Nitecore EMR20 Manual

Nitecore Batterioplader EMR20

Læs gratis den danske manual til Nitecore EMR20 (2 sider) i kategorien Batterioplader. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om Nitecore EMR20, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/2
保固服务
NITECORE® 产品拥有售后保固服务。在购买本产品的 15 天内，
如果有任何质量问题均可向经销商要求免费更换。在购买本产品
的 12 个月内享受免费保固服务。在超过 12 个月免费保固期后，
厂家将收取相应的材料费以及快递费。
本保固规则不适用于以下情况：
1. 人为破坏，拆解，改装本产品。
2. 错误操作导致产品损坏。
如对奈特科尔产品有任何疑问，欢迎联系当地的代理商或发邮件
到 4008869828@nitecore.cn
※ 本说明书中出现的商标及其产品图片版权属于其合法持有人，
此处仅作展示所用。
※ 本说明书的所有图片、陈述及文字信息仅供参考，请以官网
www.nitecore.cn 实际信息为准。广州希脉创新科技有限公
司拥有对说明书内容的最终解释权和修改权。
警告
使用前请仔细阅读使用说明。
本品并非玩具，仅供成人使用。
产品介绍
EMR20 专为户外作业、野营、钓鱼、徒步等户外活动而设计
产品参数
输入电压 USB-C：5V
⎓
2.4A 9V
⎓
2A（18W 最大）
输出电压 USB-C：5V
⎓
2.4A 9V
⎓
2A 12V
⎓
1.5A（18W 最大）
额定容量 6400mAh 5V （TYP 1A ）
电池容量 10000mAh 36Wh
加热温度 125℃ （257 ℉）（最高）
模式
室内模式：10m
2
保护区域
户外模式：20m
2
保护区域
尺寸
135mm x 48.8mm x 31mm
（5.3" x 1.9" x 1.2"）（不含配件）
重量 227g ± 5g（8oz ± 0.1oz）（不含配件）
配件 隔热罩、USB-C 充电线、驱蚊片 x 10
防护等级 IPX5
充电：
连接电源：
把 USB-C 充电线一端连至本品 USB-C 接口，另一端接上 USB
适配器、移动电源或其他USB供电设备。（输入：5V
⎓
2A
9V
⎓
2A）
注：在充电过程中，可开启驱蚊功能。
操作说明
· 开启：关闭状态下，短按再长按开关按键，4 颗电量指示灯递
增至全亮，开启驱蚊功能。按键指示灯蓝色长亮，此时默认
开启户外模式。
· 关闭：开启状态下，长按开关按键电量指示灯递减至全灭，
开关按键指示灯关闭，即关闭驱蚊功能。
· 室内模式 / 户外模式切换：开启驱蚊功能状态下，短按开关按
键可切换模式。开关按键指示灯蓝色长亮为户外模式，绿色
指示灯长亮为室内模式。
电量提示
· 短按开关按键，电量指示灯将会亮起提示剩余电量。当只有
1 颗电量指示灯闪烁，代表电量低，提示应及时进行充电。
· 充电过程中，电量指示灯会闪烁提示充电进度。充满电时，
4 颗电量指示灯长亮。
指示灯 剩余电量
4 颗亮起 约 100%
3 颗亮起 约 75%
2 颗亮起 约 50%
1 颗亮起 约 25%
1 颗闪烁 电量低，请及时进行充电
使用 EMR20
(1) 关闭状态下，取 1 片驱蚊片插至驱蚊片放置区上。
(2) 开启驱蚊功能。
(3) 10 分钟后即可建立保护区域。
(4) 使用完毕后，长按开关按键即关闭，让其进行完全冷却才可
存储。
注:奈特科尔驱蚊片尺寸
34mm
x
48mm
功效最长可达
6
小时/ 片。
替换驱蚊片
请确保 EMR20 已经关闭并且冷却，插入新的驱蚊片将使用过的
驱蚊片推出。
放置 EMR20
· 有风状态，请将 EMR20 放在驱蚊区域的上风处。
· 使用过程中请不要覆盖 EMR20。
· 如果驱蚊区域面积过大，建议多个 EMR20 一起使用。
给其他设备充电
USB 输出功能：EMR20 具有 USB 输出功能，可作为移动电源为
外部 USB 充电设备供电。
连接外部设备：把 USB-C 充电线一端连至本品输出接口，另一
端接上充电设备，即可对设备进行充电。
注：放电过程中，若电池电压过低会自动关闭输出以保护电池。
保存和运输
· 本产品在不使用时，请储存在干燥的室温环境中。
· 当需要长时间储存本品时，请每 3 个月充电一次。
注意事项
1. 在使用驱蚊功能时，请安装上隔热罩，以防高温烫伤。
2. 本品适用人群为 18 岁以上成年人，请远离儿童。
3. 为了减少烫伤风险，当在儿童附近使用本品时，需要进行密
切地监护。
4. 当本品开始工作时，不可无人看管。若发现有任何故障，请
立即停止操作。
5. 请勿将本品放置在水中。
6. 请勿将手指、金属或者其他外来物体放入本品中。
7. 请勿在密闭的空间中使用本品。
8. 如果发现电池有任何泄漏、异味或变形，应立即停止使用并
将其安全处理。
9. 不要让本产品长时间处于高于 60℃的环境中。
10. 切勿擅自拆卸、组装或改装本品，可能会导致保修服务失效，
详情请查看保固条款。
EMR20
@NITECORE 奈特科尔
@NITECORE 奈特科尔
了解 NITECORE 奈特科尔最新动态，欢迎关注：
广州希脉创新科技有限公司
咨询热线：+86-20-83862000
销售邮箱：info@nitecore.com
网 址：www.nitecore.cn
地 址：广东省广州市天河区高普路 1021 号 5 楼 6355 号
邮 编：510653
EMR30082022
Warnings
1. Please install the Heat Insulation Guard when using the
product to prevent scalds.
2. The product is designed to be used by adults. Keep the
product out of reach of children.
3. Children under 16 years old must be under adult
supervision when using this product to prevent scalds and
accidents.
4. DO NOT leave the product unattended when it is in use.
Stop using the product at any sign of malfunction.
5. DO NOT place the product in water.
6. DONOTputyourngers,metalsorforeignmattersinto
the product to avoid accidents or damage.
7. DONOTusetheproductinaconnedspace.
8. Stop using the product and dispose of it immediately if
thereisanyleakage,odor,ordeformationinthebattery.
9. DO NOT expose the product to temperatures above 60°C
(140℉)foralongtime.
10. DO NOT disassemble or modify the product without
authorization,asthiswillcausethewarrantytobenullied.
Please check the Warranty Service for details.
Warranty Service
All NITECORE
®
products are warranted for quality. Any DOA /
defective product can be exchanged for a replacement through
a local distributor/dealer within 15 days of purchase. After
that,alldefective/malfunctioningNITECORE
®
products can
be repaired free of charge within 12 months from the date
ofpurchase.Beyond12months,thechargeforaccessories,
replacement parts and delivery shall be at your own expenses.
Thewarrantywillbenulliedif
1.theproduct(s)is/arebrokendown,reconstructedand/or
modiedbyunauthorizedparties.
2.theproduct(s)is/aredamagedduetoimproperuse.
For the latest information on NITECORE
®
productsandservices,
please contact a local NITECORE
®
distributor or send an email
to service@nitecore.com
※Thetrademarksandproductimagesspeciedhereinthis
user manual are for reference purposes only. The copyright
belongs to their lawful holders.
※Allimages,textsandstatementsspeciedhereinthis
user manual are for reference purposes only. Should any
discrepancy occur between this manual and information
speciedonwww.nitecore.com,SysmaxInnovationsCo.,
Ltd. reserves the rights to interpret and amend the content
of this document at any time without prior notice.
Worldwide Warranty Service
Model number Date of purchase
————————————— —————————————
Serial number Store Stamp
————————————— —————————————
Thisisthecerticateofauthenticityifthisitemandwe
conrmthatithasbeensubjectedtothemostexacting
qualitycontrolsbySYSMAXInnovationsCo.,Ltd.
NOTE:
Please ensure this warranty card is fully completed by the
distributor or retailer after purchasing the product. Should
the product fail to operate correctly during the warranty
period,itmaybereturnedwiththecompletedwarrantycard
and original sales receipt to the retailer or local distributor
for replacement or repair.
Customer Service Email: service@nitecore.com
SYSMAX Innovations Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address
：
Unit6355,5/F,No.1021
GaopuRoad,TianheDistrict,
Guangzhou,510653,Guangdong,China
Thanks for purchasing NITECORE!
Made in China
EMR30082022
Please󽗉ndusonfacebook:NITECORECharger
EMR20
Portable Electronic
Multipurpose Repeller
IMPORTANT
Read all instructions before use.
This product is intended for adult use only. This product is not
a toy.
Product Introduction
TheEMR20isspeciallydesignedforoutdooractivities,suchas
outdoorwork,camping,shing,trekkingandmore.
Specifications
Input 5V⎓2.4A / 9V⎓2A(18WMAX)
Output 5V⎓2.4A / 9V⎓2A / 12V⎓1.5A(18WMAX)
Rated Capacity 6,400mAh5V(TYP1A)
Capacity 10,000mAh36Wh
Heating
Temperature
125℃/257℉MAX
Modes
Indoor Mode: 11ft Protection Zone
Outdoor Mode: 16ft Protection Zone
Dimensions
135mm x 48.8mm x 31mm
(5.3"x1.9"x1.2")(AccessoriesNotIncluded)
Weight
227g±5g(8oz±0.1oz)
(AccessoriesNotIncluded)
Accessories
HeatInsulationGuard,USB-CCharging
Cable,10xMosquitoRepellentMats
Waterproof
Rating
IPX5
Charging
Connecting to the External Power
Use the USB cable to connect an external power supply (e.g.
aUSBadapter,apowerbankorotherUSBchargingdevice)to
the USB charging port to begin the charging process. (Input:
5V⎓2A / 9V⎓2A)
Note: The mosquito repelling function can be activated during
the charging process.
Operating Instructions
· On: WhentheEMR20iso,shortpressandthenlongpress
the Power Button until all 4 indicators turn on one by one
toactivatethemosquitorepellingfunction,afterwhichthe
blue indicator beneath the Power Button will remain steadily
turned on to indicate the access to Outdoor Mode (Default
StartupMode).
· O:WhentheEMR20ison,longpressthePowerButton
untilall4powerindicatorsturnoonebyonetoturnothe
mosquito repelling function.
· Mode Switching: When the mosquito repelling function is
on,shortpressthePowerButtontoswitchbetweenIndoor
Mode and Outdoor Mode. If the blue indicator beneath the
PowerButtonissteadilyon,theEMR20isinOutdoorMode.
Ifthegreenindicatorissteadilyon,theEMR20isinIndoor
Mode.
Power Indication
· Short press the Power Button and the power indicators will
turn on to indicate the power level. The EMR20 needs to get
rechargedwhenthelastpowerindicatorashestoindicate
low power.
· Duringthechargingprocess,thepowerindicatorswillash
to indicate the power level. All 4 indicators will turn on
steadily when the product is fully charged.
Status of Indicators Power Level
4 Constant-on Approx. 100%
3 Constant-on Approx. 75%
2 Constant-on Approx. 50%
1 Constant-on Approx. 25%
1 Flashing
Nearly Depleted (Please charge the
productassoonaspossible)
Using the EMR20
1.Whentheproductiso,insert1repellentmatintothe
Repellent Mat Placement Area.
2. Activate the mosquito repelling function.
3. The protection zone will be created after 10 minutes.
4.Afteruse,longpressthePowerButtontoturnothe
mosquito repelling function. Please store the product after
cooling completely.
Note: NITECORE Mosquito Repellent Mat Size:
34mmx48mm/1.34"x1.89"(upto6hourseach)
Mosquito Repellent Mat Replacement
MakesuretheEMR20isoandcooled.Insertanewrepellent
mat while pushing out the used one.
EMR20 Placement
· Place the EMR20 upwind of the mosquito repellent area if it
is windy.
· DO NOT cover the EMR20 during the using process.
· It is recommended to use multiple EMR20 together to create
a larger protection zone.
Charging the External Device
USB Output:AvailablewiththeUSBoutput,theEMR20canbe
used as a power supply to charge external devices.
Connecting to the External Device: Use the USB cable to
connect an external USB device to the USB charging port to
begin the charging process.
Note: Duringthedischargingprocess,theUSBoutputwillbe
automaticallyotoprotectthebatteryifthebatteryvoltageis
low.
Storage and Transportation
· Store the product in ventilated and dry places at room
temperature.
· Charge the product every 3 months if it is not used for a long
period of time.
New
Used

Produkt Specifikationer

Mærke: Nitecore
Kategori: Batterioplader
Model: EMR20

Har du brug for hjælp?

Hvis du har brug for hjælp til Nitecore EMR20 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Batterioplader Nitecore Manualer

Nitecore

Nitecore SUMMIT 10000 Manual

27 September 2025
Nitecore

Nitecore EMR20 Manual

27 September 2025
Nitecore

Nitecore AD10 Manual

27 September 2025
Nitecore

Nitecore UI1 Manual

27 September 2025
Nitecore

Nitecore SC2 Manual

27 September 2025
Nitecore

Nitecore EBP10 Manual

3 September 2025
Nitecore

Nitecore izzCool 10 Manual

29 August 2025
Nitecore

Nitecore AP05C Manual

5 August 2025
Nitecore

Nitecore EMR15 Manual

5 August 2025
Nitecore

Nitecore izzCool 20 Manual

5 August 2025

Batterioplader Manualer

Nyeste Batterioplader Manualer

ISDT

ISDT Limeta MC336 Manual

25 September 2025
ISDT

ISDT Air 3 MC331 Manual

25 September 2025
Energizer

Energizer Recharge Pro Manual

22 September 2025
Watson

Watson C-3403 Manual

22 September 2025
Watson

Watson DX-4203 Manual

21 September 2025
Watson

Watson C-1517 Manual

21 September 2025
AKG

AKG CU4000 Manual

19 September 2025
Intenso

Intenso MW1 Manual

19 September 2025
Awelco

Awelco Thor 450 Manual

19 September 2025
Oukitel

Oukitel BP2000 Manual

18 September 2025
