UC-280 wireless interface 1 / 2 MFT51208

UC-280 Wireless Interface

The UC-280 is an 8-zone interface linking JA-60 wireless detectors

with hard-wired security control panels. It can also send triggering

signals to a JA-60A wireless outdoor siren and/or UC-216 and UC-222

universal receivers. Additionally, it can receive signals from Jablotron

RC-xx remote controls. If necessary, UC-282 expander modules can

be used to increase the number of zones up to 40.

Speciﬁcation

Power 12 V DC (10.5 V – 16.0 V)

Power consumption typ. 50 mA (all relays off)

max. 100 mA

Zone outputs Z1-Z8 8x optoMOS relays 100 mA / 60 V

with COM1 common terminal

Outputs 3x optoMOS relays 100 mA / 60 V

Tamper NC with COM2 common terminal

Fault, Battery NO with COM2 common terminal

X, Y and Siren inputs activated

when switched to GND (filter 0.2

sec., 1 V DC triggering level)

Operating frequency 433.9 MHz

Working range with JA-60 100 m (open area)

Working range with RC 30 m (open area)

Working environment indoor use (class II, EN 50131-1)

Operating temperatures -10 °C to +70 °C

Operating humidity max. 90 %

Dimensions 188 x 135 x 40 mm

Weight 800 g

Hereby, Jablotron Ltd., declares that this UC-280 is in compliance with

the essential requirements and other relevant provisions of Directive

1999/5/EC. Original of the conformity assessment can be found at the

web page www.jablotron.cz, section Technical support.

Note: Although this product does not contain any harmful materials we

suggest you to return the product to the dealer or directly to the

producer after usage.

Purchase package contains: electronic board, metal case, antenna,

screws, dowels, and manual.

Installation

The UC-280 is an electronic module built-in to a metal case

(protected by a tamper switch). The case should be installed on a wall

with its antenna in a vertical position. The device should not be

installed close to any metal structures or other objects obstructing radio

signal transmission.

Route the wires through the hole in the rear part of the housing.

Attach the case to the desired place using the provided screws.

Connect the antenna.

Terminals:

Z1-Z8 Zone 1-8 output relays’ contacts, max. 100 mA / 60 V, pulse

length can be set by 1s/3s jumper, normally closed or

normally opened mode is selected by the NO/NC jumper

COM1 common terminal of Z1-Z8 relays

TMP tamper relay output (tamper signal from wireless detectors,

a wireless siren and the UC-280 tamper switch), max.

100 mA / 60 V

BAT low battery relay output (low battery signal from wireless

detectors 1-8 or a wireless siren), max. 100 mA / 60 V

TRB trouble relay output (trouble signal from wireless detectors

1-8 or a wireless siren - e.g. lost communication), max.

100 mA / 60 V

COM2 common terminal of TMP, BAT and TRB relays

GND power supply ground terminal

SIR triggering input for activation of JA-60A wireless siren (the

siren sounds as long as this input is closed to GND, max.

15 minutes)

X input, which can trigger relay X of a UC-216 or UC-222

universal receiver when switched to GND

Y input, which can trigger relay Y of a UC-216 universal

receiver when switched to GND

OUT input, which can trigger output OUT of a UC-216 universal

receiver when switched to GND

+12V power voltage terminal

UC-280 wireless interface 2 / 2 MFT51208

Connectors:

OUT data connector for UC-282 expander module

ANT AN-01A external antenna connector (when AN-01A is used,

the rod antenna must be disconnected)

Setting buttons:

LEARN if this button is briefly pressed, you can scroll through the

learning modes of Z1-Z8 zones and a wireless siren SIR (a

selected channel is indicated by a red flashing LED). When

this button is pressed for more than 3 sec., the enrolling

signal for a UC-216 / UC-222 receiver will be transmitted

(learning mode of Z1-Z8 and SIR must be closed first)

RESET if this button is briefly pressed, the learning mode of a

selected zone will be closed. When this button is pressed for

more than 3 sec., a selected zone will be deleted (confirmed

by flashing of the TMP, BAT and TRB indicators). When this

button is pressed for more than 6 sec., all zones will be

deleted (confirmed by flashing of all indicators). Note, in

order to delete all zones, a learning mode of any zone must

be selected first.

Jumpers:

1s / 3s pulse length of 1 sec. or 3 sec. of Z1-Z8 output relays

NO / NC normally closed or normally opened mode of Z1-Z8 output

relays (TMP, BAT and TRB are normally closed)

Supervision - Regular checking of wireless detectors’ communication

can be disabled (NO SUPERVISION position). This setting

is recommended in places with radio interferences. When

the supervision is enabled, lost communication will trigger

the TRB output relay.

Indicators:

POWER The green LED indicates the presence of the power supply

Z1 - Z8, LED lights green when zone is occupied;

LED lights red when zone detector is triggered;

LED flashes red, when zone is in a learning mode;

LED flashes red together with the TMP, BAT or TRB LED =

tamper, low battery or trouble signal in zone

TMP tamper alarm – flashes together with a corresponding zone

indicator every 3 sec.

BAT low battery - flashes together with a corresponding zone

indicator every 3 sec.

TRB trouble or lost communication - flashes together with a

corresponding zone or SIR indicator every 3 sec.

Enrolling of wireless components

Enrolling of detectors

• Scroll to a desired zone Z1-Z8 using the LEARN button

• JA-60 detectors will be enrolled by inserting their batteries or

switching on a power supply

• Successful learning is indicated by the red LED

• If you enroll a component to a new zone, it will move from its

previous position

• Only one detector can be enrolled to each zone

Enrolling of remote controls

• Scroll to a desired zone Z1-Z8 using the LEARN button

• RC-xx remote controls will be enrolled by pressing a button (while in

pulse mode). Button A, B or double press can be enrolled.

• RC-11 or RC-22 Remote controls can be enrolled to any zone in an

ON/OFF mode by pressing both buttons and keeping them pressed

for more then 5 sec. After this the corresponding relay will switch on

when the A button is pressed, and off, when the B button is pressed.

• If a combination of double press and ON/OFF mode is required, the

ON/OFF mode must be enrolled first.

• Successful learning is indicated by the red LED

• If you enroll a remote control to a new zone, it will move from its

previous position

• Only one remote control can be enrolled to each zone

Enrolling of a wireless siren

• Connect a battery in a JA-60A siren and power its adapter

• Select the SIR position with the LEARN button

• When the SIR position is selected, the UC-280 will send a learning

signal to the JA-60A and vice versa. Triggering the SIR input will

then activate a JA-60A, tamper alarm or power supply failure of the

JA-60A will be transmitted to a UC-280

• Only one JA-60A siren can be used with a UC-280

Enrolling of UC-216 or UC-222 modules

SIR • Select the learning mode in a receiver (mode X1 for UC-216 or

mode 4 for UC-222)

• Learning mode of UC-280 must be closed

• Press and hold the LEARN button in UC-280 for 3 seconds

• The UC-280 will now be enrolled to the UC-216 or UC-222 receivers

and triggering of X and Y inputs will trigger the UC-216 / UC-222

output relays.

• Unlimited number of UC-216 / UC-222 can be used with a UC-280

Erasing components

If you want to delete any item from a UC-280, use the RESET button

(the procedure is described in “Setting buttons” paragraph).

Extension for more zones

When 8 zones are not enough, you can use UC-282 expander

modules. Each UC-282 module provides additional 8 zones. A

maximum of 4 expanders can be used with UC-280. Modules are

interconnected using the IN and OUT connectors, wiring should not

exceed 1 meter. Each UC-282 must be powered by 12 V DC

separately.
