One of the hardest problems to overcome in a high power car stereo

system is providing the tremendous amount of current necessary to feed high

power amplifiers. This is especially critical in subwoofer amplification.

Stillwater Designs engineers have met this challenge with the new DX-Series

amplifiers. Thanks to Class D circuitry, the average current draw is much lower

than with the conventional amplifier designs. Your new KICKER mono block

subwoofer amplifier creates the massive power you need for optimal

subwoofer performance with much less demand on your vehicle's charging

system than with a conventional amplifier. It also provides a full complement

of features you need for ultimate control of your subwoofer system.

FEATURES & CONTROLS

• Class D switching amplifier for maximum efficiency

• 18dB per octave low pass output filter for better noise rejection

• Maximum power at 2 Ohms on the DX700 and DX350, 1 Ohm on the

DX1400

• Fully regulated power supply for rated output in real-world conditions

• Four-layer printed circuit boards for high current capabilities (DX700

and DX1400)

• Superior output circuit magnetics for better noise rejection

• 24dB per octave switchable subsonic filter @ 25Hz,

• Built-in remote gain control circuitry - under-dash remote gain

controller included

• SWX two-way active electronic crossover module in

Module Docking Port

• Protection circuitry - short circuit protection, reverse polarity

protection, over voltage protection, thermal protection

• Silent turn on/off circuitry eliminates speaker damaging “thump”



DX1400, DX700, DX350

Class D Subwoofer Amplifiers

WIRING INSTRUCTIONS

WARNING- Shock Hazard: This series of Class D amplifiers has high voltage DC present

on the speaker terminals any time the amplifier is turned on. Avoid contact with the

speaker connectors and wiring while the system is operational.

IMPORTANT SAFETY NOTES: Never make any wiring connections with power applied to the

system. The risk of damage to components is very high. All power and speaker

connectors will accept up to 8 gauge wire with these exceptions: DX700 and the DX1400

power and ground connections are designed for 4 gauge. Although the average current

draw on the Class D amplifier is lower, the peak demand is about the same as for a

conventional amplifier. It is very important that the screws in the amplifier's terminal strips

are very tight. An allen wrench is included for this purpose. Always make the ground

connection first when installing this amplifier and disconnect ground last when removing it

from the system.

Connect the ground wire, which is 24 inches or less, to a structural chassis member.

Be sure the connection is to bare metal and securely screwed or bolted. (It is not

recommended to run the ground wire to the battery). Check the factory ground wire at

the battery. Besides the large wire going to the engine block, there should be a smaller

wire going from the battery negative to the body of the vehicle. If this wire is smaller than

the recommended power wires shown below, then this ground wire needs to be enlarged.

Run a positive wire of the size shown below directly to the positive terminal of the battery

and use a fuse of appropriate size within 18 inches of the battery. This fuse protects the

wire run from the battery.

Please refer to wire gauge selection chart below for minimal loss at full rated power

under test conditions:

Model Up to 10 feet 10-20 feet

DX1400 2ga. 0ga.

DX700 4ga. 2ga.

DX350 8ga. 4ga.

Inline fuse values (used at the battery):

DX1400 = 150A (supplied with amp).

DX700 = 90A

DX350 = 50A

When running the signal (RCA) cables, keep them away from all power wires in the

vehicle to avoid noise. If a signal cable must cross power wires, try to make the junction at

90 degrees. This will have the least chance of picking up noise.

Note: In the case where the recommended wire size is larger than the

amplifier's connector, it may be necessary to use a power distribution block or

inline connector to adapt down to the size your amp will accept.
