Side 1/5

Tom Holder

Crash Cymbal

Cymbal Boom Stand

Hi-Hat Stand

Snare Stand

Drum Throne

Drum Pedal

Cymbal Stand

Ride Cymbal

Hi-Hat Cymbal

Snare Drum

Tom Tom Tom Tom

Bass Drum

Floor Tom

Instruction Manual

Congratulations on your purchase! To get optimum performance from your Pearl drum set,

please read this Instruction Manual first before playing.

PEARL DRUMS

Set-Up Example

*Illustrations shown in this manual are Decade Maple drums and 930 series hardware.

* Cymbals are not included in the set.

E X L・E X X

4. Position the Bass Drum with the Tom Holder Bracket

facing upwards. Loosen the Wing Nut on the Bass

Drum Spur and rotate it to the position shown. Tighten

the Wing Nut to secure. Loosen the Wing Bolt and

extend the Spurs so that the front of the Bass Drum is

about an inch off the floor. Make sure that the Spurs on

both sides are equal in length, and tighten the Wing

Bolts. The Bass Drum Spurs have Spike Tips (for added

slip resistance) that can be exposed by turning the

Lock Nut and Rubber Tip clockwise (Fig.5).

1. Place the Shell on a clean, solid surface with the front

side (the side with the Bass Drum Spurs attached)

facing upwards. Put the Front Head with Pearl Logo on

the Shell then attach the Bass Drum Hoop with flat side

down on the Rim of the Head (Fig.1).

3. Turn the Shell over to the batter side and place the

other Head and Bass Drum Hoop on the Shell. The

batter side Bass Drum Hoop has a Hoop Protector

(Fig.4) where the Pedal is to be attached. Position the

Bass Drum Hoop so that the Hoop Protector is on the

opposite side of the Tom Holder Bracket. Attach the

Tension Rods/Hooks in the same way as the front side

(Fig.3).

Bass Drum Assembly

The Bass Drum is packed with the Shell, Bass Drum

Hoops, Heads and Parts unassembled. Please follow the

instructions below to assemble the Bass Drum.

Fig.2

Fig.5

2. Pass a Tension Rod through a Hook, and hook it on the

Bass Drum Hoop above a Lug. Finger tighten the

Tension Rod into the Lug and do the same with the rest

of the Tension Rods/Hooks on this side of the drum

(Fig.2). Using a Tuning Key, tighten the Tension Rod

until secure (Refer to the “Basic Tuning” section at the

end of this manual).

CAUTION

The Spike Tips are sharp. Be careful not to hurt yourself or

others when using them. Use the Spike Tips only on thick

carpeted surfaces to prevent damage to the flooring underneath.

Note

The Bass Drum Hoop without the Hoop Protector (Fig.4) is

used on the front side.

Fig.4

Tom Holder Bracket

Hoop Protector

Hoop Protecter

Hook

Tension Rod

Bass Drum Hoop

Head

Bass Drum Hoop

Cross-section

drawing

Bass Drum Spur

Bass Drum Hoop

Front Head (w/Logo)

Shell

Fig.1

(Front side)

Fig.3

(Batter side)

Tension Rod

Hook

Lug

Bass Drum Hoop

Rim of the Head

Spike Tip

Lock Nut

Rubber Tip

Wing Bolt

Wing Nut

Bass Drum Spur

Tom Holder Bracket
