Side 1/5

Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-XPR-5590-MH-19

02-21-2019

Instruction Manual

XPR-5590

Please read these instructions before using your Nightstick XPR-5590

They include important safety information and operating instructions.

Model XPR-5590

with Case and Tripod

CLASS I DIV 2 GRPS A-D T3

CLASS II & III DIV 2 GRPS F-G T135°C

CLASS I ZONE 2 Group IIC T3

-20ºC ≤ Tamb ≤ +40ºC

7.4V/Cell 1514-BATT

Bayco Products, Inc. XPR-5590

ID 4001184

640 S. Sanden Blvd., Wylie, TX 75098

WARNING: Risk of ignition - Do not open in a hazardous area.

AVERTISSEMENT: Ne pas ouvrir dans une zone dangereuse.

WARNING: Risk of ignition - Do not charge batteries in a hazardous area.

AVERTISSEMENT: Danger d’inflammation - Ne pas charger les piles dans une

zone dangereuse.

WARNINGS - INTRINSICALLY SAFE

y Warning: To prevent ignition of a hazardous atmosphere, do not attempt to charge

this product in the hazardous environment. This task must ONLY be performed in an

area known to be non-hazardous.

y Warning: Lithium-ion batteries must be used and charged properly. Improper use

can result in serious injury, re, or death.

y Warning: Use only the included and approved 1514-BATT rechargeable battery pack

from Bayco Products.

y Warning: When exchanging the rechargeable battery pack, use only the approved

1514-BATT rechargeable battery pack from Bayco Products.

y Warning: To prevent ignition of a hazardous atmosphere, the rechargeable battery

pack must only be exchanged in an area known to be non-hazardous.

y Warning: Do not expose the rechargeable battery pack to water or salt water, or

allow the battery pack to get wet.

y Warning: Do not store the rechargeable battery pack with metallic objects that may

cause a short circuit.

y Warning: Substitution of components components is not allowed and may impair

intrinsic safety.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

For personal safety, always conrm the rating of any known hazardous or potentially

hazardous location where the light is to be used.

INITIAL USE

Warning: To prevent ignition of a hazardous atmosphere, do not attempt

to charge this product in the hazardous environment. This task must ONLY be

performed in an area known to be non-hazardous.

Fully charge the XPR-5590 before the rst use, or if the battery is new or has been

unused for several months. The maximum charge time required is approximately 4-6

hours.

DAILY USE

WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE, DO NOT

ATTEMPT TO CHARGE THIS PRODUCT IN THE HAZARDOUS ENVIRONMENT.

THIS TASK MUST ONLY BE PERFORMED IN AN AREA KNOWN TO BE NON-

HAZARDOUS.

y Use only the supplied Nightstick AC, DC adapter, or USB cord. For best performance,

charge the XPR-5590 when the light starts to dim.

y Connect the AC, DC adapter, or USB cord into the bottom of the light.

y The total time to full charge the XPR-5590 varies depending on the remaining charge

in the battery pack.

y In order for the light to be waterproof the rubber plug must be reinserted into the

charging port. (Image 1)

Image 2Image 1 Image 3

SETTING UP THE WORK LIGHT WITH TRIPOD

Opening the tripod leg set:

Fully unfold the Tripod leg set and slide the center collar down until it locks into place.

WARNING: Do NOT attempt to use the tripod leg set unless the legs are fully extended

and locked into place. This is the ONLY position that the leg set can be used in.

Closing the tripod leg set:

Press the release button on the side of the center collar and then raise the center

collar up until the tripod leg set is fully retracted.

Adjusting the column sections:

The tripod has two adjustable sections of the column that can be used to customize

the working height of the work light. Each section is locked into place by means of a cam

lock lever. (Image 2) To adjust the height of either section, release the cam lock lever for

that section, extend the column to the desired length and the re-lock the cam lock lever.

Removing the light head from the tripod:

The NSR-5590 is designed so that the light head can be removed from the tripod.

To remove the light head, grasp the lights handle with one hand, and grasp the top of

the tripod stand with the other hand a pull the magnet apart from the mounting plate.

Installing the light head onto the tripod:

CAUTION: Before installing the light head on to the tripod, be certain that the leg

set is fully extended and locked in place and that both of the two column cam lock

levers are securely locked.

To install the light head on to the tripod, simply line up the light heads magnetic

base with the tripods mounting plate (Image 3) allowing the magnet to secure itself to

mounting plate. Be sure place the light head directly onto the center of the mounting

plate so that the light head is securely mounted.

OPERATION

CAUTION: BECAUSE THE XPR-5590 HAS A MAGNETIC BASE, IT IS LIKELY

THAT IT WILL BE PLACED IN AN ELEVATED POSITION ABOVE THE GROUND.

THEREFORE CAUTION SHOULD BE USED TO BE CERTAIN THAT THE MAGNET

IS SECURELY ATTACHED TO THE METAL SURFACE BEFORE RELEASING THE

LIGHT. IT IS ALSO ADVISED THAT EXTRA CARE BE TAKEN WHEN ADJUSTING

OR MOVING THE CORD SO THAT THE WORK LIGHT DOES NOT COME LOOSE

AND FALL TO THE GROUND.

The XPR-5590 has a single three-position toggle switch with black boot. Operation

as seen from the back of the light:

y Center position: Off

y Right position: High-brightness

y Left position: Low-brightness

WARRANTY

1 YEAR WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship

and materials to the original purchaser for 1 year from the date of purchase, and includes

the LEDs, housing, lenses, electronics, switches, rechargeable batteries and chargers.

Bulbs (other than LEDs) are covered for 90 days from the date of purchase.

We will repair or replace this product should we determine it to be defective. This is the

only warranty, expressed or implied, including any warranty of merchantability or tness for

a particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/nightstick-

product-support/warranties. Retain your receipt for proof of purchase.
