AC-8014/814 receiver 1 / 2 MJQ51505

The AC-8014/814 receiver

The AC-8014 is a 14-channel receiver of signals from TP-8x wireless

thermostats working on a frequency of 868 MHz. It can also be used

with TP-8x digital bus thermostats. The AC-8014 can efficiently control

multi-zone heating (including thermoelectric actuating valve-drivers to

replace thermostats on radiators) or cooling systems. The receiver has

a special MODE channel which turns the heating to economy mode. It is

designed for heating system control and is not suitable for extending

hardwired alarm systems via wireless detectors.

Due to the maximum current limits of the outputs, pulses switching the

outputs off for short moments are used (when more then 8 outputs are

used). Therefore the AC-8014 should only be used with thermoelectric

actuating valve-drivers. It should not be used to control any relays,

semiconductor switches etc. LEDs on the receiver’s front cover indicate

the status of each output channel.

The AC-8014 can be considered a hybrid of two components: the

AC-814 digital bus receiver and the wireless module. The AC-814 only

allows connection by digital bus and can be supplied standalone as a

cut-down variant of the AC-8014.

The AC-8000R built-in power relay module can be used as a pump

control. A second AC-8000R module can be plugged-in to provide boiler

control. Both relays work with OR logic: they are switched if any of the

1–14 outputs is activated.

Installation

Attach the unit to the desired location with three screws. Route all the

cables to the unit before you tighten the case.

Fix the cables firmly inside the box by a sliding strap.

Note: Only a qualified technician should provide installation and

servicing. The user is not allowed to open the cover and/or make

any modifications. The mains cable must also be fixed outside the

receiver’s case. Replace the mains plug if necessary for your

country.

Terminal description:

AC, AC – power input 24 V AC.

SUM (summer) – input terminal. When switched to ground, economy

mode is activated. This is indicated by the MODE

channel LED lighting.

FRE (freeze) – output terminal. If any of the thermostats sends a

signal about the temperature being under the value

of the ALLo (critically low temperature) parameter in

the thermostat, this terminal switches to ground for

10 seconds. The terminal’s maximum load is

100mA.

BUS,BUS – terminals for the digital bus connection (for

thermostats of the relevant type). Maximum length

of the connection cable is 200m.

1–14 – channel outputs, switchable to ground. The

AC-8014 has pulsed switching.

COM – common positive output terminals 24V DC.

Terminals of the AC-8000R power module:

L_A, N_A, PE_A – power supply input for the circulatory pump or

boiler (use an external fuse for its protection).

L_B, N_B, PE_B – terminals for the circulatory pump or boiler

connection (the L_B terminal is triggered if any of

the 1–14 outputs are switched on).

The receiver is protected against shorts on the output. If the output is

overloaded (the current is greater than 0.4A), then the output is

automatically disconnected. A fault is indicated by rapid red flashing

of the corresponding LED indicator. The output is under constant

monitoring and when the output current decreases below 0.4A the

output will be switched on again.

If it is necessary to have more channels, then it is possible to

connect another unit via a 4-wire cable connected to terminals 1–4. In

this case a single wireless unit should be shared by both receivers.

However, each receiver only controls its own built-in AC-8000R

module.

There is an available connector for an external antenna (e.g. AN-80

or AN-81) on the bottom side of the front housing. If the external

antenna is used no further modifications to settings or connections

are necessary.

Fuse T 400 mA

L_B

N_B

PE_B

L_A

N_A

PE_A

Second module

connection

8000R

Built-in 8000R module

Antenna connection

SUM

FRE

GND

Terminals for

auxiliary signals

Wireless module

Terminals for

digital bus thermostats

Terminals for multiple

AC-8014 wiring

Connecting cable

Pump module connection

Boiler module connection

Terminals 24 V AC

Fuse box

Fuse 3.15A

Channels 1-14

output terminals

Power supply

AC-8014/814 receiver 2 / 2 MJQ51505

Enrollment of thermostats

For each channel of the receiver, a thermostat can be enrolled in the

following way:

• Repeatedly press button < > or (left, right arrow) to select the

desired channel (the current channel will be indicated by its LED

flashing).

• Insert batteries into the thermostat. When powered up, the

thermostat generates an enrollment signal and its code is stored in

the selected receiver channel’s memory.

• Digital bus thermostats can be enrolled by pressing and holding

their button for 5 seconds.

• Enrollment of a thermostat is confirmed by the constant lighting of

the green LED.

Only one thermostat can be enrolled to each channel. A thermostat

can be enrolled to multiple channels or other receivers without any

restrictions (it allows the control of several zones by one thermostat). If

you try to enroll a new thermostat to an occupied channel, the new

thermostat will be stored and the former one will be deleted.

Note: Enrollment codes are stored in non-volatile memory, so power

disconnection will not erase them.

Deleting a thermostat

To delete an existing thermostat:

• Using buttons < > and select the desired channel (the current

channel will be indicated by its LED flashing)

• Press the RES button, the corresponding LED will turn off and the

thermostat is deleted.

Indicators 1–14

Indicators on the front housing of the receiver indicate the status of

the output channels.

LEDs 1 to 14 Meaning

Off Channel is not used (no thermostat is enrolled)

Steady Green Channel has a thermostat enrolled, relay is off

Steady Red Relay is on (activated by the enrolled thermostat)

Flashing Green Communication with the enrolled thermostat is down

(Low battery in thermostat, radio interference etc.)

Flashing Red Enrollment mode (to enroll a thermostat)

Flashing Red

(rapidly) Output is overloaded or short-circuited.

Using the MODE channel / SUM input

The receiver has a special MODE channel to which a JA-8x control

panel (PgX output) or RC-8x remote controls can be enrolled as well

as detectors of type JA-80M. The SUM terminal has the same function

for wired control. This channel can be used for remotely controlling the

mode in which all the outputs will work, switching between two

possibilities: 1) The outputs may be controlled by thermostat signals

demanding/stopping heating 2) The outputs are disabled, but will

respond to freezing alert signals demanding heating. The status of this

channel is shown by the MODE indicator.

Repeatedly press button < or > (left, right arrow) to select the MODE

channel (the current channel will be indicated by its LED flashing, in

this case aim for the MODE LED) and transmit the enrollment signal.

Enrollment of the transmitter is confirmed by the constant lighting of

the green MODE LED.

If no transmitter is enrolled to the MODE channel, then outputs 1-14

react in a normal way to signals from their corresponding thermostats.

If a control panel is enrolled and the PgX output is activated (MODE

indicator lit red) outputs 1–14 react in a normal way to signals from

their corresponding thermostats.

If the PgX output is deactivated (MODE indicator lit green), then

outputs 1–14 are deactivated. They can only be activated in response

to economy temperature signals from a TP-8x thermostat.

MODE indicator

Off The MODE channel is not used – no transmitter is

enrolled (receiver reacts to standard signals from

thermostats)

Steady

Green

A transmitter is enrolled – the MODE channel is

deactivated, (SUM is active)

Outputs 1–14 only react to the economy temperature

signals from thermostats

Steady Red A transmitter is enrolled – the MODE channel is

activated

Outputs 1–14 react to standard signals from

thermostats

Flashing

Green

Communication with the enrolled transmitter is down

(Low battery in transmitter, radio interference etc.)

Use and maintenance

All enrolled transmitters (thermostats and detectors) transmit regular

check signals. If the receiver does not receive the signal of an enrolled

transmitter for a certain period, it will indicate that communication with

this device is down (flashing green LED) and the corresponding output

will turn the heating on for 5 minutes every single hour.

One reason for the lost connection can be low batteries in the

transmitter. The average lifetime of a thermostat’s batteries is about

1 year (JA-8x detectors 3 years). Each transmitter checks its battery

conditions and signals in advance if the batteries are reaching a

critically low state (see the transmitter manual for details).

Another reason for possible connection failure can be radio signal

interference in the operational band of the receiver. In such a case the

receiver will usually indicate loss of communication with a multiple

number of transmitters. In this situation, check if there is any non-

approved or faulty radio-communicating device within the range of the

receiver.

If outputs 1–14 have not been activated for 7 days they will switch on

for 5 minutes to protect connected devices. This is also valid for the

output relay provided by the built-in AC-8000R module thus providing

protection for pumps which can be damaged if they are not used for a

long time. However, this feature is disabled for the boiler connection

established by an additional AC-8000R module.

Warning: the manufacturer is not responsible for any damage caused

by improper installation or any non-suitable use of this product.

Specifications

Power supply: 230 V AC, 50Hz, protection class II

Consumption: 0.02 A stand-by; 0.2 A max.

Max. power supply load 1.7A

Internal load-protection safety fuse F 3.15 A

Max. relay output load: 10 A / 230V

Voltage of outputs 1–14 and COM: 24V DC

Max. load of outputs 1–14: max. 0.4 A per single output

and 1.7A total for all outputs

Radio frequency: 868 MHz

Communication range 100 m (open area)

Dimensions: 258 x 214 x 77 mm

Mechanical resistance: IK08 according to EN 50102

Radio characteristics: ETSI EN 300220

EMC: EN 50130-4, EN 55022

Safety: EN 60950

Enclosure: IP30 (EN 60529)

Operational temperature: -10 to +40

Can be operated according to ERC REC 70-03

JABLOTRON ALARMS a.s. hereby declares that the

AC-8014/AC-814 is in compliance with the essential

requirements and other relevant provisions of Directive

1999/5/EC. The original of the conformity assessment can

be found on the web site www.jablotron.com , Technical

Support section.

Note: Although this product does not contain any harmful

materials we suggest you return the product to the dealer or

directly to the manufacturer after use.

Produkt Specifikationer

Mærke:	Joblotron
Kategori:	Overvågningskamera
Model:	AC-814

Har du brug for hjælp?

Hvis du har brug for hjælp til Joblotron AC-814 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Overvågningskamera Joblotron Manualer

Joblotron H-915 Manual

13 Maj 2024

Joblotron JA-60 Manual

18 April 2024

Joblotron JA-63E Manual

17 April 2024

Joblotron SP-02 Manual

6 April 2024

Joblotron GS-130 Manual

6 April 2024

Joblotron UC-230 Manual

1 April 2024

Joblotron UC-261 Manual

27 Marts 2024

Joblotron JA-60M Manual

6 Marts 2024

Joblotron JA-80A Manual

6 Marts 2024

Joblotron JK-16 Manual

6 Januar 2024

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

FLIR Ariel CM-3505 Manual

29 Juli 2025

Axis Q6355-LE Manual

29 Juli 2025

Sony SNC-EMX52R Manual

29 Juli 2025

Hikvision DS-2CD3086G2H-LIU Manual

29 Juli 2025

Hikvision DS-2DF1-402 Manual

28 Juli 2025

Hikvision DS-9116HFI-S Manual

28 Juli 2025

Sony SNC-EM632RC Manual

28 Juli 2025

Hikvision iDS-UC4P Manual

28 Juli 2025

Hikvision DS-2AE4215TI-A Manual

28 Juli 2025

Hikvision DS-UAC-S2P Manual

28 Juli 2025
