Side 1/2
© MuxLab Inc. - -A94 000795
8495 Dalton Rd, Montreal, Quebec, Canada. H4T 1V5
Tel: (514) 905-0588 Fax: (514) 905- 0589
Toll Free (North America): (877) 689- 5228
E-mail: videoease@muxlab.com URL: www.muxlab.com
Specications
Environment
Digital Audio
LPCM, Dolby Digital® 5.1, DTS, and Dolby® True HD
Input / Output signal
S/PDIF coax cable or TOSLINK optic cable, input selectable.
Sampling rate
Up to 96kHz/24bits
Maximum distance between
unit
50 150 ft. ( 0m)
Connectors
RCA, TOSLINK, POWER, RJ45 on each unit.
Power requirement
1W max, 5V DC
S/PDIF spec
Coax 75 ohm with RCA connector ,
level: 500mVp-p into 75 ohm
TOSLINK spec
Plastic optic cable with EIAJ/JEITA RC- C connector 5720 ,
Wavelength: red 66 level: -0nm, 15dBm max.
Cabling Requirement
(not supplied)
Any 4-pair straight cable C 5/5E/6 with RJ- connector. AT 45
Coax and second Optic Cable.
Included in this kit
1 x unit 1 x unit 1 x 5V Power supply, TX , RX ,
1 x Optic Cable 3ft (1m) and 1 x Installation guide.
RJ45 Pin Conguration
Pair 4+5 (data), 1+2+7(+5V), 3+6+8(0V)
Compatible mounting
hardware
500902, 500900, 500910, 500915
Temperature
Operating: -40° to (- ° to 1 ° 85°C 40 85 F)
Storage: - ° to °C (- ° to 1 °F) 40 85 40 85
Humidity
Maximum 95% (non-condensing)
Enclosure
ABS UL94HB re retardant plastic
Dimensions
2.25” x 2.25” x 1.0” x 6 x 2.5 cm each box. (6 )
Shipping Weight
1 lb. (450g)
Warranty
2 Years
Order Information
500 860 Digital Audio Extender
DIGITAL AUDIO EXTENDER KIT
500086
Quick Installation Guide
Overview
The Digital Audio Extender allows one (1) source of digital audio signal: coax (S/PDIF)
or optic (TOSLINK) to be connected to a receiver: coax or optic up to 5 ft. ( 0m) to 00 15
in a - -point conguration. The Extender supports most standards transmit two point to to
channels of uncompressed lossless PCM audio or compressed 5.1/7.1 surround sound,
such as Dolby Digital Plus or DTS-HD High Resolution Audio (multichannel digital
audio Dolby Digital® 5.1, DTS, and Dolby® True HD).
Applications
Transmission of Digital Audio Signal
© MuxLab Inc. 2015
Installation
One source unit can be connected to one receiver unit using a CAT5/6 cable. To install
the unit, perform the following steps:
Caution: Do not attempt to open the housing. There are no user-serviceable parts
inside the unit. Opening the unit will void your warranty.
Do not connect the unit to a telecommunication outlet wired to unrelated
equipment. Making such a connection may damage the equipment and/or
the unit. Verify that the desired twisted pairs are not being used for other
LAN or telephone equipment.
1. Use a dedicated 4-pair Cat5e/6 cable between the source and the receiver unit.
2. Patch panels are compatible.
3. Verify the wiring is “straight-through”, s 4 twisted pairs and s the standard Ethernet ha ha
RJ45 connector.
4. Connect the 5V power supply to one side only. Any side can be used.
5. by Connect the unit to the audio source, either coax source or optic. On the source
side, select which type of input is used. Both sides can be connected but only one is
used to transmit audio. At the receiver side both outputs will contain the same
signal. Note that some AV system may require that you connect only one signal.
Troubleshooting
The following tables describe some of the symptoms, probable causes and possible solutions regarding
the unit:
Symptom
Probable Cause
Possible Solutions
No audio
No signal from source
Source o.
Power missing. Check led.
Check continuity on all pair.
Check if pairs are not swapped.
Check if the four pairs are present.
Malfunctioning unit.
Intermittent audio or
no audio
Cable too long
If you still can t diagnose the problem, please call MuxLab Customer Technical Support at ’
877 689 905- -5228 (toll-free in North America) or (+1) 514- -0588 (International).
