Side 1/3
Installation
Instructions
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT — Save these instructions
for local inspector’s use.
• IMPORTANT — Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note – The flush-mounted cooktop must be
properly grounded.
FOR YOUR SAFETY
Review all Safety, Power Requirements,
Dimensions and Clearances and Preparation of
the cutout opening instructions in the Installation
Instructions included with your cooktop.
NOTICE — Read all instructions thoroughly,
PRIOR to beginning any work. Actual product
dimensions may vary due to manufacturing
tolerances.
WARNING To avoid the risk of property
damage, the cutout should be made by a professional
cabinet installer.
WARNING Do not attempt to flush-mount
any cooktop counter unit that requires a down draft
ventilation system.
WARNING Installer must ensure that the
counter is capable of holding at least 300 lbs. once
the cooktop has been flush mounted.
JXFLUSH1
Cooktop Flush-Mount Kit
KIT INCLUDES
• Installation Instructions
• (2) 60” long 3/4” wide one sided foam tape
• (2) 130” long 3/4” wide one sided Teflon tape
• Hold Down Bracket Hardware:
(2) hold down bracket
(2) 3/8” long 1/4” hex head screw
(2) 2 1/2” long thumb screw
MATERIALS YOU WILL NEED
• High-temperature sealant meeting the following
requirements:
- Only certain models may be installed over wall
ovens. The wall oven and cooktop will both have
a label stating which models are approved in
combination.
- 100% Silicone
- Temperature rating – 400°F minimum
- Tack free time – 30 minutes minimum
- Recommendation:
GE SUPREME 100% Silicone “CLEAR”
• Caulking tool(s) to shape/finish the silicone bead.
• 2 Heavy duty suction cups, each rated for 100 lbs.
minimum.
• Masking tape
• Measuring tape
• Pencil
• Scraper
CUTTING THE COUNTERTOP
If you are installing the cooktop in a solid surface
material such as granite, quartz or any other natural
or synthetic solid surface, we recommend that the
flush-mount cutout be prepared by a professional
cabinet or countertop installer.
Cooktop cutouts in wood or wood-laminate
countertops may be able to be prepared using a 1½
HP (minimum) router and carbide router bit.
If you have questions, call GE Appliances at 800.GE.CARES (800.432.2737)
or visit our website at: GEAppliances.com.
31-11024 09-16 GEA
231-11024
Installation Instructions
1. Initially prepare the cutout as per the installation
instructions that were supplied with your cooktop.
IMPORTANT: Prior to final installation of the unit
in the flush-mount cutout using the silicone caulk,
temporarily make all wiring connections and
check the unit per the installation instructions to
ensure it is working properly. The unit should be
re-wired and re-checked for correct working upon
final installation.
2. Use a pencil and measuring tape to prepare the
cutout area by marking it off per the dimensions
on page 4.
3. The cutout must be made to a maximum depth of
ó´DQGVKRXOGDOZD\VOHDYHDWOHDVWDǩ´JDSDOO
around the edge of the cooktop.
IMPORTANT: To ensure sufficient support for the
cooktop while cooking, reinforcing strips of wood
or solid surface material must be secured in place
below the edge of the cutout (see illustration).
Ensure sufficient support is provided in all
necessary locations on the countertop. Follow all
countertop manufacturer installation instructions.
WARNING Failure to provide adequate
countertop reinforcement for cooktop may result
in damage to unit when weight is added to
cooktop during cooking.
INSTALLING THE COOKTOP
4. Vacuum dust and other particles from the cooktop
cutout.
5. Apply the black foam tape provided in the kit to
the top of the rabbeted edge of the countertop,
flush with the outer edge of the rabbet (see
picture in step 3.) The foam tape will keep the
silicone sealant from seeping between the
countertop and the underside of the cooktop.
Make sure the foam tape does not overlap - it
needs to be a single thickness for proper spacing.
6. Apply the Teflon tape to the underside of the
cooktop flush with the outside edge of the glass
and partially covering the metal flange (see picture
in step 3.) Trim the Teflon tape at the corners of
the cooktop to match the curve of the glass. The
Teflon tape will keep the silicone sealant from
seeping between the glass and the metal.
7. Install the hold-down brackets provided in the kit
onto the cooktop (both sides). DO NOT TIGHTEN
YET. Turn the brackets inwards to avoid
interference when dropping the cooktop into the
countertop. The baffle supplied with the cooktop
needs to be attached as well, unless the cooktop
is being installed over a single wall oven.
Baffle
Screws
Bottom of Cooktop
Foam tape
(Compressed)
Ensure cooktop sits
on the metal flange
on all four sides
Countertop
Teflon tape
Glass
Silicone Caulk
Reinforcing strip
Cooktop burner box
1/4”
Max.
1/8” Min.
