Side 1/3

www.princetontec.com

ENGLISH

Figure 1 – Switch Operation

Opération de commutation Betriebsartenschalter

* Princeton Tec calculates total burn time as the time it takes for the light source to produce a

minimum of 0.25 lux at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.

* Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe erzeugte

minimale Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux entsprechen in etwa

der Beleuchtungsstärke des Vollmonds in einer klaren Nacht.

* Princeton Tec définit la durée totale d’éclairage comme le temps nécessaire à la source

lumineuse pour produire un minimum de 0,25lux à 2mètres. 0,25lux équivaut à peu près à la

luminosité d’une pleine lune dans un ciel nocturne dégagé.

REMIX

LED HEADLAMP

Operating and Maintenance

Instructions

Notice d’utilisation et d’entretien

Bedienungsanleitung

Battery Installation – See Battery Installation Diagram

• 3 AAA

• Alkaline (LR03)

• Rechargeable NiCad or NiMH

Princeton Tec cares about the environment and

recommends recycling batteries. For more information

about battery recycling, please go to:

www.batteryrecycling.com

To install the batteries, unlatch the battery door. Open

the Remix case by popping the door latch over the

catch and rotate the door open.

Install three AAA batteries according to the polarity

markings on the inside of the cabinet. Observe proper

battery polarity when installing the batteries. Improper

installation of the batteries will damage the light and

void the warranty.

Rotate the door to the closed position, squeeze the

body between your forefingers and thumb to snap the

door latch over the catch.

WARNING

• Never mix fresh and used batteries.

• Never mix different battery brands or

chemistry types.

• Always remove drained batteries immediately.

• Remove batteries during long periods of storage.

NOTE: Rechargeable NiCad or NiMH batteries

may result in reduced brightness due to lower

nominal voltage.

Switch Operation – See Switch Operation diagram

The Remix has two light sources to choose from, three

Ultrabright LEDs or a Maxbright LED. Each light source

has two modes (High and Low).

To switch between light sources, press and hold the

button down until the light source switches to the

desired source. As soon as it switches release the

button.

NOTE: If you keep the button pressed the light will

continue to switch back and forth between the 5mm

and Maxbright LED (on low light settings) until you

release the button.

Once you have found your desired light source, you

now can select different brightness levels. Your light

will start on “low output”. To change to “high output”

you must press the button again in less than 1.6

seconds from the previous press. Any additional

delay will cause the light to turn off after the next

button press.

One final note about the light function – If you have the

light turned on, (and more than 1.6 seconds has

passed since your last button press) and you press

and hold the button down to switch light sources, you

will be in darkness for about one second as the light

sees this press as a signal to turn the light off and

switch to the other light source simultaneously.

**The times listed on the rear of the package

assume you have start with fresh batteries and

use only one mode.

Troubleshooting

If the Remix fails to light:

• Check the batteries for proper installation.

• Replace batteries if proper installation is

confirmed.

• Check the light for water contamination on the

circuit board. The light will resume normal operation

once the water is shaken or blown out and the light is

left open until completely dry. If the light has been

contaminated with salt water, flush the unit with fresh

water and dry as described above.

USA– International 5-Year Warranty

WARRANTY – Princeton Tec warrants this product to

be free from defects in workmanship and materials

under normal use for as long as you own this product.

This warranty covers all of the component parts of the

product except batteries. This warranty does not cover

deterioration due to normal wear or damage due to

misuse, alteration, negligence, accidents, or

unauthorized repair. Princeton Tec will repair or replace

parts which are defective in workmanship or materials.

Your authorized Princeton Tec Dealer and Princeton

Tec are the only facilities authorized to repair the

product. After (3) unsuccessful attempts (within the

warranty period) to repair the product, you have the

right to elect replacement of the product or a refund of

the purchase price less allowance for use of the

product. NO INCIDENTAL OR CONSEQUENTIAL

DAMAGES ARE INCLUDED IN THIS WARRANTY.

(Some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above

limitations or exclusions may not apply to you.) This

warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

Princeton Tec reserves the right to change product

specifications without notice.

Return Policy

If your light fails to operate, follow these simple steps:

1) Check batteries. Replace if necessary.

2) Contact Princeton Tec customer service at

800-257-9080 to request an RMA number to send your

light in for repair or replacement. No warranty repairs

will be accepted without an RMA number.

3) Return the light without batteries to: Princeton Tec,

5198 Rt. 130, Bordentown, NJ 08505. Postage due

and freight collect items will not be accepted.

Princeton Tec

PO Box 8057,

Trenton, NJ 08650

Phone: 609-298-9331

Fax: 609-298-9601

www.princetontec.com

Figure 2 – Battery Replacement

Remplacement des piles Einlegen der Batterien

press 1x = Low

press 2x = High

1 MAXBRIGHT

LED

DISTANCE (Meters)

10 38 53 73

LOW

53H

HIGH

28H

LOW

200H

HIGH

61H

DISTANCE (Meters)

10 23 28 53

To switch between light

sources, press and hold

button (1-2 seconds)

1 2

press 1x = Low

press 2x = High

3 ULTRABRIGHT

LEDs

Produkt Specifikationer

Mærke:	Princeton Tec
Kategori:	Lommelygte
Model:	HYB-BK
Vægt:	83 g
Produktfarve:	Sort
Lampe type:	LED
Vandfast:	Ja
Batterilevetid (maks.):	200 t
Batteritype:	AAA
Antal understøttede batterier:	3
Pæreeffekt:	- W
Antal lamper:	4 Lampe( r)
Lommelygte type:	Hovedbånd lommelygte
Lysstrøm:	100 lm
