Side 1/4

936.3395/A/0110/1.4e/ZWT

VOS 32/F 20910020

VOS 40/F 20910012

VGR 28/30 20910008

VGR 28/65 20910009

House connection ampliﬁ er

Return path ampliﬁ er

QHouse connection ampliﬁ er for modern HFC networks

QBuilt-in power supply

QDie-cast housing with F-type connectors

QLED to indicate operation mode

QVariable interstage gain setting using on-board plug-in attenuators

(delivery condition: with interstage attenuation)

QThe maximum operation levels are also valid for operation with

interstage attenuation

QInterstage equaliser (6 dB) connectable with bridging plugs

(pre-emphasis)

QReturn path optional, individually ﬁ ttable:

5-30 MHz mit VGR 28/30

5-65 MHz mit VGR 28/65

(delivery condition: without return path ampliﬁ er, with null bridges)

QIntegrated variable attenuator and adjustable equaliser

QTest socket on output -20 dB (with directional coupler)

QTest socket on input -20 dB (connectable with bridging plug)

for return path levelling

QConforms to: EN 60728-11, EN 50083-2 and EN 60065

QFor indoor installation

House connection ampliﬁ er

The ampliﬁ er complies with the requirements in the EMC Directive 2004/108/EC and Low-Voltage Directive 2006/95/EC applicable

at the time of shipping

Dimensions and Installation

Only to be undertaken by authorised personnel

Unplug from the mains before installation. The safety regulations in accordance with EN 60728-11 and EN 60065 are to be

observed!

a) Clearances to containing surfaces: 150 mm≥

b) Clearances to containing surfaces: 50 mm≥

Permissible installation

Caution!

Do not install on ﬂ ammable materials!

6.5 mm

House connection ampliﬁ er

F-type socket 4x

Connection dimensions acc.

to IEC 61169-24

Potential equalisation

Clamping range 4...6 mm2

Mains power cable

63.5 mm

House connection ampliﬁ er

Output

Input

Output

Technical data

According to EN 60728-3; CENELEC raster 42 carriers, the level values also apply for interstage attenuation

2) According to EN 60728-3 (category C); as of 40 MHz => 14 dB -1.5 dB/octave, but => 10 dB

3) As of serial number G1B38xxxxxx

Type VOS 32/F VOS 40/F

Order no. 20910020 20910012

Forward path

Frequency range MHz 47 (85)-862 47 (85)-862

Gain (switchable) dB 26/32 34/40

Amplitude deviation dB ± 1.5 ± 1.5

Setting range variable attenuator dB 0-20 0-20

Setting range equaliser dB 0-20 0-20

Setting range Interstage attenuation

(switchable with bridging plugs) dB 0/6 0/6

Setting range Interstage equaliser

(switchable with bridging plugs) dB 0/6 0/6

Maimum operating level 1) (60-dB CTB/CSO)

- ﬂ at

- with 6 dB interstage pre-emphasis

dBµV

100/100

102/102

104/110

107/110 3)

Recommended operating level 1) (66-dB CTB/66-dB CSO)

- ﬂ at

- with 6 dB interstage pre-emphasis

dBµV

105/105 3)

Noise ﬁ gure (Interstage attenuation 6/0 dB) dB 7/6 7/6

Number of outputs 1 1

Return path

See data of VGR 28/xx See data of VGR 28/xx

General

Impedance input/output 75 75Ω

Return loss input/output ²) dB 14 14

RF connections F-type connector F-type connector

Test socket output with directional coupler (5-862 MHz) dB -20 -20

Test socket output return path (5-65 MHz) dB -20 -20

Nominal input voltage VAC 230 230

Power consumption (without/with return path ampliﬁ er) W 4/5 6/7

Operational display LED green LED green

Protection class II II

Protection category (to EN 60529) IP 50 IP 50

Temperature range °C -20 to +55 -20 to +55

Dimensions mm 184 x 134 x 63 184 x 134 x 63

Packing unit/weight pc./kg 1 (10)/1.7 1 (10)/1.4

Basic safety precautions

Caution!

The ampliﬁ er supply voltage is 230-V AC

and is dangerous on direct physical contact!

• Do not touch live parts

• The power plug must be easily operable as the means of cutting power to the ampliﬁ er,

i.e. the wall outlet must be close to the ampliﬁ er and easily accessible

• The power must be cut when installing or removing the ampliﬁ er

• Do not operate the ampliﬁ er if the standard power supply protective cover is not ﬁ tted.

936.3395/A/0110/2.4e/ZWT

Produkt Specifikationer

Mærke:	Kathrein
Kategori:	TV signal forstærker
Model:	VOS 32/F
Kode for international beskyttelse (IP):	IP50
Vægt:	1700 g
Produktfarve:	Metallic
Strømforbrug (typisk):	5 W
Driftstemperatur (T-T):	-20 - 55 °C
Dimensioner (BxDxH):	184 x 134 x 63 mm
Beskyttelsesklasse:	II
Indgangsspænding:	198 - 252 V
Stik:	F
Indgangsfrekvens:	50 Hz
Forstærkning:	26 dB
Porte, antal:	1
Frekvensområde (fremføringsvej):	47 - 862 Mhz
Frekvensområde (returvej):	5 - 65 Mhz
Støjtal:	6 dB
