side of the housing.

When a battery is first installed, the product is turned off. S e Fig 6e

1) to activate high mode. Short press either activation button (left or right),

Short press either activation button (left or right) again to power off.

2) and the P.ID Press and hold either activation button for more than 0.5s,

will remain until you release the switch for momentary operation.on

3) Changing between High and Low Modes:

P.ID / P.ID-HC has two intensity modes High and Low :

Press and hold the both activation buttons simultaneously to change

modes. Modes will change every 1s while both buttons are pressed.

P.ID: High Mode output is 1,000 Lumens/23,000 Candela, Low

Mode is 500 Lumens/11,000 Candela.

P.ID-HC: High Mode output is 800 Lumens/42,000 Candela, Low

Mode is 400 Lumens/21,000 Candela.

4) Lockout:

The Lockout function prevents unintentional light discharges.

Triple tap one of the activation buttons to activate the lockout.

Repeat to deactivate the Lockout.

Phone: 909-594-2888

Fax: (909) 598-4888

Email: warranty@holosun.com

Holosun Technologies Inc.

Ver:A 0

P.ID O peration

Limited arrantyLifetime W

Maintenance & areC

3) Place the fixed side of the rail clamp against the firearm rail

and swing the light into position until the recoil lug of the rail interface

insert piece is resting completely in a rail slot. Next, press the clamp block

into position on the rail.

4) While pushing forwardon the P ID towardthe firearmmuzzle turn the . ( ),

clamp screw head clockwisecompletely until the P ID is tightened .

securely and there is no movement S e Fig 4. .

Clamp Block

ClampScrewH ead

Adapter Insert

Springs

Fig 4

2. SELECTING THE PROPER ADAPTER

The P.ID comes with 3 adapters , Marked as 1,2,3 respectively. See Fig 5.

All three adapters are meant for any firearms with MIL-STD 1913 or

similar rail. To change out the rail interface adapter the P.ID must be

removed from the rail.

1) Use the included tool lampscrew head counterclockwise to turn the c

until the clamp block is separated from the clamp screw. Remove the

c taking care not to lose the lamp screw two springs that are on the clamp

block.

2) Test fit each adapter to determine which one positions the P.ID best for

you

3) Put the correct adapter into the slot on top of the light, reinsert the lamp c

screw through adapter and thread it clockwise into the clamp block

the .

4) Place the fixed side of the rail clamp against the firearm rail, use the

included tool to turn the clamp screw head clockwise completely until the

P. ID is secured onto the rail and cannot be moved forward or back. See

Fig 5

Left Activation Button

Right Activation Button

WARNING:

Do not point the P.ID / P.ID-HC directly into human eyes. This may cause

temporary blindness, or permanent damage to the eyes.

Do not cover the light head, or place the light head down on the ground

when the light is on. The radiation energy of the light may cause damage

to the light itself, or even result in burning other materials.

Do not leave the light in any type of fabric bag or fusible plastic container

under high temperature.

CAUTION:

Fully charge the battery before storing the light for a long period of time.

Ensure the light is OFF before performing any type of inspection.
