PES400: PA28981A01_01 Page: 1 of 51 4-2018
Table of contents
1. SETUP and INSTALLATION GUIDE ........................................................... 3
1.1 Unpacking ............................................................................................................. 3
1.2 Checking the Accessories ................................................................................... 3
1.3 Connecting Communication Cables .................................................................... 5
1.4 Install Software for the USB to Serial Adapter .................................................... 6
1.4.1 System Requirements ............................................................................... 6
1.4.2 Install Software for the USB to Serial Adapter (XP, Vista, 2000) ............ 7
1.4.3 Windows 7, 8 and 10 .................................................................................. 7
1.5 Install External Hopper ......................................................................................... 7
1.6 Easy-Mark Plus™ Software Installation .............................................................. 7
2. INTRODUCTION .......................................................................................... 9
3. SYSTEM SPECIFICATIONS ...................................................................... 15
3.1 Electrical Specification ....................................................................................... 15
3.1.1 Equipment Classification and Standard Reference ............................. 15
3.1.2 Working Condition .................................................................................. 15
3.1.3 Dimensions and Weight ......................................................................... 15
3.1.4 Production Capacity ............................................................................... 16
3.2 Safety Regulations and Operating Precautions ............................................... 17
4. MACHINE SETUP FOR PRODUCING PLATES ....................................... 19
4.1 Quick Start Steps for Changing Plate Sizes and Embossing .......................... 19
4.2 Detailed Setup Instructions ................................................................................ 21
4.2.1 Remove Top Weights ............................................................................... 21
4.2.2 Remove Plates ......................................................................................... 21
4.2.3 Move RH Side Wall ................................................................................... 21
4.2.4 Plate Support Block Changeover ........................................................... 22
4.2.5. Gate Height Adjustment ......................................................................... 26
4.2.6. Guide Rail Adjustment ............................................................................ 30
4.2.9 Loading Marker Plates ............................................................................. 32
4.2.10 Side Eject Guide Plate Adjustment: ..................................................... 32
4.2.11 External Hopper Adjustment ................................................................. 33
4.2.11a Gripper Assembly Jaw Pressure Adjustment ................................... 35
4.2.12 Turn on PES400 ..................................................................................... 36
4.2.13 Open and use Panduit Easy-Mark Plus™ software............................. 36
4.2.14 Embossing Plates .................................................................................. 39
4.2.15 Changing Plate Formats ........................................................................ 40
4.3 Embossing Force Adjustment ........................................................................... 40
5. Error Codes .............................................................................................. 43
5.1 PES400 Display ................................................................................................... 43
5.2 Easy-Mark Plus™ Errors .................................................................................... 46
6. TROUBLE SHOOTING .............................................................................. 47
7. GENERAL MAINTENANCE ...................................................................... 48
8. CLEANING AND MAINTENANCE SCHEDULE FOR PES400 .................. 49
