User’s Manual of LRP-822CS/LRP-1622CS

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be

required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the power cable to

disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it

is strongly suggested to remove the power connection for the device if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET Multi-port Coax + 2-port 10/100/1000T + 2-port 100/1000X SFP Long Reach PoE over Coaxial Switch User's Manual

For Model: LRP-822CS/LRP-1622CS

Revision: 1.1 (Jul. 2015)

Part No: EM-LRP-822CS_LRP-1622CS_v1.1

Produkt Specifikationer

Mærke:	Planet
Kategori:	Netværkskort/adapter
Model:	LRP-822CS
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	440 mm
Dybde:	300 mm
Højde:	44.5 mm
Vægt:	3878 g
Produktfarve:	Blå
Formfaktor:	1U
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Driftstemperatur (T-T):	0 - 50 °C
Sikkerhedsalgoritmer:	128-bit AES
Husmateriale:	Metal
Strømforbrug (maks.):	320 W
Netværksstandarder:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Understøttede netværksprotokoller:	IPv4 / IPv6
Webbaseret administration:	Ja
Knap til nulstilling:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Ja
Harmoniseret systemkode (HS):	85176990
Firmware kan opgraderes:	Ja
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ja
Switch-type:	Administreret
ARP inspektion:	Ja
System hændelseslog:	Ja
Total Power over Ethernet (PoE):	240 W
Power over Ethernet plus (PoE+) porte, antal:	8
Power over Ethernet (PoE) effekt pr. port:	36 W
10G understøttelse:	Ingen
Spanning tree protokol:	Ja
Auto MDI/MDI-X:	Ja
VLAN understøttelse:	Ja
Flowkontrol support:	Ja
Auto-sensing:	Ja
Port-spejlning:	Ja
Antal VLAN'er:	4094
Link aggregering:	Ja
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Vituelle LAN funktioner:	Private VLAN, Tagged VLAN, Protocol-based VLAN
Basis omskiftning RJ-45 Ethernet porte, antal:	2
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
Port til konsol:	RJ-45
IGMP snooping:	Ja
BPDU filtrering/beskyttelse:	Ja
Adgangskontrolliste (ACL):	Ja
Godkendelse:	Portbaseret godkendelse
IP-MAC-portbinding:	Ja
Filtrering af MAC-adresser:	Ja
Loop beskyttelse:	Ja
Administrationsprotokoller:	web, telnet, SNMP
Fiber ethernet kabelteknologi:	1000BASE‑LX, 1000BASE‑SX
Opbevar-og-frem:	Ja
MAC adresselabel:	8000 entries
Switch kapacitet:	9.6 Gbit/sek.
Antal køer:	8
Jumbo Frames support:	Ja
Jumbo rammer:	10000
Stativ-montering:	Ja
Varmeafgivelse:	1091.8 BUT/t
Multicast-understøttelse:	Ja
Trafik klassificering:	Ja
Antal SFP modulslots:	2
Gigabit Ethernet (kobber) porte, antal:	2
Begrænsning af hastighed:	Ja
DIN-skinne montering:	Ingen
Auto-forhandling:	Ja
SSH/SSL support:	Ja
