Side 1/2

www.princetontec.com

ENGLISH

Figure 1 – Switch Operation

Opération de commutation Betriebsartenschalter

• Princeton Tec calculates total burn time as the time it takes for the light source to produce

a minimum of 0.25 lux at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.

• Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe

erzeugte minimale Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux

entsprechen in etwa der Beleuchtungsstärke des Vollmonds in einer klaren Nacht.

• Princeton Tec définit la durée totale d’éclairage comme le temps nécessaire à la source

lumineuse pour produire un minimum de 0,25lux à 2mètres. 0,25lux équivaut à peu près à

la luminosité d’une pleine lune dans un ciel nocturne dégagé.

AMP 3.5

LED FLASHLIGHT

Operating and Maintenance

Instructions

Notice d’utilisation et d’entretien

Bedienungsanleitung

Figure 2 – Battery Replacement

Remplacement des piles

Einlegen der Batterien

High

112

Battery

Type

Low

Power Level

Output

Distance (m)

Overall

Burn Time (Hours)

4 AAA

Alkaline

* The times listed in this chart assume you start with fresh batteries and use

only one mode.

* Les durées mentionnées dans le présent tableau sont calculées sur la

base de l’utilisation de piles neuves et d’un seul mode d’éclairage.

* Bei den in der folgenden Tabelle aufgeführten Zeiten wird vorausgesetzt,

dass Sie neue Batterien und lediglich eine Leuchtstärke verwenden.

Battery Installation

– See Battery Installation Diagram

• 4 AAA

• Alkaline (LR03)

• Lithium (L92)

• Rechargeable NiCad or NiMH

NOTE: Rechargeable NiCad or NiMH batteries may result in

reduced brightness due to lower nominal voltage.

Princeton Tec cares about the environment and

recommends recycling batteries. For more information about

battery recycling, please go to: www.batteryrecycling.com

To install the batteries, rotate the lens cap counter clock wise

to remove it. Remove the module from the light to access the

battery compartment.

Install Four AAA batteries according to the polarity markings

on the inside of the battery compartment. Improper

installation of the batteries will damage the light and void the

warranty.

Place the module into the light body. Reinstall the lens cap

onto the body, rotating the lens clockwise until the lens is

snug. Do not over tighten the lens cap!

WARNING

• Never mix fresh and used batteries.

• Never mix different battery brands or chemistry

types.

• Always remove drained batteries immediately.

• Remove batteries during long periods of storage.

NOTE: Lithium batteries offer extended constant

brightness time, extreme cold weather performance,

and lighter weight. Rechargeable NiCad or NiMH

batteries may result in reduced brightness due to

lower nominal voltage.

Some battery formulations can emit hydrogen gas. This gas

can create an explosion potential in sealed devices if it is not

vented or removed. The platinum catalyst installed in this

light will remove the gas.

Switch Operation – See Switch Operation diagram

A quick press of the button will turn the light on. To change

from high to low, press the button again. You may switch

between the two settings without extinguishing the light. To

turn the light off, press and hold the button until the light

goes out. (about two seconds)

Circuitry and Power Consumption / Regulated LEDs

The AMP 3.5 uses a sophisticated current regulating circuit

that maintains initial brightness as long as the batteries have

sufficient voltage.

Regulated LEDs - Provide steady light output over a given

time period.

Non-Regulated LEDs – Have constantly diminishing light

over the same time period.

Regulated burn time is dependent on the battery type and

light level selected. As battery power diminishes, the different

modes (high and low) may appear to have the same

brightness level. This is a normal function of the Regulated

LED/Current controlled circuit. Replacing the drained

batteries with fresh ones will restore the full light function.

Refer to the burn time chart for performance data for different

battery types and mode settings.

O-Ring and Lens Cap

Occasionally clean and lightly lubricate the O-ring and Lens

Cap threads. Use only silicone grease, never use aerosol

spray lubricants. Certain types of aerosol sprays can cause

damage the plastic and void the warranty.

General Maintenance

As with any outdoor equipment, the light should be kept

clean with mild soap and water. Avoid getting dirt on the o

ring and in the threads of the lens cap. If this should occur,

take the light apart, remove the o ring, light module and

batteries, then clean the light body, lens and o ring

re-lubricate the o-ring and reassemble the light.

Troubleshooting

If the Amp 3.5 fails to light:

• Check the batteries for proper installation.

• Replace batteries if proper installation is confirmed.

• Check the light for water contamination. The light will

resume normal operation once the water is shaken or blown

out and the light is left open until completely dry. If the light

has been contaminated with salt water, flush the unit with

fresh water and dry as described above.

USA Lifetime Warranty– International 10-Year Warranty

Due to international regulations, Princeton Tec’s lifetime

warranty can only be offered to customers in the USA.

Princeton Tec offers a 10-year warranty to our customers

outside the USA.

FULL WARRANTY – Princeton Tec warrants this product to

be free from defects in workmanship and materials under

normal use for as long as you own this product. This

warranty covers all of the component parts of the product

except batteries. This warranty does not cover deterioration

due to normal wear or damage due to misuse, alteration,

negligence, accidents, or unauthorized repair. Princeton Tec

will repair or replace parts which are defective in

workmanship or materials.

Your authorized Princeton Tec Dealer and Princeton Tec are

the only facilities authorized to repair theproduct. After (3)

unsuccessful attempts to repair the product, you have the right

to elect replacement of the product or a refund of the purchase

price less allowance for use of the product. NO INCIDENTAL

OR CONSEQUENTIAL DAMAGES ARE INCLUDED IN THIS

WARRANTY. (Some states do not allow the exclusion or

limitation of incidental or consequential damages, so the above

limitations or exclusions may not apply to you.) This warranty

gives you specific legal rights, and you may also have other

rights which vary from state to state.

Princeton Tec reserves the right to change product

specifications without notice.

Return Policy

If your light fails to operate, follow these simple steps:

1) Check batteries. Replace if necessary.

2) Contact Princeton Tec customer service at 800-257-9080 to

request an RMA number to send your light in for repair or

replacement. No warranty repairs will be accepted without an

RMA number.

3) Return the light without batteries to: Princeton Tec, 5198 Rt.

130, Bordentown, NJ 08505. Postage due and freight collect

items will not be accepted.

Princeton Tec

PO Box 8057,

Trenton, NJ 08650

Phone: 609-298-9331

Fax: 609-298-9601

www.princetontec.com

press 1x = High

press 2x = Low

BURN TIME

1 10 20 30

DISTANCE (Meters)

HIGH 61 HLOW 90 H

(4) 5 MM

Ultrabright LEDs

BURN TIME

1 30 43 75

DISTANCE (Meters)

HIGH 2 HLOW 112 H

Maxbright

LED

Produkt Specifikationer

Mærke:	Princeton Tec
Kategori:	Lommelygte
Model:	AMP 3.5
Antal effektniveauer:	2
Vægt:	122 g
Produktfarve:	Black, Yellow
Lampe type:	LED
Batteriteknologi:	Alkaline
Vandfast:	Ingen
Batterilevetid (maks.):	112 t
Batteritype:	AAA
Antal understøttede batterier:	4
Pæreeffekt:	- W
Antal lamper:	1 Lampe( r)
Lommelygte type:	Hånd lommelygte
Lysstråle afstand (maks.):	75 m
Lysstrøm:	100 lm
