70-305

www.rikontools.com

70-305M3

16”x42” Heavy Duty VSR Lathe

Operator’s Manual

Record the serial number and date of purchase in your manual for future reference.

Serial Number: _________________________ Date of purchase: _________________________

For technical support or parts questions, email techsupport@rikontools.com or call toll free at (877)884-5167

4001824

TABLE OF CONTENTS

SPECIFICATIONS

NOTE: The specications, photographs, drawings and information in this manual represent the current model

when the manual was prepared. Changes and improvements may be made at any time, with no obligation on

the part of Rikon Power Tools, Inc. to modify previously delivered units. Reasonable care has been taken to

ensure that the information in this manual is correct, to provide you with the guidelines for the proper safety,

assembly and operation of this machine.

Specications.....................................................................................................................2

Safety Instructions ........................................................................................................3 - 6

Getting To Know Your Machine ..............................................................................................7

Contents of Package .....................................................................................................7 - 8

Installation ......................................................................................................................8

Assembly ................................................................................................................................... 9

Operation ..................................................................................................................10 - 11

Adjustments...............................................................................................................12 - 14

Maintenance .................................................................................................................... 15

Electricals & Wiring Diagram .......................................................................................5 & 16

Troubleshooting ....................................................................................................................... 17

Parts Diagrams & Parts Lists .................................................................................. 18 - 21

Notes ......................................................................................................................... 15 & 22

Warranty .......................................................................................................................... 23

Motor .............................................................................................1-1/2 HP, TEFC

Volts, Phase ........................................................................................ 220 V, 1 Ph

Amps, Hertz ....................................................................................... 4.7 A, 60 Hz

Motor Speed (no load).......................................................................... 1,725 RPM

Direction ..................................................................................... Forward/Reverse

Swing Over Bed ................................................................................. 16” (46 mm)

Swing Over Tool Rest Base.............................................................. 12” (305 mm)

Distance Between Centers............................................................. 42” (1067 mm)

Speeds ............................................................................ Variable 0 - 3,200 RPM

Speed Ranges (2) ......................................................... 0 - 1,200; 0 - 3,200 RPM

Spindle Nose Threading....................................................................1-1/4” x 8 TPI

Headstock Taper ............................................................................................ MT-2

Tailstock Taper ............................................................................................... MT-2

Hole Through Drive Spindle .............................................................. 3/8” (10 mm)

Hole Through Tailstock ...................................................................... 3/8” (10 mm)

Tailstock RAM Travel ......................................................................... 4" (100 mm)

Number of Indexing Positions....................................................... 12 (36 possible)

Tool Rest Post Diameter ....................................................................1” (25.4 mm)

Headstock Rotation ........................................................................................ 360°

Spindle to Floor Distance .............................................................. 44“ (1118 mm)

Overall Size (LxWxH)........................ 77” x 22” x 47-1/4” (1956 x 559 x 1200 mm)

Base / Stand Size ........................................... 17-3/8” X 59-1/4” (441 x 1505 mm)

Net Weight ....................................................................................386 lbs (175 kg)
