UC-282 expanding module 1 / 2 MFT51804
UC-282 Expanding Module
The UC-282 is designed to expand a number of wireless zones of
UC-281 or UC-282 wireless interface. It provides additional 8 zones
interface linking JA-60 wireless detectors or RC-xx remote controls
with hard-wired security control panels.
The UC-282 cannot be used independently, as it is not equipped
with receiver or transmitter module.
Up to 4 UC-282 expander modules can be used to increase the
number of zones of UC-281 or UC-282.
Specification
Power 12 V DC (10.5 V – 16.0 V)
Power consumption typ. 50 mA (all relays off)
max. 150 mA
Zone outputs Z1-Z8 8x optoMOS relays 100 mA / 60 V
with COM1 common terminal
Outputs 3x optoMOS relays 100 mA / 60 V
Tamper NC with COM2 common terminal
Fault, Battery NO with COM2 common terminal
Working environment indoor use (class II, EN 50131-1)
Operating temperatures -10 °C to +70 °C
Operating humidity max. 90 %
Dimensions 188 x 135 x 40 mm
Weight 800 g
Complies with the essential requirements of: 89/336/EC EMC Directive -
Protection concerning electromagnetic compatibility when is used for its
intended purpose. Original of the conformity assessment can be found at
the web page www.jablotron.cz, section Technical support.
Note:
Although this product does not cont
ain any harmful materials we
suggest you to return the product to the dealer or directly to the
producer after usage.
Purchase package contains: electronic board, metal case, screws,
dowels, and manual.
Installation
The UC-280 is an electronic module built-in to a metal case
(protected by a tamper switch). The case should be installed on a wall
close to UC-281 or UC-282 master module. The device should not be
installed close to any metal structures or other objects obstructing radio
signal transmission.
Route the wires through the hole in the rear part of the housing.
Attach the case to the desired place using the provided screws.
Connect the tamper switch.
Terminals:
Z1-Z8 Zone 1-8 output relays’ contacts, max. 100 mA / 60 V, pulse
length can be set by 1s/3s jumper, normally closed or
normally opened mode is selected by the NO/NC jumper
COM1 common terminal of Z1-Z8 relays
TMP tamper relay output (tamper signal from wireless detectors,
a wireless siren and the UC-280 tamper switch), max.
100 mA / 60 V
BAT low battery relay output (low battery signal from wireless
detectors 1-8 or a wireless siren), max. 100 mA / 60 V
TRB trouble relay output (trouble signal from wireless detectors
1-8 or a wireless siren - e.g. lost communication), max.
100 mA / 60 V
COM2 common terminal of TMP, BAT and TRB relays
GND power supply ground terminal
+12V power voltage terminal
TAMPER a pair of terminals used for the connection of the case
tamper switch
Connectors:
IN data connector for UC-280 or UC-281 wireless interface
OUT data connector for additional UC-282 expanding module
Setting buttons:
LEARN if this button is briefly pressed, you can scroll through the
learning modes of Z1-Z8 zones (a selected channel is
indicated by a red flashing LED).
RESET if this button is briefly pressed, the learning mode of a
selected zone will be closed. When this button is pressed for
more than 3 sec., a selected zone will be deleted (confirmed
by flashing of the TMP, BAT and TRB indicators). When this
button is pressed for more than 6 sec., all zones will be
deleted (confirmed by flashing of all indicators). Note, in
order to delete all zones, a learning mode of any zone must
be selected first.
UC-282 expanding module 2 / 2 MFT51804
Jumpers:
1s / 3s pulse length of 1 sec. or 3 sec. of Z1-Z8 output relays
NO / NC normally closed or normally opened mode of Z1-Z8 output
relays (TMP, BAT and TRB are normally closed)
Supervision - Regular checking of wireless detectors’ communication
can be disabled (NO SUPERVISION position). This setting
is recommended in places with radio interferences. When
the supervision is enabled, lost communication will trigger
the TRB output relay.
Indicators:
POWER The green LED indicates the presence of the power supply
Z1 -
Z8,
LED lights green when zone is occupied;
LED lights red when zone detector is triggered;
LED flashes red, when zone is in a learning mode;
LED flashes red together with the TMP, BAT or TRB LED =
tamper, low battery or trouble signal in zone
TMP tamper alarm – flashes together with a corresponding zone
indicator every 3 sec.
BAT low battery - flashes together with a corresponding zone
indicator every 3 sec.
TRB trouble or lost communication - flashes together with a
corresponding zone or SIR indicator every 3 sec.
Enrolling of wireless components
Enrolling of detectors
• Scroll to a desired zone Z1-Z8 using the LEARN button
• JA-60 detectors will be enrolled by inserting their batteries or
switching on a power supply
• Successful learning is indicated by the red LED
• If you enroll a component to a new zone, it will move from its
previous position
• Only one detector can be enrolled to each zone
Enrolling of remote controls
• Scroll to a desired zone Z1-Z8 using the LEARN button
• RC-xx remote controls will be enrolled by pressing a button (while in
pulse mode). Button A, B or double press can be enrolled.
• RC-11 or RC-22 Remote controls can be enrolled to any zone in an
ON/OFF mode by pressing both buttons and keeping them pressed
for more then 5 sec. After this the corresponding relay will switch on
when the A button is pressed, and off, when the B button is pressed.
• If a combination of double press and ON/OFF mode is required, the
ON/OFF mode must be enrolled first.
• Successful learning is indicated by the red LED
• If you enroll a remote control to a new zone, it will move from its
previous position
• Only one remote control can be enrolled to each zone
Erasing components
If you want to delete any item from a UC-282, use the RESET button
(the procedure is described in “Setting buttons” paragraph).
Extension for more zones
When 8-zone extension is not enough, you can use additional
UC-282 expanding modules. Up to 4 UC-282 can be used with one
UC-280 or UC-281. Modules are interconnected using the IN and OUT
connectors, wiring should not exceed 1 meter.
Internet: www.jablotron.cz
Tel.: +420 483 559 999
fax: +420 483 559 993
Pod Skalkou 3 3
46 6 01 Jablonec nad Nisou
Czech Republic
