Side 1/75

P/N: 2900-301628 Rev 1 www.kramerav.com

USER MANUAL

MODEL:

KIT-500

5x2 Matrix/Scaler Kit

Kramer Electronics Ltd.

KIT-500 – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  4
Defining KIT-500 5x2 Matrix/Scaler Kit  5
Defining KIT-500T  5
Defining KIT-500R  7
Mounting KIT-500  9
Connecting KIT-500  10
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor  12
Connecting to KIT-500 via RS-232  12
Connecting an Occupancy Sensor to the TOGL Pin  12
Connecting to USB Hosts  13
Wiring RJ-45 Connectors  13
Principles of Operation  14
KIT-500T Input Auto-Switching  14
USB Host Switching  14
CEC Signaling  15
Control via RS-232 Ports  15
Operating and Controlling KIT-500  16
Using Front Panel Buttons  16
Using Remote Control Switches  17
Controlling and Operating Via the OSD Menu  17
Operating via Ethernet  24
Using Embedded Web Pages  27
Routing Inputs to Outputs  29
Setting Audio Video Parameters  29
Managing KIT-500T EDID  35
Defining KIT-500T General Settings  37
Defining Network Settings  39
Managing RS-232 Control  40
Defining Advanced Settings  43
Setting Authentication  47
Viewing the About Page  50
Upgrading Firmware  51
Technical Specifications  52
Default Communication Parameters  54
KIT-500R Output Resolution Support  54
Input Resolution Support  54
Default EDID  55
Protocol 3000  57
Understanding Protocol 3000  57
Protocol 3000 Commands  58
Result and Error Codes  70
